Dachai CA6DK1-28E61 280hp 7.2L China VI Diesel Engine
EXW
Export quote
Dachai CA6DK1 Series engine
Main model photos
11 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Dachai CA6DK1-28E61 280hp 7.2L China VI Diesel Engine | 280hp / China VI | ||
| Dachai CA6DK1-26E61 260hp 7.2L China VI Diesel Engine | 260hp / China VI | ||
| Dachai CA6DK1-32E61 320 hp 7.2L China VI Diesel Engine | 320hp / China VI | ||
| Dachai CA6DK1-32E51 320hp 7.2L China V Diesel Engine | 320hp / China V | ||
| Dachai CA6DK1-26E51 260 hp 7.15L China V Diesel Engine | 260hp / China V |
Dachai CA6DK1-26E61 260hp 7.2L China VI Diesel Engine
EXW
Export quote
Dachai CA6DK1-32E61 320 hp 7.2L China VI Diesel Engine
EXW
Export quote
Dachai CA6DK1-32E51 320hp 7.2L China V Diesel Engine
EXW
Export quote
Dachai CA6DK1-26E51 260 hp 7.15L China V Diesel Engine
EXW
Export quote
Series Specs
Engine parameters
Engine Series: CA6DK1 Series
Engine manufacturer: FAW Group Corporation / Dachai
Suitable Range: Heavy-duty cargo trucks over 20 tons, tractor trucks, dump trucks / 12–25m high-grade highways, tourism and large city buses, heavy-duty cargo trucks over 30 tons, 10–12m³ concrete mixer trucks, loaders over 50
Intake type: Turbocharged Air-to-Air Intercooling / Air-to-air intercooled
Min. fuel consumption at full load: 190 / ≤190g/kW.h
Engine net weight: 623 / 650 / 1050kg
Engine Dimensions: 1280×805×974 / 1291×717×966 / 1365×775×1180 / 1365×775×118mm
noise at 1m: ≤92.5 / ≤91 / 96dB
Bore × Stroke: 108×130 / 123×155mm
Valves per cylinder: 4pcs
Engine Brand: Dachai
Engine Model: CA6DK1-28E61 / CA6DK1-26E61 / CA6DK1-32E61 / CA6DK1-32E51 / CA6DK1-26E51 / CA6DK1-32E6 / CA6DK1-31E6 / CA6DK1-28E6 / CA6DK1-26E6 / CA6DK1-32E5 / CA6DK1-28E5 / CA6DK1-26E5 / CA6DK1-24E5 / CA6DK1-28E51 / CA6DK1-26E4 / CA6DK1-28E4
Number of cylinders: 6cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 7.2 / 7.146L
Emission standard: China VI / China V / China IV
Max output power: 209 / 195 / 239 / 235 / 228 / 206 / 192 / 180kW
Max hp: 280 / 260 / 320 / 310 / 240Horsepower
Max torque: 1300 / 1000 / 1200 / 1180 / 1100 / 1050N·m
Max torque speed: 1200-1500 / 1200-1800 / 1200-1700 / 1100-1400rpm
Rated speed: 2300 / 1900rpm
Engine Type: EGR+DOC+DPF+SCR / 6-cylinder inline, direct injection, turbocharged intercooled, electronic common rail / High-pressure common rail + EGR + DOC + DPF + SCR + ASC / Common Rail+SCR / 6-cylinder inline, 4-valve, direct injection, electronic common rail
FAQ
What kind of truck is Dachai Dachai CA6DK1 Series engine?
Dachai Dachai CA6DK1 Series is an export-oriented engine lineup with about 16 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does Dachai CA6DK1 Series engine cover?
Dachai CA6DK1 Series engine mainly covers: Horsepower: 260 hp / 280 hp / 320 hp; Emission: China V / China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Dachai CA6DK1 Series engine?
For Dachai CA6DK1 Series engine, choose in order: emission → drive → horsepower/fuel → compare price and photos → open a model to quote. Include port and quantity.
What is engine typically used for?
For engine, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does Dachai CA6DK1 Series engine include?
Dachai CA6DK1 Series engine currently lists about 16 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Dachai CA6DK1 Series engine?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
