Q23A-143C60
EXW
Export quote
Quanchai Q Series engine
Main model photos
4 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Q23A-143C60 | 140hp / China VI | ||
| Q23A-110E60 | 110hp / China VI | ||
| Q23A-130C60 | 122hp / China VI | ||
| Q23A-130E60 | 130hp / China VI | ||
| Q23A-100C60 | 100hp / China VI |
Q23A-110E60
EXW
Export quote
Q23A-130C60
EXW
Export quote
Q23A-130E60
EXW
Export quote
Q23A-100C60
EXW
Export quote
Series Specs
Engine parameters
Engine Series: Quanchai Q Series
Engine manufacturer: Anhui Quanchai Power Co., Ltd.
Suitable Range: Light truck, heavy truck, medium-heavy truck
Intake type: Turbocharged Air-to-Air Intercooling
Min. fuel consumption at full load: ≤205g/kW.h
Engine net weight: 260 / 280kg
Compression ratio: (17.5±0.5):1
noise at 1m: ≤95 / ≤96dB
Bore × Stroke: 87×97 / 94×102mm
Valves per cylinder: 2pcs
Engine Brand: Quanchai
Engine Model: Q23A-143C60 / Q23A-110E60 / Q23A-130C60 / Q23A-130E60 / Q23A-100C60 / Q23A-143E60 / Q25A-150C60 / Q25-152E60A / Q23A-100E60 / Q25D-160E60 / Q23D-142E60 / Q25A-162E60 / Q25A-150E60 / Q23A-142E60 / Q25A-160E60 / Q25N-152E60 / Q23A-82E60 / Q23A-95E60 / Q28-156E60 / Q23-110E60 / Q25-152E60 / Q28-152E60 / Q23-136E60 / Q23-95C60 / Q23-132E60 / Q23-115C60 / Q23-95E60 / Q28-130C60 / Q23-115E60 / Q28-130E60
Number of cylinders: 4cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 2.3 / 2.496 / 2.493 / 2.8 / 2.5L
Emission standard: China VI
Max output power: 103 / 80 / 90 / 96 / 73 / 110 / 112 / 116 / 60 / 70 / 115 / 83 / 100 / 97 / 85kW
Max hp: 140 / 110 / 122 / 130 / 100 / 143 / 150 / 152 / 160 / 142 / 162 / 82 / 95 / 156 / 136 / 132 / 115Horsepower
Max torque: 350 / 330 / 440 / 450 / 400 / 380 / 320 / 240 / 395 / 405N·m
Max torque speed: 1400-2400 / 3000 / 1400 / 1600-2000 / 1200-3000 / 1400-2600 / 2000rpm
Rated speed: 3300 / 3000rpm
Engine Type: Inline 4-cylinder, water-cooled, 4-stroke, turbocharged with intercooler, high-pressure common rail / Common Rail
FAQ
What kind of truck is Quanchai Quanchai Q Series engine?
Quanchai Quanchai Q Series is an export-oriented engine lineup with about 30 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does Quanchai Q Series engine cover?
Quanchai Q Series engine mainly covers: Horsepower: 100 hp / 110 hp / 122 hp / 130 hp / 140 hp; Emission: China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Quanchai Q Series engine?
For Quanchai Q Series engine, choose in order: emission → drive → horsepower/fuel → compare price and photos → open a model to quote. Include port and quantity.
What is engine typically used for?
For engine, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does Quanchai Q Series engine include?
Quanchai Q Series engine currently lists about 30 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Quanchai Q Series engine?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
