Quanchai H25-172E60 172hp 2.5L China VI diesel engine
EXW
Export quote
Quanchai H Series engine
Main model photos
6 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Quanchai H25-172E60 172hp 2.5L China VI diesel engine | 172hp / China VI | ||
| Quanchai H25-165E60 165 hp 2.5L China VI Diesel Engine | 165hp / China VI | ||
| Quanchai H33-180E60 180hp 3.3L China VI Diesel Engine | 180hp / China VI | ||
| Quanchai H20 Series 130hp 2L China VI Diesel Engine | 130hp / China VI | ||
| Quanchai H30-165E60 165 hp 3L China VI diesel engine | 165hp / China VI |
Quanchai H25-165E60 165 hp 2.5L China VI Diesel Engine
EXW
Export quote
Quanchai H33-180E60 180hp 3.3L China VI Diesel Engine
EXW
Export quote
Quanchai H20 Series 130hp 2L China VI Diesel Engine
EXW
Export quote
Quanchai H30-165E60 165 hp 3L China VI diesel engine
EXW
Export quote
Series Specs
Engine parameters
Engine Series: Quanchai H Series
Engine manufacturer: Anhui Quanchai Power Co., Ltd.
Suitable Range: light truck, pickup, SUV / light truck, bus, tractor, harvester
Intake type: Turbocharged Air-to-Air Intercooling
Min. fuel consumption at full load: ≤200 / ≤202g/kW.h
Engine net weight: 320 / 220kg
Compression ratio: (17.5±0.5):1
noise at 1m: ≤93 / ≤94.7dB
Bore × Stroke: 94×108 / 81×95.5mm
Valves per cylinder: 4pcs
Engine Brand: Quanchai
Engine Model: H25-172E60 / H25-165E60 / H33-180E60 / H20-130E60 / H30-165E60 / H30 Series 75 hp / H20 Series 150 hp / H20 Series 82 hp / H20-120E60
Number of cylinders: 4cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 2.496 / 3.3 / 2 / 3L
Emission standard: China VI
Max output power: 126 / 120 / 130 / 93 / 55 / 110 / 60 / 90kW
Max hp: 172 / 165 / 180 / 130 / 75 / 150 / 82 / 120Horsepower
Max torque: 460 / 400 / 500 / 350 / 325N·m
Max torque speed: 2000rpm
Rated speed: 3000 / 2800 / 3200rpm
Engine Type: Inline 4-cylinder, water-cooled, 4-stroke, turbocharged with intercooler, high-pressure common rail / Bosch common rail / High-pressure common rail
FAQ
What kind of truck is Quanchai Quanchai H Series engine?
Quanchai Quanchai H Series is an export-oriented engine lineup with about 9 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does Quanchai H Series engine cover?
Quanchai H Series engine mainly covers: Horsepower: 130 hp / 165 hp / 172 hp / 180 hp; Emission: China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Quanchai H Series engine?
For Quanchai H Series engine, choose in order: emission → drive → horsepower/fuel → compare price and photos → open a model to quote. Include port and quantity.
What is engine typically used for?
For engine, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does Quanchai H Series engine include?
Quanchai H Series engine currently lists about 9 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Quanchai H Series engine?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
