Dongfeng Commercial Vehicle Tianjin KR 4X2(6 wheels) Electric Sweeper Truck (Zhonglian Brand) (ZBH5180TXSEQABEV)
EXW
Export quote
ZOOMLION Dongfeng Commercial Vehicle chassis
Main model photos
73 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Dongfeng Commercial Vehicle Tianjin KR 4X2(6 wheels) Electric Sweeper Truck (Zhonglian Brand) (ZBH5180TXSEQABEV) | 4x2 | ||
| Dongfeng Commercial Vehicle Tianjin KR 230 hp 4X2(6 wheels) Sweeper Truck (Zoomlion Brand) (China VI) | 4x2 / 230hp / China VI |
Dongfeng Commercial Vehicle Tianjin KR 230 hp 4X2(6 wheels) Sweeper Truck (Zoomlion Brand) (China VI)
EXW
Export quote
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Dongfeng Commercial Vehicle Tianjin 180hp 4X2(6 wheels) Sweeper Truck (Zoomlion) | 4x2 / 180hp / China III / Euro III | ||
| Dongfeng Commercial Vehicle Tianjin 185hp 4X2(6 wheels) Sweeper Truck (Zoomlion) | 4x2 / 185hp / China III / Euro III | ||
| Dongfeng Commercial Vehicle Tianjin 210hp 4X2(6 wheels) Sweeper Truck (Zoomlion) | 4x2 / 210hp / China IV | ||
| Dongfeng Commercial Vehicle Tianjin 185hp 4X2(6 wheels) Sweeper Truck (Zoomlion) | 4x2 / 185hp / China III / Euro III | ||
| Dongfeng Commercial Vehicle Tianjin 180hp 4X2(6 wheels) Sweeper Truck (Zoomlion) | 4x2 / 180hp / China III / Euro III |
Dongfeng Commercial Vehicle Tianjin 180hp 4X2(6 wheels) Sweeper Truck (Zoomlion)
EXW
Export quote
Dongfeng Commercial Vehicle Tianjin 185hp 4X2(6 wheels) Sweeper Truck (Zoomlion)
EXW
Export quote
Dongfeng Commercial Vehicle Tianjin 210hp 4X2(6 wheels) Sweeper Truck (Zoomlion)
EXW
Export quote
Dongfeng Commercial Vehicle Tianjin 185hp 4X2(6 wheels) Sweeper Truck (Zoomlion)
EXW
Export quote
Dongfeng Commercial Vehicle Tianjin 180hp 4X2(6 wheels) Sweeper Truck (Zoomlion)
EXW
Export quote
Series Specs
Basic Info
Cab dimensions: 8.92×2.5×3.15 / 8.92×2.49×3.05 / 7.875×2.470×2.92 / 8.586×2.49×2.98 / 7.875×2.47×2.92 / 8.2×2.475×3.2 / 7.86×2.47×3.19m
Type: electric sweeper truck (main) / Washing and sweeping truck / sweeper truck
Drive type: 4X2
Wheelbase: 4500 / 5000mm
Front/rear track width: Front: 1880mm; Rear: 1860 / Front: 1876mm; Rear: 1860 / Front track: 1880, Rear track: 1800 / 1880/1800 / Front track: 1880mm; Rear track: 1860mm / 1800/1800
Rated mass: 4.105 / 5.405 / 6.145 / 4.155 / 3.945 / 5.165ton
GVWR: 18 / 16ton
Front/rear suspension: 1.43/2.22 / 1.4/2.22 / 1.43/1.945 / 1.4/2.156 / 1.43/2.27 / 1.43/1.93m
Energy Type: Diesel
Body Parameters
Other special notes: Optional alternative garbage bin and air pre-filter / This vehicle is a domestic pioneer combining washing and sweeping functions into one cleaning vehicle, water tank capacity 9m³, / Water tank capacity 3000L, max sweeping width 3.5m / Water tank capacity 2000L, max cleaning width 5m / Water tank capacity 1400L, max cleaning width 3.5m, optional new-style garbage bin. Side guard and rear underrun guard material Q235, bolted to vehicle; rear underrun guard section 60mm×240mm, max ground clearance 310mm with standard bin, 450mm with new-style bin
Vehicle certification code: ZBH5180TXSEQABEV / ZBH5181TXSDFE6 / ZLJ5163TSLE3 / ZLJ5160TXSE3 / ZLJ5163TSLE4 / ZLJ5160TSLE3 / ZLJ5164TSLE3
Body Brand: ZOOMLION
Engine parameters
Engine Model: DongfengB6.2NS6B230 / Dongfeng ISDe18030 / Dongfeng ISBE18530 / Dongfeng ISDe21040
Displacement: 6.2 / 4.5 / 6.7L
Emission standard: China VI / China III / Euro III / China IV
Max output power: 169 / 132 / 136 / 155kW
Max hp: 230 / 180 / 185 / 210Horsepower
Rated speed: 2300 / 2500rpm
Cargo box parameters
Box volume: 8 / 7 / 5 / 6m³
Chassis Specs
Chassis Brand: Dongfeng Commercial Vehicle
Chassis Series: Tianjin KR / Dongfeng Tianjin
Chassis Model: EQ1180GEVJ1 / DFH1180EX8 / DFL1160BX2 / DFL1160BX / DFL1160BX4
Leaf spring count: 8/10+8 / 7/9+6 / 7/9+6,8/10+8 / 8/10+8,7/9+6
Transmission Parameters
Number of gears: 6Gear
Transmission Model: 6-speed transmission
Cab parameters
Cab: Tianjin KR
Tire
Tire Size: 295/80R22.5 18PR / 275/80R22.5 18PR / 9.00-20 / 9.00-20,9.00R20，10.00-20,10.00R20 / 9
Number of tires: 6pcs
FAQ
What kind of truck is ZOOMLION ZOOMLION Dongfeng Commercial Vehicle chassis sweeper truck?
ZOOMLION ZOOMLION Dongfeng Commercial Vehicle chassis is an export-oriented sweeper truck lineup with about 7 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does ZOOMLION Dongfeng Commercial Vehicle chassis cover?
ZOOMLION Dongfeng Commercial Vehicle chassis mainly covers: Drive: 4x2; Horsepower: 180 hp / 185 hp / 210 hp / 230 hp; Emission: China III / Euro III / China IV / China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in ZOOMLION Dongfeng Commercial Vehicle chassis?
For ZOOMLION Dongfeng Commercial Vehicle chassis: define the job and emission first, compare key drive/power options, then open the matching model for special equipment and quote.
What is sweeper truck typically used for?
sweeper truck specs vary widely by job. Define the application first, then compare specs here and request a quote.
How many models does ZOOMLION Dongfeng Commercial Vehicle chassis include?
ZOOMLION Dongfeng Commercial Vehicle chassis currently lists about 7 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for ZOOMLION Dongfeng Commercial Vehicle chassis?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
