SHACMAN Commercial Vehicle Xuande X9 184hp 4X2(6 wheels) Green Sprinkler Truck
EXW
From $20,889
Export quote
SHACMAN Commercial Vehicle SHACMAN Xuande X9 Light
Main model photos
391 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| SHACMAN Commercial Vehicle Xuande X9 184hp 4X2(6 wheels) Green Sprinkler Truck | 4x2 / 184hp / China VI | From $20,889 | |
| SHACMAN Commercial Vehicle Xuande X9 130 hp 4X2(6 wheels) Green Spraying Truck | 4x2 / 130hp / China V | From $16,014 | |
| SHACMAN Commercial Vehicle Xuande X9 130 hp 4X2(6 wheels) Green Spraying Truck | 4x2 / 130hp / China V | From $16,278 |
SHACMAN Commercial Vehicle Xuande X9 130 hp 4X2(6 wheels) Green Spraying Truck
EXW
From $16,014
Export quote
SHACMAN Commercial Vehicle Xuande X9 130 hp 4X2(6 wheels) Green Spraying Truck
EXW
From $16,278
Export quote
Series Specs
Basic Info
Cab dimensions: 7.6×2.44×3.1 / 6.8×2.22×2.6 / 6.6×2.15×2.36m
Drive type: 4X2
Truck Type: landscaping sprinkler truck
Vehicle origin: Baoji, Shaanxi
Wheelbase: 4100 / 3800mm
Front track width: 1770 / 1670 / 1830mm
rear track: 1700 / 1650 / 1810mm
Curb Weight: 6.4 / 5.4 / 3.89ton
Rated payload: 9.405 / 7.905 / 4.195ton
Max. speed: 89 / 85 / 90km/h
Front/rear suspension: 1.3/2.2 / 1.2/1.8 / 1.2/1.6m
Energy Type: Diesel
Body Parameters
Tank Dimensions (L×W×H): 4.2×2.35×1.45 / 4×2×1.35 / 3.4×1.7×1.1m
Vehicle certification code: SX5160GPSGP6411 / SX5140GPSGP5381 / SX5080GPSGP5
Body Brand: SHACMAN Commercial Vehicle
Others: Standard: TJG131 cab, reserved A/C interface, regulatory Tianxingjian; cab color: pearl white; transmission reserved PTO interface, brakes: domestic 4-channel ABS, spring brake. Optional: A/C, power windows.
Engine parameters
Engine Model: Yunnei PowerD40TCIF1 / WeichaiWP3Q130E50 / WeichaiWP3.7Q130E50
Number of cylinders: 4cylinder
Displacement: 4 / 2.97 / 3.66L
Emission standard: China VI / China V
Max output power: 135 / 96kW
Max hp: 184 / 130Horsepower
Rated speed: 2300 / 3000 / 2900rpm
Engine Type: Electronic control common rail system HEGR + DOC + DPF + SCR + ASC / Inline, water-cooled, 4-stroke, turbocharged with intercooler / Common Rail+SCR
Cargo box parameters
Box volume: 9.8 / 8 / 4.3m³
Chassis Specs
Chassis Brand: SHACMAN Commercial Vehicle
Chassis Series: Xuande X9
Chassis Model: SX1160GP6411 / SX1140GP5381 / SX1080GP5
Front axle description: 145/3.2T / 1068
Frame Dimensions: 800x232/6 single-layer / 800×192~132/6+4 double-layermm
rear axle description: 145/8T / 1080 / 1068
Axle ratio: 5.286 / 6.83 / 4.875
Leaf spring count: 9/11+5,9/11+8 / 7/10+3,7/9+7,9/11+8
Transmission Parameters
Number of gears: 8 / 6Gear
Transmission Model: Fast Gear8JS75TA / WLYWLY6TS40 / WLYWLY6T50
Cab parameters
Cab: TJG131 single row
Tire
Tire Size: 9.00R20 / 8.25R20/16RP / 7.50R16/14RP
Number of tires: 6pcs
FAQ
What kind of truck is SHACMAN Commercial Vehicle SHACMAN Xuande X9 Light Truck water sprinkler truck?
SHACMAN Commercial Vehicle SHACMAN Xuande X9 Light Truck is an export-oriented water sprinkler truck lineup with about 3 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for SHACMAN Commercial Vehicle SHACMAN Xuande X9 Light?
SHACMAN Commercial Vehicle SHACMAN Xuande X9 Light export reference is about $16,014 – $20,889. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does SHACMAN Commercial Vehicle SHACMAN Xuande X9 Light cover?
SHACMAN Commercial Vehicle SHACMAN Xuande X9 Light mainly covers: Drive: 4x2; Horsepower: 130 hp / 184 hp; Emission: China V / China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in SHACMAN Commercial Vehicle SHACMAN Xuande X9 Light?
For SHACMAN Commercial Vehicle SHACMAN Xuande X9 Light: define the job and emission first, compare key drive/power options, then open the matching model for special equipment and quote.
What is water sprinkler truck typically used for?
water sprinkler truck specs vary widely by job. Define the application first, then compare specs here and request a quote.
How many models does SHACMAN Commercial Vehicle SHACMAN Xuande X9 Light include?
SHACMAN Commercial Vehicle SHACMAN Xuande X9 Light currently lists about 3 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for SHACMAN Commercial Vehicle SHACMAN Xuande X9 Light?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
