FAW Jiefang J6P 350hp 8X4(12 wheels) flatbed truck (Chengliwei brand)
EXW
From $48,611
Export quote
Chengliwei FAW Jiefang chassis flatbed truck
Main model photos
121 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| FAW Jiefang J6P 350hp 8X4(12 wheels) flatbed truck (Chengliwei brand) | 8x4 / 350hp / China V | From $48,611 | |
| FAW Jiefang J6P 350hp 8X4(12 wheels) flatbed truck (Chengliwei brand) | 8x4 / 350hp / China V | From $49,167 | |
| FAW Jiefang J6M 320hp 6X4(10 wheels) Flatbed Truck (Chengliwei Brand)(457 Rear Axle) | 6x4 / 320hp / China V | From $40,056 | |
| FAW Jiefang J6M 320 hp 6X4(10 wheels) Flatbed Truck (Chengliwei Brand) | 6x4 / 320hp / China V | From $40,708 | |
| FAW Jiefang J6M 280 hp 6X4(10 wheels) Flatbed Truck (Chengliwei Brand) | 6x4 / 280hp / China V | From $39,389 |
FAW Jiefang J6P 350hp 8X4(12 wheels) flatbed truck (Chengliwei brand)
EXW
From $49,167
Export quote
FAW Jiefang J6M 320hp 6X4(10 wheels) Flatbed Truck (Chengliwei Brand)(457 Rear Axle)
EXW
From $40,056
Export quote
FAW Jiefang J6M 320 hp 6X4(10 wheels) Flatbed Truck (Chengliwei Brand)
EXW
From $40,708
Export quote
FAW Jiefang J6M 280 hp 6X4(10 wheels) Flatbed Truck (Chengliwei Brand)
EXW
From $39,389
Export quote
Series Specs
Basic Info
Cab dimensions: 11×2.55×3.3 / 11.4×2.55×3.6 / 9.7×2.5×3.2 / 11×2.5×3.2 / 8.5×2.5×2.85 / 9×2.5×2.85m
Type: flatbed truck
Drive type: 8X4 / 6X4 / 6X2 / 4X2
Wheelbase: 2100+3600+1350 / 2100+4300+1350 / 4350+1350 / 1900+4700 / 4500 / 5300mm
Rated mass: 15.87 / 15.305 / 13.21 / 15.135 / 8.975ton
GVWR: 31 / 25 / 15.6ton
Front/rear suspension: 1.47/1.48 / 1.47/2.18 / 1.4/2.65 / 1.4/3 / 1.4/2.6m
Body Parameters
Other special notes: 2017 J6L semi-floating flat roof small half-row cab, power windows, power mirrors, mechanical suspension driver seat, single DIN Beidou-compatible onboard system, center seat; axle Φ344 stamped welded axle (auto slack adjuster, domestic ABS); frame height 220×75×6; auto AC, iron bumper, aluminum radiator, manual hydraulic tilt, front underrun protection, rear overhang 855mm, speed limited to 89km/h; Φ395 clutch; axle 1800 front axle
Vehicle certification code: CLW5310TPBC5 / CLW5311TPBC5 / CLW5251TPBC5 / CLW5250TPBC5 / CLW5161TPBC5
Body Brand: Chengliwei
Engine parameters
Engine Model: XichaiCA6DL2-35E5 / DachaiCA6DK1-32E51 / DachaiCA6DK1-28E51 / DachaiCA6DK1-24E5 / DachaiCA4DK1-22E5 / DachaiCA4DK1-18E51 / Dachai CA4DK1-18E5
Displacement: 8.57 / 7.146 / 4.764 / 4.76L
Emission standard: China V
Max output power: 261 / 239 / 209 / 180 / 165 / 139kW
Max hp: 350 / 320 / 280 / 240 / 220 / 180Horsepower
Chassis Specs
Chassis Brand: FAW Jiefang
Chassis Series: J6P / FAW JiefangJ6P / FAW JiefangJ6M / FAW JiefangJ6L
Chassis Model: CA3310P66K2L5BT4AE5 / CA3310P66K2L6BT4AE5 / CA1250P63K1L3T1E5Z / CA1250P62K1L7T3E5 / CA1160P62K1L2E5Z
rear axle description: 16T / Φ457 stamped-welded axle; ratio 4.875 / φ290 wheel reduction axle; ratio 5.263 / 457 stamped-welded axle; ratio 4.875 / Ф435 stamped-welded axle; ratio 4.111 / 378 / 378 axle
Leaf spring count: 9/9/10 / 10/10/12,9/9/10 / 11/11,3/11,9/10 / 11/11/13+7,3/3/10+9,3/3/4+3,3/3/12+9,10/10/12+9 / 7/10+3,10/12+8,7/7+6,12/12+8,12/10+9
Transmission Parameters
Number of gears: 12 / 10 / 8 / 6Gear
Transmission Model: FAW Jiefang 12-speed / FAW12-speed / FAWCA10TA130M / Fast Gear8JS85E / FAWCA8TAX090M / Fast Gear 8-speed
Tire
Tire Size: 11.00R20 / 11.00R20,11.00-20 / 295/80R22.5 / 9.00R20 / 9.00-20,9.00R20,10R22.5,10.00-20,10.00R20
FAQ
What kind of truck is Chengliwei Chengliwei FAW Jiefang chassis flatbed truck?
Chengliwei Chengliwei FAW Jiefang chassis is an export-oriented flatbed truck lineup with about 11 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Chengliwei FAW Jiefang chassis flatbed truck?
Chengliwei FAW Jiefang chassis flatbed truck export reference is about $21,528 – $49,167. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Chengliwei FAW Jiefang chassis flatbed truck cover?
Chengliwei FAW Jiefang chassis flatbed truck mainly covers: Drive: 6x4 / 8x4; Horsepower: 280 hp / 320 hp / 350 hp; Emission: China V. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Chengliwei FAW Jiefang chassis flatbed truck?
For Chengliwei FAW Jiefang chassis flatbed truck: define the job and emission first, compare key drive/power options, then open the matching model for special equipment and quote.
What is flatbed truck typically used for?
flatbed truck specs vary widely by job. Define the application first, then compare specs here and request a quote.
How many models does Chengliwei FAW Jiefang chassis flatbed truck include?
Chengliwei FAW Jiefang chassis flatbed truck currently lists about 11 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Chengliwei FAW Jiefang chassis flatbed truck?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
