Foton Aumark S3 Series 156 hp 4X2(6 wheels) Wrecker Truck (China VI) (Pafeite Brand)
EXW
From $43,750
Export quote
Pafeite Foton chassis Tow Truck
Main model photos
34 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Foton Aumark S3 Series 156 hp 4X2(6 wheels) Wrecker Truck (China VI) (Pafeite Brand) | 4x2 / 156hp / China VI | From $43,750 | |
| Foton Aumark S3 Series 156 hp 4X2(6 wheels) Wrecker Truck (China VI) (Pafeite Brand) | 4x2 / 156hp / China VI | From $35,000 | |
| Foton Aumark S3 Series 156 hp 4X2(6 wheels) Wrecker Truck (China VI) (Pafeite Brand) | 4x2 / 156hp / China VI | From $32,778 | |
| Foton Aumark S3 170hp 4X2(6 wheels) Wrecker (China VI) (Pafeite brand) | 4x2 / 170hp / China VI | From $36,528 | |
| Foton Aumark S1 131 hp 4X2(6 wheels) Wrecker (China VI)(Pafeite) | 4x2 / 131hp / China VI | From $27,222 |
Foton Aumark S3 Series 156 hp 4X2(6 wheels) Wrecker Truck (China VI) (Pafeite Brand)
EXW
From $35,000
Export quote
Foton Aumark S3 Series 156 hp 4X2(6 wheels) Wrecker Truck (China VI) (Pafeite Brand)
EXW
From $32,778
Export quote
Foton Aumark S3 170hp 4X2(6 wheels) Wrecker (China VI) (Pafeite brand)
EXW
From $36,528
Export quote
Foton Aumark S1 131 hp 4X2(6 wheels) Wrecker (China VI)(Pafeite)
EXW
From $27,222
Export quote
Series Specs
Basic Info
Cab dimensions: 8.06×2.42×2.28 / 8.06×2.42×2.375 / 7.4×2.42×2.34 / 8.885×2.55×2.35 / 5.995×2.32×2.26 / 5.58×2.05×2.4 / 7.385×2.42×2.32 / 8.95×2.42×2.46 / 8.05×2.48×2.49 / 7.385×2.42×2.51 / 5.995×2.32×2.27 / 5.995×2.32×2.3 / 5.995×2.3×2.27m
Type: Tow truck (towing one vehicle)
Drive type: 4X2
Wheelbase: 4700 / 4200 / 3800 / 3360mm
Front/rear track width: Front: 1705mm; Rear: 1615 / Front: 1705mm; Rear: 1800 / Front: 1590mm; Rear: 1485 / Front: 1590; Rear: 1590 / Front: 1830mm; Rear: 1680 / Front: 1710mm; Rear: 1630 / Front: 1730mm; Rear: 1590 / Front: 1490mm; Rear: 1425
GVWR (Gross Vehicle Weight Rating): 7.5 / 7.75 / 5.28 / 7.4 / 3.8 / 5.6 / 3.9 / 4.98 / 6.62 / 6.73 / 5.78 / 3.965 / 3.995ton
GVWR: 9.99 / 8.275 / 9.995 / 4.495 / 8.28ton
Max. speed: 89 / 105 / 95 / 99km/h
Front/rear suspension: 1.13/2.73 / 1.13/2.47 / 1.13/3.055 / 1.11/1.525 / 1.11/1.11 / 1.12/2.465 / 1.195/3.055 / 1.12/2.73 / 1.085/1.55m
Energy Type: Diesel
Body Parameters
Lifting capacity: 2480 / 2400 / 500 / 400 / 3105 / 3175 / 3070 / 2305 / 410 / 370kg
Vehicle certification code: PFT5103TQZP6B / PFT5103TQZP6A / PFT5085TQZP6B / PFT5102TQZP6A / PFT5041TQZP6 / PFT5085TQZP6A / PFT5040TQZM5 / PFT5041TQZP25 / PFT5085TQZP15 / PFT5102TQZP5 / PFT5103TQZP15 / PFT5085TQZP5 / PFT5041TQZP35 / PFT5041TQZP15 / PFT5041TQZP5
Body Brand: Pafeite
Engine parameters
Engine Model: FotonF3.8NS6B156 / FotonF2.8NS6B156 / FotonF3.8NS6B170 / FotonF2.8NS6B131 / Yunnei PowerD25TCIE1 / FotonISF2.8s5129T / FotonISF3.8s5154 / FotonISF3.8s5168 / FotonISF2.8s5F117
Displacement: 3.8 / 2.78 / 2.499 / 3.76L
Emission standard: China VI / China V
Max output power: 115 / 125 / 96 / 105 / 87kW
Max hp: 156 / 170 / 131 / 143 / 168 / 154 / 129 / 117Horsepower
Chassis Specs
Chassis Brand: Foton
Chassis Series: Auman S3 / Auman S1 Series / Auman Series 3 / Auman Series 5 / Auman S3 Series
Chassis Model: BJ1108VEJED-F3 / BJ1088VEJEA-FK / BJ1108VFPEG-FK / BJ1045V8JDA-FK / BJ1045V9JD6-F2 / BJ5089XXY-FA / BJ1109VEPEG-A1 / BJ1109VEJED-A1 / BJ1049V9JD6-A2 / BJ1049V9JD6-A1
rear axle description: 6T / 6.5T / 4.5T / 4.5T; ratio 4.3 / Ratio 4.875 / 7T / Ratio 4.33
Leaf spring count: 3/8+6 / 9/8+6 / 3/5+2 / 9/11+7 / 8/10+10 / 9/10+10,9/11+7 / 8/10+10,9/10+10,3/4+3 / 3+1/6+7,9/11+7,3/6+7,3/8+6,3/4+3,6+1/9+7 / 7/4+5,3+1/6+7,3+1/5+4,7/6+7 / 3/4+2,3/5+2,3/3+2,3/2+1,2/2+1 / 7/4+5,7/6+7 / 3+1/6+7,9/11+7,3/6+7
Transmission Parameters
Number of gears: 6 / 5Gear
Transmission Model: WLYWLY6TS55 / WLYWLY6G70 / ZFZF5S328 / WLYWLY5S408 / WLYWLY5S328 / WLYWLY651B / DachiDC6J75TT / WLY 6-speed manual / WLY 5-speed manual / WLYWLY646B
Number of Reverse Gears:
Tire
Tire Size: 8.25R16LT 16PR / 7.50R16LT 14PR / 7.00R16LT 8PR / 7.00R16 8PR / 7.50R16LT 14PR,8.25-16LT 16PR
Number of tires: 6pcs
FAQ
What kind of truck is Pafeite Pafeite Foton chassis Tow Truck?
Pafeite Pafeite Foton chassis is an export-oriented Tow Truck lineup with about 20 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Pafeite Foton chassis Tow Truck?
Pafeite Foton chassis Tow Truck export reference is about $13,486 – $43,750. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Pafeite Foton chassis Tow Truck cover?
Pafeite Foton chassis Tow Truck mainly covers: Drive: 4x2; Horsepower: 131 hp / 156 hp / 170 hp; Emission: China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Pafeite Foton chassis Tow Truck?
For Pafeite Foton chassis Tow Truck: define the job and emission first, compare key drive/power options, then open the matching model for special equipment and quote.
What is Tow Truck typically used for?
Tow Truck specs vary widely by job. Define the application first, then compare specs here and request a quote.
How many models does Pafeite Foton chassis Tow Truck include?
Pafeite Foton chassis Tow Truck currently lists about 20 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Pafeite Foton chassis Tow Truck?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
