Chaochai CYQD80-E3 110 hp 3L China III Diesel Engine
EXW
Export quote
Chaochai CYQD Series engine
Main model photos
5 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Chaochai CYQD80-E3 110 hp 3L China III Diesel Engine | 110hp / China III / Euro III | ||
| Chaochai CYQD80D-E3 110 hp 3L China III Diesel Engine | 110hp / China III / Euro III | ||
| Chaochai CYQD80-E4 110 hp 3.15L China IV Diesel Engine | 110hp / China IV | ||
| Chaochai CYQD32Tic 138 hp 3.15L China III Diesel Engine | 138hp / China III / Euro III | ||
| Chaochai CYQD32T 110 hp 3.15L China II Diesel Engine | 110hp / China II/Euro II |
Chaochai CYQD80D-E3 110 hp 3L China III Diesel Engine
EXW
Export quote
Chaochai CYQD80-E4 110 hp 3.15L China IV Diesel Engine
EXW
Export quote
Chaochai CYQD32Tic 138 hp 3.15L China III Diesel Engine
EXW
Export quote
Chaochai CYQD32T 110 hp 3.15L China II Diesel Engine
EXW
Export quote
Series Specs
Engine parameters
Engine Series: CYQD Series
Engine manufacturer: Dongfeng Chaoyang Chaochai Power Co., Ltd.
Suitable Range: Mid-to-high-end light truck, SUV, pickup, off-road vehicle / Diesel power best suited for large off-road vehicles / This product is suitable for various light trucks, SUVs, pickup trucks, light passenger vehicles, MPVs, etc.
Intake type: Inline / Turbocharged Air-to-Air Intercooling / Turbocharged / Naturally aspirated
Min. fuel consumption at full load: ≤215 / 225 / 230 / 233.9g/kW.h
Engine net weight: 275 / 272 / 260 / 258kg
Engine Dimensions: 726x630x741 / 721×701×665 / 721×701×715 / 721×597×677mm
noise at 1m: 93.4 / 93dB
Compression ratio: 22∶1 / 22：1
Bore × Stroke: 99.2x102mm
Valves per cylinder: 2pcs
firing order: 1-3-4-2
Engine Brand: Chaochai
Engine Model: CYQD80-E3 / CYQD80D-E3 / CYQD80-E4 / Warrior Heart III-CYQD32Tic / Fengying Heart-CYQD32T / Warrior Heart-CYQD32Ti / CYQD32（EGR） / CYQD32
Number of cylinders: 4cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 2.954 / 2.951 / 3.153L
Emission standard: China III / Euro III / China IV / China II/Euro II
Max output power: 80.9 / 101.5 / 75.8kW
Max hp: 110 / 138 / 103Horsepower
Max torque: 221 / 313 / 216N·m
Max torque speed: 2200-2600 / 2000 / 2200rpm
Rated speed: 3600rpm
Engine Type: Vertical, inline, water-cooled, four-stroke / Vertical in-line, water-cooled, 4-stroke, turbocharged & intercooled, electronic VE pump, dual-stage DOC / Vertical inline, water-cooled, four-stroke, turbocharged intercooled / Vertical inline, four-stroke, turbocharged / Vertical inline, 4-stroke, turbocharged intercooled / Vertical inline, swirl combustion chamber, EGR / Vertical inline, swirl combustion chamber
FAQ
What kind of truck is Chaochai Chaochai CYQD Series engine?
Chaochai Chaochai CYQD Series is an export-oriented engine lineup with about 8 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does Chaochai CYQD Series engine cover?
Chaochai CYQD Series engine mainly covers: Horsepower: 110 hp / 138 hp; Emission: China II/Euro II / China III / Euro III / China IV; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Chaochai CYQD Series engine?
For Chaochai CYQD Series engine, choose in order: emission → drive → horsepower/fuel → compare price and photos → open a model to quote. Include port and quantity.
What is engine typically used for?
For engine, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does Chaochai CYQD Series engine include?
Chaochai CYQD Series engine currently lists about 8 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Chaochai CYQD Series engine?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
