SHACMAN Commercial Vehicle Xuande Wing 6 270 hp 6X4(10 wheels) Compressed Garbage Truck (Chengliwei Brand)
EXW
From $50,000
Export quote
Chengliwei SHACMAN Commercial Vehicle chassis
Main model photos
35 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| SHACMAN Commercial Vehicle Xuande Wing 6 270 hp 6X4(10 wheels) Compressed Garbage Truck (Chengliwei Brand) | 6x4 / 270hp / China VI | From $50,000 | |
| SHACMAN Commercial Vehicle Xuande X9 200 hp 4X2(6 wheels) Compressed Garbage Truck (Chengliwei Brand) | 4x2 / 200hp / China VI | From $27,500 | |
| SHACMAN Commercial Vehicle Xuande X9 129 hp 4X2(6 wheels) Compressed Garbage Truck (Chengliwei Brand) | 4x2 / 129hp / China V | From $11,389 | |
| SHACMAN Commercial Vehicle Xuande X9 130 hp 4X2(6 wheels) Compressed Garbage Truck (Chengliwei Brand) (Weichai) | 4x2 / 130hp / China V | From $11,944 | |
| SHACMAN Commercial Vehicle Xuande X9 125 hp 4X2(6 wheels) Compression Refuse Truck (Chengliwei Brand) | 4x2 / 125hp / China V | From $11,389 |
SHACMAN Commercial Vehicle Xuande X9 200 hp 4X2(6 wheels) Compressed Garbage Truck (Chengliwei Brand)
EXW
From $27,500
Export quote
SHACMAN Commercial Vehicle Xuande X9 129 hp 4X2(6 wheels) Compressed Garbage Truck (Chengliwei Brand)
EXW
From $11,389
Export quote
SHACMAN Commercial Vehicle Xuande X9 130 hp 4X2(6 wheels) Compressed Garbage Truck (Chengliwei Brand) (Weichai)
EXW
From $11,944
Export quote
SHACMAN Commercial Vehicle Xuande X9 125 hp 4X2(6 wheels) Compression Refuse Truck (Chengliwei Brand)
EXW
From $11,389
Export quote
Series Specs
Basic Info
Cab dimensions: 10.3×2.55×3.3 / 8.57×2.55×3.33 / 7.09×2.2/2.3/2.4×2.55/2.6m
Type: Compression-type garbage truck
Drive type: 6X4 / 4X2
Wheelbase: 4375+1350 / 4500 / 3300mm
Front/rear track width: Front track: 1900mm; Rear track: 1860/1860 / Front track: 1830mm; Rear track: 1940mm / Front: 1670,1700mm; Rear: 1525,1640,1594
Rated mass: 9.905 / 7.47 / 2.285ton
GVWR: 25 / 18 / 8.28ton
Front/rear suspension: 1.45/3.005 / 1.3/2.45 / 1.2/2m
Energy Type: Diesel
Engine parameters
Injection System: Common Rail
Engine Model: YuchaiYCS06270-60 / YuchaiYCS04200-68 / Yunnei PowerYN38CRE1 / WeichaiWP3.7Q130E50 / Yunnei PowerD25TCIE3 / WeichaiWP3Q130E50 / Yunnei PowerYNF40E2 / FotonISF3.8s5154
Displacement: 6.23 / 4.16 / 3.76 / 3.66 / 2.499 / 2.97 / 3.92L
Emission standard: China VI / China V
Max output power: 199 / 147 / 95 / 96 / 92 / 115kW
Max hp: 270 / 200 / 129 / 130 / 125 / 156 / 154Horsepower
Rated speed: 2300 / 3000 / 2900 / 3200 / 2600rpm
Body Parameters
Special Function Description: Fuel tank 270L aluminum
Vehicle certification code: CLW5251ZYSAHJ / CLW5181ZYSBHJ
Body Brand: Chengliwei
Cargo box parameters
Box volume: 5m³
Chassis Specs
Chassis Brand: SHACMAN Commercial Vehicle
Chassis Series: Xuande Yi6 / Xuande X9
Chassis Model: SX1250GP6444C / SX1180BP6501 / SX1080GP5
Frame Dimensions: 280/8+6 double-layermm
rear axle description: 13t single reduction dual rear axle / 10T / Rear axle load 5280 kg
Leaf spring count: 10/12 / 9/10+8 / 7/10+3,7/9+7,9/11+8
Transmission Parameters
Number of gears: 9 / 8 / 5Gear
Transmission Model: Fast Gear9JS119A / 8-speed gearbox / 5-speed transmission
Cab parameters
Cab: Xuande X9
Tire
Tire Size: 11.00R20 18PR / 10.00R20 18PR / 7.50-16LT,7.50R16LT,8.25-16LT,8.25R16LT
Number of tires: 10 / 6pcs
FAQ
What kind of truck is Chengliwei Chengliwei SHACMAN Commercial Vehicle chassis garbage truck?
Chengliwei Chengliwei SHACMAN Commercial Vehicle chassis is an export-oriented garbage truck lineup with about 8 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Chengliwei SHACMAN Commercial Vehicle chassis?
Chengliwei SHACMAN Commercial Vehicle chassis export reference is about $11,389 – $50,000. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Chengliwei SHACMAN Commercial Vehicle chassis cover?
Chengliwei SHACMAN Commercial Vehicle chassis mainly covers: Drive: 4x2 / 6x4; Horsepower: 125 hp / 129 hp / 130 hp / 200 hp / 270 hp; Emission: China V / China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Chengliwei SHACMAN Commercial Vehicle chassis?
For Chengliwei SHACMAN Commercial Vehicle chassis: define the job and emission first, compare key drive/power options, then open the matching model for special equipment and quote.
What is garbage truck typically used for?
garbage truck specs vary widely by job. Define the application first, then compare specs here and request a quote.
How many models does Chengliwei SHACMAN Commercial Vehicle chassis include?
Chengliwei SHACMAN Commercial Vehicle chassis currently lists about 8 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Chengliwei SHACMAN Commercial Vehicle chassis?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
