Sinotruk HOWOMAX 540hp 8X4(12 wheels) 9.2m AMT Automatic Refrigerated Truck (Hongye)
EXW
From $73,611
Export quote
Hongye Sinotruk HOWO chassis Refrigerated Truck
Main model photos
22 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Sinotruk HOWOMAX 540hp 8X4(12 wheels) 9.2m AMT Automatic Refrigerated Truck (Hongye) | 8x4 / 540hp / China VI | From $73,611 | |
| Sinotruk HOWOMAX 540hp 8X4(12 wheels) 9.4m AMT Automatic Refrigerated Truck (Hongye) | 8x4 / 540hp / China VI | From $73,611 | |
| Sinotruk HOWOMAX 350hp 6X2(8 wheels) 9.4m AMT Automatic Refrigerated Truck (Hongye) | 6x2 / 350hp / China VI | From $58,333 | |
| Sinotruk HOWO MAX 330hp 6X2(8 wheels) 9.4m AMT automatic refrigerated truck (Hongye) | 6x2 / 330hp / China VI | From $58,333 | |
| Sinotruk HOWO N5G 250hp 4X2(6 wheels) 6.2m refrigerated truck (Hongye) | 4x2 / 250hp / China VI | From $45,833 |
Sinotruk HOWOMAX 540hp 8X4(12 wheels) 9.4m AMT Automatic Refrigerated Truck (Hongye)
EXW
From $73,611
Export quote
Sinotruk HOWOMAX 350hp 6X2(8 wheels) 9.4m AMT Automatic Refrigerated Truck (Hongye)
EXW
From $58,333
Export quote
Sinotruk HOWO MAX 330hp 6X2(8 wheels) 9.4m AMT automatic refrigerated truck (Hongye)
EXW
From $58,333
Export quote
Sinotruk HOWO N5G 250hp 4X2(6 wheels) 6.2m refrigerated truck (Hongye)
EXW
From $45,833
Export quote
Series Specs
Basic Info
Cab dimensions: 12×2.6×4 / 8.6×2.6×3.96 / 9.2×2.6×3.96 / 12×2.6×3.96 / 8.6×2.6×4m
Drive type: 8X4 / 6X2 / 4X2
Truck Type: Refrigerated Truck
Wheelbase: 1950+4425+1400 / 1950+5450 / 4700 / 5100 / 1950+3800+1400 / 5000mm
Vehicle origin: Shenyang, Liaoning
Front track width: 2041/2041 / 1996/1996 / 1956 / 2022/2022 / 1950mm
rear track: 1860/1860 / 1830 / 1800 / 1848/1848 / 1848mm
Curb Weight: 14 / 11.5 / 8.3 / 7.7ton
Rated payload: 17.87 / 13.37 / 9.57 / 17.805 / 10.17ton
GVWR: 32 / 25 / 1.8ton
Max. speed: 89km/h
Front/rear suspension: 1.465/2.76 / 1.465/3.135 / 1.55/2.35 / 1.55/2.55 / 1.54/2.51 / 1.43/2.77m
Energy Type: Diesel
Engine parameters
Engine Model: SinotrukMC13H.54-61 / SinotrukMC07H.35-60 / SinotrukMC07H.33-60 / SinotrukMC07.25-60 / SinotrukMC07.27-60 / SinotrukMC11H.46-61
Number of cylinders: 6cylinder
Displacement: 13.02 / 7.36 / 6.87 / 11.05L
Emission standard: China VI
Max output power: 400 / 257 / 240 / 188 / 199 / 341kW
Max hp: 540 / 350 / 330 / 250 / 270 / 460Horsepower
Max torque: 1400 / 1060 / 2200N·m
Rated speed: 2200 / 1900rpm
Engine Type: Inline 6-cylinder, water-cooled, 4-stroke, turbocharged intercooled, high-pressure common rail / Inline, water-cooled, 4-stroke, turbocharged with intercooler
Cargo box parameters
Cargo box dimensions: 9.2×2.43×2.55 / 9.4×2.43×2.55 / 6.2×2.43×2.54 / 6.8×2.43×2.54 / 9.4×2.43×2.5m
Cargo box width: 2.43m
Cargo box height: 2.55 / 2.54 / 2.5m
Cargo box material: High-molecular eco-friendly material
Body Parameters
Vehicle certification code: MHY5320XLCZZM / MHY5250XLCZZM / MHY5180XLCZZN / MHY5320XLCZZT / MHY5180XLCZZT
refrigeration unit brand: Kaixue
Refrigeration unit: KX-1100
Body Brand: Hongye
Refrigeration temperature: -20°C
Others: Side: optional no door or single door; body: optional standard or meat-hook / Side: optional single door or no door; interior: optional standard or meat-hook device
Chassis Specs
Chassis Brand: SinotrukHOWO
Chassis Series: HOWOMAX / HOWON5G / HOWO TH7 / HOWO TX
Chassis Model: ZZ1327V446KF1K / ZZ1257N54CKF1 / ZZ1187K511JF1 / ZZ1327V466HF1K / ZZ1187K501GF1
Leaf spring count: 2/2/-/- / 3/3/4 / 7/7+3 / 4/4/-/- / 11/9+8
Transmission Parameters
Number of gears: 16 / 10Gear
Transmission Model: SinotrukHW16C / SinotrukHW10C
Tire
Tire Size: 11.00R20 18PR / 275/80R22.5 18PR / 315/80R22.5 18PR / 295/80R22.5 18PR
Number of tires: 12 / 8 / 6pcs
FAQ
What kind of truck is Hongye Hongye Sinotruk HOWO chassis Refrigerated Truck?
Hongye Hongye Sinotruk HOWO chassis is an export-oriented Refrigerated Truck lineup with about 12 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Hongye Sinotruk HOWO chassis Refrigerated Truck?
Hongye Sinotruk HOWO chassis Refrigerated Truck export reference is about $45,833 – $73,611. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Hongye Sinotruk HOWO chassis Refrigerated Truck cover?
Hongye Sinotruk HOWO chassis Refrigerated Truck mainly covers: Drive: 4x2 / 6x2 / 8x4; Horsepower: 250 hp / 330 hp / 350 hp / 540 hp; Emission: China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Hongye Sinotruk HOWO chassis Refrigerated Truck?
For Hongye Sinotruk HOWO chassis Refrigerated Truck: 1) set emission; 2) match body/wheelbase to cargo type; 3) pick drive and horsepower; 4) compare prices, then open a model to quote.
What is Refrigerated Truck typically used for?
Refrigerated Truck covers box, stake or flatbed cargo work from city delivery to regional haul. Filter by body and payload needs.
How many models does Hongye Sinotruk HOWO chassis Refrigerated Truck include?
Hongye Sinotruk HOWO chassis Refrigerated Truck currently lists about 12 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Hongye Sinotruk HOWO chassis Refrigerated Truck?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
