Foton Auman New ETX Basic 350hp 8X4(12 wheels) 7m Dump Truck (China VI)(Ratio 5.286)
EXW
From $41,222
Export quote
Auman Auman new ETX heavy truck Dump Trucks
Main model photos
304 photos
Models
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Foton Auman New ETX Basic 350hp 8X4(12 wheels) 7m Dump Truck (China VI)(Ratio 5.286) | 8x4 / 350hp / China VI | From $41,222 | |
| Foton Auman New ETX Basic 350hp 8X4(12 wheels) 6.8m Dump Truck (China VI)(Ratio 5.286) | 8x4 / 350hp / China VI | From $41,222 | |
| Foton Auman New ETX Basic 350hp 8X4(12 wheels) 6.5m Dump Truck (China VI)(Axle Ratio 5.286) | 8x4 / 350hp / China VI | From $41,222 | |
| Foton Auman New ETX Basic 350hp 8X4(12 wheels) 6.5m Dump Truck (China VI)(Axle Ratio 5.286) | 8x4 / 350hp / China VI | From $40,667 | |
| Foton Auman New ETX Basic 350hp 8X4(12 wheels) 6.2m Dump Truck (China VI)(Axle Ratio 5.286) | 8x4 / 350hp / China VI | From $40,667 |
Foton Auman New ETX Basic 350hp 8X4(12 wheels) 6.8m Dump Truck (China VI)(Ratio 5.286)
EXW
From $41,222
Export quote
Foton Auman New ETX Basic 350hp 8X4(12 wheels) 6.5m Dump Truck (China VI)(Axle Ratio 5.286)
EXW
From $41,222
Export quote
Foton Auman New ETX Basic 350hp 8X4(12 wheels) 6.5m Dump Truck (China VI)(Axle Ratio 5.286)
EXW
From $40,667
Export quote
Foton Auman New ETX Basic 350hp 8X4(12 wheels) 6.2m Dump Truck (China VI)(Axle Ratio 5.286)
EXW
From $40,667
Export quote
Series Specs
Basic Info
Model code (announced): BJ3313Y6GRL-07 / BJ3313Y6GRL-05 / BJ3313Y6GRL-01 / BJ3313Y6GRL-08 / BJ3313Y6GRL-06 / BJ3313DNPKC-AE / BJ3313DNPKC-AC / BJ3313DMPKJ-AC / BJ3313DMPKF-AD / BJ3313DMPKF-AC / BJ3313DMPKC-AD / BJ3313DMPKC-AC / BJ3313DMPKC-AA / BJ3313DNPKC-AB
Drive type: 8X4
Wheelbase: 2100+3000+1350 / 2100+2500+1350 / 2100+2300+1350 / 2100+2775+1350 / 2100+2325+1350 / 2100+3350+1350 / 2100+2750+1350 / 1800+2550+1350 / 1800+4500+1350 / 1800+4700+1350 / 1800+4300+1350 / 1800+3950+1350 / 1800+3650+1350 / 1800+3300+1350mm
Engine Model: WeichaiWP8.350E61 / FotonX11NS6B320 / FotonX11NS6B360 / WeichaiWP10.350E53 / WeichaiWP12.375E50 / WeichaiWP12.430E50 / FotonISGe5-400 / FotonISGe5-360
Transmission Model: Fast Gear10JSD160B / Fast Gear10JSD160T / Fast Gear12JSD200B / Fast Gear10JSD160 / Fast Gear12JSD180TA / Fast Gear12JSDX240TA / Fast Gear 12JSD180TA with PTO / Fast Gear12JSD180A
Rear Axle Ratio: 5.286 / 4.625 / 5.143 / 4.8 / 5.92
Cab length: 9.88 / 9.68 / 9.53 / 9.23 / 9.03 / 8.83 / 8.78 / 9.58 / 9.38 / 9.21 / 9.01 / 8.905 / 10.28 / 10.08 / 9.28 / 9.08 / 8.8 / 11.68 / 11.08 / 10.88 / 10.38 / 10.18m
Cab width: 2.55 / 2.495 / 2490m
Cab height: 3.58 / 3.7m
Front track width: 2020/2020 / 2021/2021 / 1960/1960 / 2005/2005mm
rear track: 1830/1830 / 1880/1880 / 1865/1865mm
Curb Weight: 13.5 / 15.5 / 14.79 / 14.8 / 15.385 / 15.2 / 15.1 / 14.98 / 14.88ton
Rated payload: 17.37 / 15.37 / 15.379 / 16.08 / 16.07 / 15.485 / 15.67 / 15.77 / 15.89 / 15.99ton
GVWR: 31ton
Origin: Huairou, Beijing / Beijing
tonnage class: Heavy truck
Approach angle: 18°
departure angle: 16 / 24°
Remarks: Double U-bolts. / Optional: leaf springs 10/10/12, 450L fuel tank. / Optional: leaf springs 10/10/12. / Loxa Kunlun / With PTO / With PTO; optional axle ratio 4.76/5.92; high-roof cab
Series: 9 series / 6 series
Version:
Energy Type: Diesel
Engine parameters
Engine Brand: Weichai / Foton
Number of cylinders: 6cylinder
Displacement: 7.8 / 10.5 / 9.726 / 11.596 / 11.8L
Emission standard: China VI / China V
Max output power: 257 / 235 / 265 / 276 / 316 / 294kW
Max hp: 350 / 320 / 360 / 375 / 430 / 400Horsepower
Max torque: 1400 / 1600 / 1800 / 2060 / 2100 / 1900N·m
Max torque speed: 1200-1600 / 1000-1400 / 1000-1300rpm
Rated speed: 2100 / 1900rpm
Engine Type: Inline 6-cylinder, water-cooled, 4-stroke, high-pressure common rail, turbocharged intercooled, EGR / Electronic high-pressure common rail + SCR / Inline, water-cooled, six-cylinder, electronically controlled high-pressure common rail SCR / Inline 6-cylinder, electronically controlled high-pressure common rail + SCR / Inline, water-cooled, six-cylinder, electronically controlled high-pressure common rail + SCR
Technology route: Common Rail SCR
Transmission Parameters
Transmission Brand: Fast Gear / Fast Gear with PTO
shift method: Manual
Forward gears: 10 / 12Gear
Cargo box parameters
hydraulic cylinder brand & model: Jiaheng 5-157*4450
Seal cover type: Electric sealed cover
Cargo box thickness: 8mm base, 5mm sides
Unloading Type: Rear-dump body / Dump type
FAQ
What kind of truck is Auman Auman Auman new ETX heavy truck Dump Trucks?
Auman Auman Auman new ETX heavy truck is an export-oriented Dump Trucks lineup with about 294 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Auman Auman new ETX heavy truck Dump Trucks?
Auman Auman new ETX heavy truck Dump Trucks export reference is about $22,319 – $58,875. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Auman Auman new ETX heavy truck Dump Trucks cover?
Auman Auman new ETX heavy truck Dump Trucks mainly covers: Drive: 8x4; Horsepower: 350 hp; Emission: China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Auman Auman new ETX heavy truck Dump Trucks?
For Auman Auman new ETX heavy truck Dump Trucks: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is Dump Trucks typically used for?
Dump Trucks is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does Auman Auman new ETX heavy truck Dump Trucks include?
Auman Auman new ETX heavy truck Dump Trucks currently lists about 294 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Auman Auman new ETX heavy truck Dump Trucks?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
