FAW Jiefang J6L 240hp 4X2(6 wheels) hook lift garbage truck (China VI) (Huiqiang Vehicles)
EXW
Export quote
Huiqiang Heavy Industry FAW Jiefang chassis garbage
Main model photos
16 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| FAW Jiefang J6L 240hp 4X2(6 wheels) hook lift garbage truck (China VI) (Huiqiang Vehicles) | 4x2 / 240hp / China VI | ||
| FAW Jiefang J6L 220hp 4X2(6 wheels) Hook Lift Garbage Truck (China VI)(Huiqiang Vehicles) | 4x2 / 220hp / China VI | ||
| FAW Jiefang J6L 180hp 4X2(6 wheels) hook lift garbage truck (China VI) (Huiqiang Vehicles) | 4x2 / 180hp / China VI | ||
| FAW Jiefang J6L 220hp 4X2(6 wheels) Hook Lift Garbage Truck (China VI)(Huiqiang Vehicles) | 4x2 / 220hp / China VI | ||
| FAW Jiefang J6L 240hp 4X2(6 wheels) Compressed Garbage Truck (Huiqiang Vehicles) | 4x2 / 240hp / China VI |
FAW Jiefang J6L 220hp 4X2(6 wheels) Hook Lift Garbage Truck (China VI)(Huiqiang Vehicles)
EXW
Export quote
FAW Jiefang J6L 180hp 4X2(6 wheels) hook lift garbage truck (China VI) (Huiqiang Vehicles)
EXW
Export quote
FAW Jiefang J6L 220hp 4X2(6 wheels) Hook Lift Garbage Truck (China VI)(Huiqiang Vehicles)
EXW
Export quote
FAW Jiefang J6L 240hp 4X2(6 wheels) Compressed Garbage Truck (Huiqiang Vehicles)
EXW
Export quote
Series Specs
Basic Info
Cab dimensions: 7.4×2.468×3.1 / 8.803×2.468×3.5 / 9.625×2.521×3.61m
Type: Interchangeable body garbage truck / Compression-type garbage truck
Drive type: 4X2 / 6X4
Front/rear track width: Front:1928;Rear:1860 / Front:1928;Rear:1878 / Front:1928;Rear:1878/1878mm
Wheelbase: 5300 / 4700 / 4350+1350mm
Rated mass: 9.905 / 6.46 / 10.805ton
GVWR: 18 / 25ton
Front/rear suspension: 1.4/1.5 / 1.4/2.47 / 1.4/2.122m
Energy Type: Diesel
Engine parameters
Engine Model: DachaiCA6DH1-24E6 / DachaiCA6DH1-22E6 / DachaiCA4DK1-18E6 / DachaiCA4DK1-22E6 / DachaiCA6DK1-32E6 / DachaiCA6DK1-28E6 / DachaiCA6DK1-26E6
Displacement: 5.7 / 4.8 / 7.2L
Emission standard: China VI
Max output power: 179 / 165 / 136 / 162 / 235 / 206 / 192kW
Max hp: 240 / 220 / 180 / 320 / 280 / 260Horsepower
Rated speed: 2500 / 2300rpm
Cargo box parameters
Box volume: 16 / 20m³
Body Parameters
Vehicle certification code: BSQ5180ZXXCAD6 / BSQ5180ZYSCAD6 / BSQ5251ZYSCAD6
Body Brand: Huiqiang Vehicle
Chassis Specs
Chassis Brand: FAW Jiefang / CA1180P62K1L2A1E6Z / CA1250P62K1L3T1E6Z
Chassis Series: J6L / FAW Jiefang
Chassis Model: CA1180P62K1L2A1E6Z / FAW JiefangJ6L
Leaf spring count: 10/12+8 / 12/10
Transmission Parameters
Number of gears: 6Gear
Transmission Model: 6-speed transmission / 8-speed / 9-Speed
Cab parameters
Cab: J6L
Tire
Tire Size: 11.00R20 / 10.00R20
Number of tires: 6 / 10pcs
FAQ
What kind of truck is Huiqiang Heavy Industry Huiqiang Heavy Industry FAW Jiefang chassis garbage truck?
Huiqiang Heavy Industry Huiqiang Heavy Industry FAW Jiefang chassis is an export-oriented garbage truck lineup with about 10 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does Huiqiang Heavy Industry FAW Jiefang chassis garbage cover?
Huiqiang Heavy Industry FAW Jiefang chassis garbage mainly covers: Drive: 4x2; Horsepower: 180 hp / 220 hp / 240 hp; Emission: China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Huiqiang Heavy Industry FAW Jiefang chassis garbage?
For Huiqiang Heavy Industry FAW Jiefang chassis garbage: define the job and emission first, compare key drive/power options, then open the matching model for special equipment and quote.
What is garbage truck typically used for?
garbage truck specs vary widely by job. Define the application first, then compare specs here and request a quote.
How many models does Huiqiang Heavy Industry FAW Jiefang chassis garbage include?
Huiqiang Heavy Industry FAW Jiefang chassis garbage currently lists about 10 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Huiqiang Heavy Industry FAW Jiefang chassis garbage?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
