FAW Jiefang J6L 240 hp 6X2(8 wheels) truck-mounted crane (Shangjun brand)
EXW
From $31,528
Export quote
Shangjun FAW Jiefang Chassis truck-mounted crane
Main model photos
5 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| FAW Jiefang J6L 240 hp 6X2(8 wheels) truck-mounted crane (Shangjun brand) | 6x2 / 240hp / China V | From $31,528 | |
| FAW Jiefang J6L 220 hp 6X2(8 wheels) truck-mounted crane (Shangjun brand) | 6x2 / 220hp / China V | From $30,694 | |
| FAW Jiefang J6M 280 hp 6X4(10 wheels) truck-mounted crane (Shangjun brand) (457 rear axle) | 6x4 / 280hp / China V | From $40,903 | |
| FAW Jiefang J6M 280 hp 6X4(10 wheels) truck-mounted crane (Shangjun brand) | 6x4 / 280hp / China V | From $40,111 | |
| FAW Jiefang J6M 260 hp 6X4(10 wheels) truck-mounted crane (Shangjun brand) | 6x4 / 260hp / China V | From $39,694 |
FAW Jiefang J6L 220 hp 6X2(8 wheels) truck-mounted crane (Shangjun brand)
EXW
From $30,694
Export quote
FAW Jiefang J6M 280 hp 6X4(10 wheels) truck-mounted crane (Shangjun brand) (457 rear axle)
EXW
From $40,903
Export quote
FAW Jiefang J6M 280 hp 6X4(10 wheels) truck-mounted crane (Shangjun brand)
EXW
From $40,111
Export quote
FAW Jiefang J6M 260 hp 6X4(10 wheels) truck-mounted crane (Shangjun brand)
EXW
From $39,694
Export quote
Series Specs
Basic Info
Cab dimensions: 12X2.55X3.8 / 12X2.55X3.85m
Type: truck-mounted crane
Drive type: 6X2 / 6X4
Wheelbase: 2200+5100 / 5800+1350mm
Rated mass: 10.025 / 8.575ton
GVWR: 25ton
Front/rear suspension: 1.4/3.3 / 1.4/3.45m
Energy Type: Diesel
Body Parameters
Crane model: SQ10;SQ8 / SQ12
Lifting capacity: 10;8 / 12ton
crane self-weight: 4.8;4.4 / 5.9ton
Vehicle certification code: CSJ5252JSQ5 / CSJ5250JSQ5
Body Brand: Shangjun brand
Engine parameters
Engine Brand: Dachai
Engine Model: DachaiCA6DH1-24E5 / DachaiCA4DK1-22E51 / DachaiCA6DK1-28E5 / DachaiCA6DK1-26E5
Displacement: 5.7 / 4.764 / 7.146L
Emission standard: China V
Max output power: 176 / 165 / 209 / 195kW
Max hp: 240 / 220 / 280 / 260Horsepower
Max torque: 900 / 820 / 1100 / 1050N·m
Max torque speed: 1200-1800 / 1200-1700rpm
Rated speed: 2500 / 2300rpm
Chassis Specs
Chassis Brand: FAW Jiefang
Chassis Series: FAW JiefangJ6L / FAW JiefangJ6M
Chassis Model: CA5250JSQP62K1L7T3E5 / CA5250JSQP63K1L5T1E5
Frame Dimensions: 270×75×(7+5+8) / 270×75×(7+5) / 300×80×(8+5+5)mm
rear axle description: Ф435 stamped-welded axle / Ф457 cast axle
Axle ratio: 4.875 / 5.143
Leaf spring count: 10/10/13+7,11/11/13+7 / 11/11,9/10
clutch: Φ395 / Φ430
Transmission Parameters
Number of gears: 8 / 10Gear
Transmission Model: Fast Gear8JS85E / FAWCA10TA130M / FAWCA10TAX130M
Cab parameters
Cab: J6L Semi-floating Flat Roof Short Extended Cab / J6M Semi-Float Flat Roof Small Day Cab
Tire
Tire Size: 11.00R20 / 295/80R22.5
FAQ
What kind of truck is Shangjun Shangjun FAW Jiefang Chassis truck-mounted crane?
Shangjun Shangjun FAW Jiefang Chassis is an export-oriented truck-mounted crane lineup with about 5 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Shangjun FAW Jiefang Chassis truck-mounted crane?
Shangjun FAW Jiefang Chassis truck-mounted crane export reference is about $30,694 – $40,903. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Shangjun FAW Jiefang Chassis truck-mounted crane cover?
Shangjun FAW Jiefang Chassis truck-mounted crane mainly covers: Drive: 6x2 / 6x4; Horsepower: 220 hp / 240 hp / 260 hp / 280 hp; Emission: China V; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Shangjun FAW Jiefang Chassis truck-mounted crane?
For Shangjun FAW Jiefang Chassis truck-mounted crane: define the job and emission first, compare key drive/power options, then open the matching model for special equipment and quote.
What is truck-mounted crane typically used for?
truck-mounted crane specs vary widely by job. Define the application first, then compare specs here and request a quote.
How many models does Shangjun FAW Jiefang Chassis truck-mounted crane include?
Shangjun FAW Jiefang Chassis truck-mounted crane currently lists about 5 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Shangjun FAW Jiefang Chassis truck-mounted crane?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
