Foton Aumark S3-Series 131hp 4X2(6 wheels) 4.04m refrigerated truck (Hongyu Brand)
EXW
From $15,611
Export quote
Zhengzhou Hongyu Foton Chassis Refrigerated Truck
Main model photos
31 photos
Models
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Foton Aumark S3-Series 131hp 4X2(6 wheels) 4.04m refrigerated truck (Hongyu Brand) | 4x2 / 131hp / China V | From $15,611 | |
| Foton Aumark S3 141hp 4X2(6 wheels) 4.04m Refrigerated Truck (Hongyu Brand) | 4x2 / 141hp / China V | From $17,264 |
Foton Aumark S3 141hp 4X2(6 wheels) 4.04m Refrigerated Truck (Hongyu Brand)
EXW
From $17,264
Export quote
Series Specs
Basic Info
Cab dimensions: 5.995×2.47×3.4m
Truck Type: Refrigerated Truck
Drive type: 4X2
Vehicle origin: Zhengzhou, Henan
Wheelbase: 3360mm
Front track width: 1730mm
rear track: 1615mm
Curb Weight: 3.2ton
Rated payload: 1.1ton
Max. speed: 108km/h
Front/rear suspension: 1.12/1.515m
Energy Type: Diesel
Engine parameters
Engine Model: FotonISF2.8s5129T / FotonISF3.8s5141
Number of cylinders: 4cylinder
Displacement: 2.78 / 3.76L
Emission standard: China V
Max output power: 96 / 105kW
Max hp: 131 / 141Horsepower
Max torque: 300 / 440N·m
Rated speed: 2900 / 2600rpm
Engine Type: Turbocharged intercooled, Bosch high-pressure common rail, high-pressure direct injection, SCR / Inline 4-cylinder, water-cooled, 4-stroke, turbocharged with intercooler, Bosch high-pressure common rail, high-pressure direct injection, SCR
Cargo box parameters
Cargo box dimensions: 4.04×2.3×2.2m
Cargo box width: 2.3m
Cargo box height: 2.2m
Body Parameters
Vehicle certification code: HYJ5040XLCB17
Body Brand: Hongyu brand
Chassis Specs
Chassis Brand: Foton
Chassis Series: Auman S3
Chassis Model: BJ1048V9JEA-FE
Front axle description: Payload 1850kg
rear axle description: Payload 2645kg
Leaf spring count: 3/7+6 / 3/7+6,3/8+6,3/4+2,3/5+2,9/8+6
Transmission Parameters
Number of gears: 5 / 6Gear
Transmission Model: WLY5-speed / WLYWLY6T120
Tire
Tire Size: 7.00R16LT 8PR / 7.00R16LT 8PR,7.50R16LT 6PR,8.25R16LT 6PR
Number of tires: 6pcs
FAQ
What kind of truck is Zhengzhou Hongyu Zhengzhou Hongyu Foton Chassis Refrigerated Truck?
Zhengzhou Hongyu Zhengzhou Hongyu Foton Chassis is an export-oriented Refrigerated Truck lineup with about 2 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Zhengzhou Hongyu Foton Chassis Refrigerated Truck?
Zhengzhou Hongyu Foton Chassis Refrigerated Truck export reference is about $15,611 – $17,264. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Zhengzhou Hongyu Foton Chassis Refrigerated Truck cover?
Zhengzhou Hongyu Foton Chassis Refrigerated Truck mainly covers: Drive: 4x2; Horsepower: 131 hp / 141 hp; Emission: China V; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Zhengzhou Hongyu Foton Chassis Refrigerated Truck?
For Zhengzhou Hongyu Foton Chassis Refrigerated Truck: 1) set emission; 2) match body/wheelbase to cargo type; 3) pick drive and horsepower; 4) compare prices, then open a model to quote.
What is Refrigerated Truck typically used for?
Refrigerated Truck covers box, stake or flatbed cargo work from city delivery to regional haul. Filter by body and payload needs.
How many models does Zhengzhou Hongyu Foton Chassis Refrigerated Truck include?
Zhengzhou Hongyu Foton Chassis Refrigerated Truck currently lists about 2 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Zhengzhou Hongyu Foton Chassis Refrigerated Truck?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
