Jiangxi Isuzu 6WG1-TCG50 460hp 15.68L China V Diesel Engine
EXW
Export quote
Jiangxi Isuzu Isuzu 6-Cylinder Series engine
Main model photos
6 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Jiangxi Isuzu 6WG1-TCG50 460hp 15.68L China V Diesel Engine | 460hp / China V | ||
| Jiangxi Isuzu 6WG1-TC 430 hp 15.68L China III Diesel Engine | 430hp / China III / Euro III | ||
| Jiangxi Isuzu 6WA1-TC 360 hp 12L China III Diesel Engine | 360hp / China III / Euro III | ||
| Jiangxi Isuzu 6WF1D 390 hp 14.26L China III Diesel Engine | 390hp / China III / Euro III | ||
| Jiangxi Isuzu 6SD1-TC 270 hp 9.8L China III Diesel Engine | 270hp / China III / Euro III |
Jiangxi Isuzu 6WG1-TC 430 hp 15.68L China III Diesel Engine
EXW
Export quote
Jiangxi Isuzu 6WA1-TC 360 hp 12L China III Diesel Engine
EXW
Export quote
Jiangxi Isuzu 6WF1D 390 hp 14.26L China III Diesel Engine
EXW
Export quote
Jiangxi Isuzu 6SD1-TC 270 hp 9.8L China III Diesel Engine
EXW
Export quote
Series Specs
Engine parameters
Engine Series: 6-cylinder series
Engine manufacturer: Jiangxi Isuzu Motor Co., Ltd.
Suitable Range: Truck engine
Engine net weight: 1178kg
Engine Dimensions: 1693x1033x1159mm
Compression ratio: 17.5:1
Bore × Stroke: 147x154mm
Engine Brand: Jiangxi Isuzu
Engine Model: 6WG1-TCG50 / 6WG1-TC / 6WA1-TC / 6WF1D / 6SD1-TC / 6HH1
Number of cylinders: 6cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 15.681 / 15.68 / 12.07 / 14.256 / 9.84 / 8.23L
Emission standard: China V / China III / Euro III
Max output power: 338 / 316 / 265 / 287 / 199 / 136kW
Max hp: 460 / 430 / 360 / 390 / 270 / 185Horsepower
Max torque: 2256 / 2059 / 1422 / 1863 / 1000N·m
Max torque speed: 900-1300 / 1100 / 1300 / 1600rpm
Rated speed: 1800 / 1500rpm
Engine Type: High-pressure common rail / 4-stroke, water-cooled, direct injection with turbocharger and intercooler, diesel engine, overhead camshaft, common rail system / Inline direct injection / Diesel inline direct injection OHC
FAQ
What kind of truck is Jiangxi Isuzu Isuzu 6-Cylinder Series engine?
Jiangxi Isuzu Isuzu 6-Cylinder Series is an export-oriented engine lineup with about 6 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does Jiangxi Isuzu Isuzu 6-Cylinder Series engine cover?
Jiangxi Isuzu Isuzu 6-Cylinder Series engine mainly covers: Horsepower: 270 hp / 360 hp / 390 hp / 430 hp / 460 hp; Emission: China III / Euro III / China V; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Jiangxi Isuzu Isuzu 6-Cylinder Series engine?
For Jiangxi Isuzu Isuzu 6-Cylinder Series engine, choose in order: emission → drive → horsepower/fuel → compare price and photos → open a model to quote. Include port and quantity.
What is engine typically used for?
For engine, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does Jiangxi Isuzu Isuzu 6-Cylinder Series engine include?
Jiangxi Isuzu Isuzu 6-Cylinder Series engine currently lists about 6 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Jiangxi Isuzu Isuzu 6-Cylinder Series engine?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
