Xichai CA6DL1-32E5 320hp 7.7L China V Diesel Engine
EXW
Export quote
Xichai Aowei 6DL1 Series engine
Main model photos
13 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Xichai CA6DL1-32E5 320hp 7.7L China V Diesel Engine | 320hp / China V | ||
| Xichai CA6DL1-29E5 290hp 7.7L China V Diesel Engine | 290hp / China V | ||
| Xichai CA6DL1-28E5 280hp 7.7L China V Diesel Engine | 280hp / China V | ||
| Xichai CA6DL1-26E5 260hp 7.7L China V Diesel Engine | 260hp / China V | ||
| Xichai CA6DL1-32E4U2 320 hp 7.7L China IV Diesel Engine | 320hp / China IV |
Xichai CA6DL1-29E5 290hp 7.7L China V Diesel Engine
EXW
Export quote
Xichai CA6DL1-28E5 280hp 7.7L China V Diesel Engine
EXW
Export quote
Xichai CA6DL1-26E5 260hp 7.7L China V Diesel Engine
EXW
Export quote
Xichai CA6DL1-32E4U2 320 hp 7.7L China IV Diesel Engine
EXW
Export quote
Series Specs
Engine parameters
Engine Series: Aowei 6DL1 series
Engine manufacturer: Xichai / FAW Jiefang Automobile Co., Ltd. without Xichai engine plant
Suitable Range: Ideal matching power for heavy-duty cargo trucks over 20 tons, large high-end buses 9-12m, large city buses, and 6-8m³ concrete mixer trucks / 11-13.7m coach, tour and large city bus; heavy-duty truck over 20 tons / 10-12m highway, tourist and city large bus / >20t heavy-duty cargo truck / 6-8m³ concrete mixer truck / 10-12m highway, tourist and city large buses; heavy-duty cargo trucks over 20 tons; 6-8m³ concrete mixer trucks / 10-12m highway, tourist and large city bus, over 20-ton heavy-duty cargo truck, 6-8m³ concrete mixer truck / 10-12m highway, tourist and city large bus, >20t heavy-duty cargo truck, 6-8m³ concrete mixer truck / 11–13.7m highway, tourist and city large bus, over 20t heavy-duty cargo truck, 8m³ concrete mixer truck, 50 loader
Intake type: Electronic unit pump / Turbocharged Air-to-Air Intercooling / Inline, direct injection, turbocharged, intercooled, electronically controlled common rail / Turbocharged intercooled, direct injection, inline, electronic common rail / Turbocharged intercooled, inline, direct injection, electronic common rail / Turbocharged
Min. fuel consumption at full load: 192 / ≤205 / 200 / ≤192 / 202 / 198 / 196 / ≤198 / ≤193g/kW.h
Engine net weight: 800 / 820 / 850（EGR） / 820（SCR） / 800 (excl. clutch, intercooler) / 800 (excluding clutch, intercoolerkg
Engine Dimensions: 1285×820×1080 / 1308×778×976 / 1285×820×1050mm
noise at 1m: ≤95 / 95.5 / ≤95.5 / ≤96.5 / 96.5dB
Bore × Stroke: 110x135mm
Valves per cylinder: 4pcs
Engine Brand: Xichai
Engine Model: CA6DL1-32E5 / CA6DL1-29E5 / CA6DL1-28E5 / CA6DL1-26E5 / CA6DL1-32E4U2 / CA6DL1-28E4U2 / CA6DL1-26E4U2 / XichaiCA6DL1-28E3U / CA6DL1-30E3 / CA6DL1-32E3U / CA6DL1-28E3U / CA6DL1-26E3U / CA6DL1-31E3F / CA6DL1-28E3F / CA6DL1-26E3F / CA6DL1-31E3 / CA6DL1-30E / CA6DL1-28E3 / CA6DL1-32E4 / CA6DL1-31E4(R) / CA6DL1-29E4(R) / CA6DL1-28E4(R) / CA6DL1-26E4 / CA6DL1-24 / CA6DL1-31 / CA6DL1-32 / CA6DL1-30 / CA6DL1-26 / CA6DL1-32E3 / CA6DL1-29E3 / CA6DL1-26E3 / CA6DL1-28
Number of cylinders: 6cylinder
fuel type: Diesel
Cylinder arrangement: Inline / 6-cylinder, inline, direct injection, turbocharged, intercooled
Displacement: 7.7L
Emission standard: China V / China IV / China III / Euro III / China II/Euro II
Max output power: 238 / 216 / 209 / 195 / 206 / 231 / 235 / 192 / 228 / 220 / 230 / 188 / 191 / 224kW
Max hp: 320 / 290 / 280 / 260 / 300 / 310 / 240 / 299Horsepower
Max torque: 1250 / 1150 / 1100 / 1050 / 1350 / 1000 / 1200N·m
Max torque speed: 1300-1700 / 1300-1600 / 1300-1500 / 1400 / 1200-1400rpm
Rated speed: 2300rpm
Engine Type: 6-cylinder inline, 4-valve, direct injection, electronic unit pump, SCR aftertreatment / 6-cylinder inline, direct injection, turbocharged intercooled, electronic unit pump / Inline, direct injection, turbocharged, intercooled, electronically controlled common rail / 6-cylinder inline, direct injection, turbocharged intercooled, inline pump EGR / 6-cylinder inline, direct injection, turbocharged intercooled, electronic common rail / 8-cylinder inline, direct injection, turbocharged intercooled, electronic common rail / 6-cylinder, inline, direct injection, turbocharged, intercooled / 6-cylinder, inline, direct injection, turbocharged, air-to-air intercooled / Inline, electronic, common rail, turbocharged, air-to-air intercooled / Inline, direct injection, electronically controlled common rail, turbocharged, intercooled, air-to-air intercooled
FAQ
What kind of truck is Xichai Xichai Aowei 6DL1 Series engine?
Xichai Xichai Aowei 6DL1 Series is an export-oriented engine lineup with about 32 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does Xichai Aowei 6DL1 Series engine cover?
Xichai Aowei 6DL1 Series engine mainly covers: Horsepower: 260 hp / 280 hp / 290 hp / 320 hp; Emission: China IV / China V; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Xichai Aowei 6DL1 Series engine?
For Xichai Aowei 6DL1 Series engine, choose in order: emission → drive → horsepower/fuel → compare price and photos → open a model to quote. Include port and quantity.
What is engine typically used for?
For engine, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does Xichai Aowei 6DL1 Series engine include?
Xichai Aowei 6DL1 Series engine currently lists about 32 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Xichai Aowei 6DL1 Series engine?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
