Dongfeng Special Chassis Series 170 hp 4X2(6 wheels) Water Sprinkler Truck (Dali Brand)
EXW
From $22,639
Export quote
Dali Dongfeng chassis water sprinkler truck
Main model photos
49 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Dongfeng Special Chassis Series 170 hp 4X2(6 wheels) Water Sprinkler Truck (Dali Brand) | 4x2 / 170hp / China V | From $22,639 | |
| Dongfeng Special Series 210hp 4X2(6 wheels) Water Sprinkler Truck (Dali Brand) | 4x2 / 210hp / China V | From $25,417 | |
| Dongfeng Special Series 180hp 4X2(6 wheels) Water Sprinkler Truck (Dali Brand) | 4x2 / 180hp / China V | From $24,167 | |
| Dongfeng Special Chassis Series 190 hp 4X2(6 wheels) Water Sprinkler Truck (Dali Brand) | 4x2 / 190hp / China V | From $23,472 | |
| Dongfeng Special Chassis Series 160 hp 4X2(6 wheels) Water Sprinkler Truck (Dali Brand) | 4x2 / 160hp / China V | From $18,611 |
Dongfeng Special Series 210hp 4X2(6 wheels) Water Sprinkler Truck (Dali Brand)
EXW
From $25,417
Export quote
Dongfeng Special Series 180hp 4X2(6 wheels) Water Sprinkler Truck (Dali Brand)
EXW
From $24,167
Export quote
Dongfeng Special Chassis Series 190 hp 4X2(6 wheels) Water Sprinkler Truck (Dali Brand)
EXW
From $23,472
Export quote
Dongfeng Special Chassis Series 160 hp 4X2(6 wheels) Water Sprinkler Truck (Dali Brand)
EXW
From $18,611
Export quote
Series Specs
Basic Info
Cab dimensions: 7.83×2.5×3.2 / 8.35×2.5×3.15 / 8.3×2.5×3.2 / 7.75×2.5×3.2 / 8.6×2.5×3.15 / 8.25×2.48×3.15 / 7.7×2.48×3.15 / 8.2×2.48×3.18 / 7.7×2.48×3.18m
Truck Type: Water Sprinkler Truck / landscaping sprinkler truck
Drive type: 4X2
Wheelbase: 4700 / 4500 / 3950mm
Vehicle origin: Suizhou, Hubei
Front track width: 1810 / 1900 / 1940mm
rear track: 1800 / 1860mm
Curb Weight: 5.8 / 7.328 / 6.405 / 5.605 / 6.125ton
Rated payload: 9.805 / 10.477 / 9.2 / 10 / 9.68ton
Max. speed: 90km/h
Front/rear suspension: 1.25/2.08 / 1.45/2.43 / 1.25/2.6 / 1.44/2.36 / 1.45/2.4 / 1.25/2.5 / 1.45/2.25m
Energy Type: Diesel
Body Parameters
Tank Dimensions (L×W×H): 4.3×2.3×1.5 / 5×2.3×1.62 / 4.7×2.24×1.3 / 5×2.11×1.2 / 4.2×2.2×1.5 / 5×2.4×1.46 / 4.4×2.2×1.5m
Vehicle certification code: DLQ5160GSSSD5 / DLQ5183GPSLV5 / DLQ5160GSSZK5 / DLQ5182GPSL5 / DLQ5161GSSL5 / DLQ5161GPSL5
Body Brand: Dali Brand
Engine parameters
Engine Model: DongfengISB170 50 / DongfengISB210 50 / YuchaiYC6JA180-50 / DongfengISB190 50 / YuchaiYC4E160-56 / YuchaiYC4FA130-50 / YuchaiYC4S150-50 / WeichaiWP4.1Q165E50
Number of cylinders: 6 / 4cylinder
Displacement: 5.9 / 6.87 / 4.26 / 2.982 / 3.767 / 4.088L
Emission standard: China V
Max output power: 125 / 155 / 132 / 140 / 118 / 95 / 110 / 120kW
Max hp: 170 / 210 / 180 / 190 / 160 / 130 / 150 / 165Horsepower
Rated speed: 2500 / 2300 / 2600 / 3200rpm
Engine Type: SCR / Vertical, inline, water-cooled, four-stroke / High-pressure common rail + SCR
Cargo box parameters
Box volume: 10.29 / 11 / 9.66 / 10.5 / 10.16m³
Chassis Specs
Chassis Brand: Dongfeng
Chassis Series: Dongfeng Special Chassis / Dongfeng Jincheng
Chassis Model: EQ1160GD5DJ1 / EQ1180GD5DJ1 / EQ1160GD5DJ / EQ1180GSZ5DJ / EQ1160GZ5DJ
rear axle description: 9T / 10T / 7.6T / 8T
Leaf spring count: 8/9+7,8/10+7,3/4+3 / 8/9+7,8/10+7,3/4+3,9/12+10,8/10+8,7/9+6,11/11+10,9/10+8 / 9/12+10,8/10+7,8/10+8,7/9+6,11/11+10,9/10+8 / 9/11+9,8/10+8 / 9/10+8,8/10+7
Transmission Parameters
Number of gears: 8 / 6Gear
Transmission Model: Fast Gear 8-speed / Changtai 8-speed / Fast Gear small 8-speed / Dachi 6-speed
Tire
Tire Size: 10.00R20 16PR / 9.00-20 16PR / 10.00-20 18PR,10.00R20 18PR,11.00-20 16PR,11.00R20 18PR,295/80R22.5 18PR,315/80R22.5 16PR / 10.00R20 18PR / 10.00R20 / 10.00R20 16PR,10.00R20 18PR / 9.00R20 16PR
Number of tires: 6pcs
FAQ
What kind of truck is Dali Dali Dongfeng chassis water sprinkler truck?
Dali Dali Dongfeng chassis is an export-oriented water sprinkler truck lineup with about 30 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Dali Dongfeng chassis water sprinkler truck?
Dali Dongfeng chassis water sprinkler truck export reference is about $17,917 – $25,417. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Dali Dongfeng chassis water sprinkler truck cover?
Dali Dongfeng chassis water sprinkler truck mainly covers: Drive: 4x2; Horsepower: 160 hp / 170 hp / 180 hp / 190 hp / 210 hp; Emission: China V; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Dali Dongfeng chassis water sprinkler truck?
For Dali Dongfeng chassis water sprinkler truck: define the job and emission first, compare key drive/power options, then open the matching model for special equipment and quote.
What is water sprinkler truck typically used for?
water sprinkler truck specs vary widely by job. Define the application first, then compare specs here and request a quote.
How many models does Dali Dongfeng chassis water sprinkler truck include?
Dali Dongfeng chassis water sprinkler truck currently lists about 30 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Dali Dongfeng chassis water sprinkler truck?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
