MC13.58-61
EXW
Export quote
Sinotruk MC13 series engine
Main model photos
12 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| MC13.58-61 | 580hp / China VI | ||
| Sinotruk MC13.46-61 460 hp 12.5L China VI Diesel Engine | 460hp / China VI | ||
| Sinotruk MC13.51-50 510hp 13L China V Diesel Engine | 510hp / China V | ||
| Sinotruk MC13.54-61 540hp 13L China VI Diesel Engine | 540hp / China VI | ||
| Sinotruk MC13.50-61 500hp 13L China VI Diesel Engine | 500hp / China VI |
Sinotruk MC13.46-61 460 hp 12.5L China VI Diesel Engine
EXW
Export quote
Sinotruk MC13.51-50 510hp 13L China V Diesel Engine
EXW
Export quote
Sinotruk MC13.54-61 540hp 13L China VI Diesel Engine
EXW
Export quote
Sinotruk MC13.50-61 500hp 13L China VI Diesel Engine
EXW
Export quote
Series Specs
Engine parameters
Engine Series: MC13 Series
Engine manufacturer: Sinotruk Group Co., Ltd. / Sinotruk
Suitable Range: For Trucks
Intake type: Turbocharged Air-to-Air Intercooling
Min. fuel consumption at full load: ≤186 / ≤185 / ≤188 / ≤190g/kW.h
Engine net weight: 975 / 970 / 990kg
noise at 1m: ≤94 / ≤97.5 / ≤97dB
Compression ratio: 19：1 / 16.5:1
Bore × Stroke: 126x166mm
Valves per cylinder: 4pcs
firing order: 1-5-3-6-2-4
Engine Brand: Sinotruk
Engine Model: MC13.58-61 / MC13.46-61 / MC13.51-50 / MC13.54-61 / MC13.50-61 / MC13.50-60 / MC13.48-60 / MC13.54-50 / MC13.48-50 / MC13.54-30 / MC13.48-30 / MC13.54-40 / MC13.48-40
Number of cylinders: 6cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 12.419L
Emission standard: China VI / China V / China III / Euro III / China IV
Max output power: 429 / 341 / 378 / 400 / 371 / 368 / 353 / 397kW
Max hp: 580 / 460 / 510 / 540 / 500 / 480Horsepower
Max torque: 2500 / 2400 / 2300N·m
Max torque speed: 1000-1400 / 1050-1400 / 1050-1350rpm
Rated speed: 1900rpm
Engine Type: Inline 6-cylinder, water-cooled, 4-stroke, turbocharged intercooled, high-pressure common rail / Inline, water-cooled, 4-stroke, turbocharged with intercooler
FAQ
What kind of truck is Sinotruk Sinotruk MC13 series engine engine?
Sinotruk Sinotruk MC13 series engine is an export-oriented engine lineup with about 13 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does Sinotruk MC13 series engine cover?
Sinotruk MC13 series engine mainly covers: Horsepower: 460 hp / 500 hp / 510 hp / 540 hp / 580 hp; Emission: China V / China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Sinotruk MC13 series engine?
For Sinotruk MC13 series engine, choose in order: emission → drive → horsepower/fuel → compare price and photos → open a model to quote. Include port and quantity.
What is engine typically used for?
For engine, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does Sinotruk MC13 series engine include?
Sinotruk MC13 series engine currently lists about 13 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Sinotruk MC13 series engine?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
