Dongfeng F5 200 hp 4X2(6 wheels) Green Spraying Truck (China VI)
EXW
Export quote
Dongfeng F5 heavy truck water sprinkler truck
Main model photos
61 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Dongfeng F5 200 hp 4X2(6 wheels) Green Spraying Truck (China VI) | 4x2 / 200hp / China VI | ||
| Dongfeng F5 200 hp 4X2(6 wheels) Green Spraying Truck (China VI) | 4x2 / 200hp / China VI | ||
| Dongfeng F5 230 hp 4X2(6 wheels) Green Spraying Truck (China VI) | 4x2 / 230hp / China VI | ||
| Dongfeng F5 200 hp 4X2(6 wheels) Water Sprinkler Truck (China VI) | 4x2 / 200hp / China VI | ||
| Dongfeng F5 200 hp 4X2(6 wheels) Water Sprinkler Truck (China VI) | 4x2 / 200hp / China VI |
Dongfeng F5 200 hp 4X2(6 wheels) Green Spraying Truck (China VI)
EXW
Export quote
Dongfeng F5 230 hp 4X2(6 wheels) Green Spraying Truck (China VI)
EXW
Export quote
Dongfeng F5 200 hp 4X2(6 wheels) Water Sprinkler Truck (China VI)
EXW
Export quote
Dongfeng F5 200 hp 4X2(6 wheels) Water Sprinkler Truck (China VI)
EXW
Export quote
Series Specs
Basic Info
Cab dimensions: 8.35×2.5×3.15 / 8.5×2.5×3.2 / 8.45×2.25×2.96 / 7.49×2.5×3.3 / 7.43×2.25×2.86m
Truck Type: landscaping sprinkler truck / Water Sprinkler Truck
Drive type: 4X2
Wheelbase: 4500 / 3950mm
Vehicle origin: Shiyan, Hubei / Shenzhen, Guangdong
Front track width: 1950 / 1820mm
rear track: 1820 / 1800mm
Curb Weight: 6.78 / 7.32 / 7.28 / 6.18 / 6.17ton
Rated payload: 11.09 / 10.55 / 10.525 / 9.625 / 9.635ton
Max. speed: 88km/h
Front/rear suspension: 1.25/2.6 / 1.25/2.75 / 1.41/2.54 / 1.25/2.29 / 1.31/2.17m
Energy Type: Diesel
Engine parameters
Engine Model: YuchaiYCS06200-60 / YuchaiYCS04200-68 / DongfengB6.2NS6B230 / YuchaiYCY30170-60 / YuchaiYCY30165-60 / Yunnei PowerD30TCIF1
Number of cylinders: 6 / 4cylinder
Displacement: 6.23 / 4.16 / 6.2 / 2.97 / 3L
Emission standard: China VI
Max output power: 147 / 169 / 125 / 121kW
Max hp: 200 / 230 / 170 / 165Horsepower
Rated speed: 2300 / 2800rpm
Engine Type: High-pressure common rail + EGR + DOC + DPF + SCR + ASC / Electronic control common rail system HEGR + DOC + DPF + SCR + ASC
Cargo box parameters
Box volume: 12.18 / 11.58 / 11.18 / 10.1m³
Body Parameters
Vehicle certification code: EQ5180GPSL6D / EQ5180GSSL6D / EQ5181GPSSEH6 / EQ5160GSSL6D / EQ5160GSSSEH6
Body Brand: Dongfeng
Chassis Specs
Chassis Brand: Dongfeng
Chassis Series: Huashen F5
Chassis Model: EQ1180GL6DJ / EQ1160GL6DJ
Front axle description: 5T / 3.6T / 2.7T
Frame Dimensions: 250 (7+4) locally reinforced / 250(7+4) / 250mm / 250×7
rear axle description: 9T / 10T / 7.65T
Leaf spring count: 9/11+8
Transmission Parameters
Number of gears: 8Gear
Transmission Model: Fast Gear 8-speed
Cab parameters
Cab: D913E-3 / D913E
Tire
Tire Size: 10.00R20 18PR / 9.00R20 16PR
Number of tires: 6pcs
FAQ
What kind of truck is Dongfeng Dongfeng F5 heavy truck water sprinkler truck?
Dongfeng Dongfeng F5 heavy truck is an export-oriented water sprinkler truck lineup with about 19 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does Dongfeng F5 heavy truck water sprinkler truck cover?
Dongfeng F5 heavy truck water sprinkler truck mainly covers: Drive: 4x2; Horsepower: 200 hp / 230 hp; Emission: China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Dongfeng F5 heavy truck water sprinkler truck?
For Dongfeng F5 heavy truck water sprinkler truck: define the job and emission first, compare key drive/power options, then open the matching model for special equipment and quote.
What is water sprinkler truck typically used for?
water sprinkler truck specs vary widely by job. Define the application first, then compare specs here and request a quote.
How many models does Dongfeng F5 heavy truck water sprinkler truck include?
Dongfeng F5 heavy truck water sprinkler truck currently lists about 19 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Dongfeng F5 heavy truck water sprinkler truck?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
