HFC4DB4-2E1
EXW
Export quote
JAC 4DB Series engine
Main model photos
7 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| HFC4DB4-2E1 | 171hp / China VI | ||
| JAC HFC4DB2-2E1 170hp 2L China VI Diesel Engine | 170hp / China VI | ||
| JAC HFC4DB3-2E5 129 hp 2.2L China VI Diesel Engine | 129hp / China VI | ||
| JAC HFC4DB3-2E1 136 hp 2.2L China VI Diesel Engine | 136hp / China VI | ||
| JAC HFC4DB3-2E4 129 hp 2L China VI Diesel Engine | 129hp / China VI |
JAC HFC4DB2-2E1 170hp 2L China VI Diesel Engine
EXW
Export quote
JAC HFC4DB3-2E5 129 hp 2.2L China VI Diesel Engine
EXW
Export quote
JAC HFC4DB3-2E1 136 hp 2.2L China VI Diesel Engine
EXW
Export quote
JAC HFC4DB3-2E4 129 hp 2L China VI Diesel Engine
EXW
Export quote
Series Specs
Engine parameters
Engine Series: 4DB series
Engine manufacturer: JAC / Anhui JAC Automobile Co., Ltd. / JAC Engine Company
Suitable Range: Multifunction commercial vehicle, light truck
Intake type: Turbocharged Air-to-Air Intercooling
Min. fuel consumption at full load: 210g/kW.h
Bore × Stroke: 83×92.4 / 83×90mm
Valves per cylinder: 4pcs
Engine Brand: JAC
Engine Model: HFC4DB4-2E1 / HFC4DB2-2E1 / HFC4DB3-2E5 / HFC4DB3-2E1 / HFC4DB3-2E4 / HFC4DB3-2E3 / HFC4DB2-2E / HFC4DB3-2E / HFC4DB2-1D1 / HFC4DB2-1D2 / HFC4DB1-2D / HFC4DB2-1D / 2.0L CTI
Number of cylinders: 4cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 2.5 / 1.999 / 2.183 / 1.997 / 2.184 / 2.003 / 1.947L
Emission standard: China VI / China V
Max output power: 126 / 125 / 95 / 100 / 89 / 110 / 102 / 97kW
Max hp: 171 / 170 / 129 / 136 / 121 / 150 / 139 / 132 / 138Horsepower
Max torque: 460 / 320 / 360 / 285 / 310N·m
Max torque speed: 1400-2600 / 1500-2500 / 1400-2400 / 1600-2200 / 1800-2400 / 1400-3000 / 2000-2800 / 2200-2600rpm
Rated speed: 3000 / 3200 / 3600 / 4000rpm
Engine Type: Inline 4-cylinder, high-pressure common rail, turbocharged intercooled / Inline 4-cylinder, high-pressure common rail, turbocharged intercooled, DPF aftertreatment / Inline 4-cylinder, high-pressure common rail, turbocharged
FAQ
What kind of truck is JAC JAC 4DB Series engine?
JAC JAC 4DB Series is an export-oriented engine lineup with about 13 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does JAC 4DB Series engine cover?
JAC 4DB Series engine mainly covers: Horsepower: 129 hp / 136 hp / 170 hp / 171 hp; Emission: China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in JAC 4DB Series engine?
For JAC 4DB Series engine, choose in order: emission → drive → horsepower/fuel → compare price and photos → open a model to quote. Include port and quantity.
What is engine typically used for?
For engine, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does JAC 4DB Series engine include?
JAC 4DB Series engine currently lists about 13 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for JAC 4DB Series engine?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
