JAC H5 2.5L Diesel 155hp 4X2(6 wheels) WLY 8-speed 3.85m semi-crew flatbed grain van light truck
EXW
From $13,111
Export quote
JAC H5 light truck Cargo Trucks
Main model photos
332 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| JAC H5 2.5L Diesel 155hp 4X2(6 wheels) WLY 8-speed 3.85m semi-crew flatbed grain van light truck | 4x2 / 155hp / China VI | From $13,111 | |
| JAC H5 2.5L diesel 155 hp 4X2(6 wheels) WLY 8-speed 4.18m single-row stake light truck | 4x2 / 155hp / China VI | From $12,903 | |
| JAC H5 2.5L diesel 155 hp 4X2(6 wheels) Lu'an 6-speed 3.85m double-row stake light truck | 4x2 / 155hp / China VI | From $12,694 | |
| JAC H5 2.5L Diesel 155hp 4X2(6 wheels) WLY 8-speed 3.85m semi-crew flatbed grain van light truck | 4x2 / 155hp / China VI | From $13,111 | |
| JAC H5 2.5L diesel 155 hp 4X2(6 wheels) WLY 8-speed 4.18m single-row stake light truck | 4x2 / 155hp / China VI | From $12,903 |
JAC H5 2.5L diesel 155 hp 4X2(6 wheels) WLY 8-speed 4.18m single-row stake light truck
EXW
From $12,903
Export quote
JAC H5 2.5L diesel 155 hp 4X2(6 wheels) Lu'an 6-speed 3.85m double-row stake light truck
EXW
From $12,694
Export quote
JAC H5 2.5L Diesel 155hp 4X2(6 wheels) WLY 8-speed 3.85m semi-crew flatbed grain van light truck
EXW
From $13,111
Export quote
JAC H5 2.5L diesel 155 hp 4X2(6 wheels) WLY 8-speed 4.18m single-row stake light truck
EXW
From $12,903
Export quote
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| JAC H5 2.0L CNG 150hp 4X2(6 wheels) Xingrui 6-speed 3.85m semi-row cage cargo light truck | 4x2 / 150hp / China VI | ||
| JAC H5 2.0L CNG 150hp 4X2(6 wheels) Xingrui 6-speed 4.18m single-row cage cargo light truck | 4x2 / 150hp / China VI | ||
| JAC H5 2.0L CNG 150 hp 4X2(6 wheels) Xingrui 6-Speed 3.82m Extended Cab Van Light Truck | 4x2 / 150hp / China VI | ||
| JAC H5 2.0L CNG 150 hp 4X2(6 wheels) Xingrui 6-Speed 4.15m Single Row Van Light Truck | 4x2 / 150hp / China VI | ||
| JAC H5 2.0L CNG 150 hp 4X2(6 wheels) Xingrui 6-Speed 3.85m Extended Cab Flatbed Light Truck | 4x2 / 150hp / China VI |
JAC H5 2.0L CNG 150hp 4X2(6 wheels) Xingrui 6-speed 3.85m semi-row cage cargo light truck
EXW
Export quote
JAC H5 2.0L CNG 150hp 4X2(6 wheels) Xingrui 6-speed 4.18m single-row cage cargo light truck
EXW
Export quote
JAC H5 2.0L CNG 150 hp 4X2(6 wheels) Xingrui 6-Speed 3.82m Extended Cab Van Light Truck
EXW
Export quote
JAC H5 2.0L CNG 150 hp 4X2(6 wheels) Xingrui 6-Speed 4.15m Single Row Van Light Truck
EXW
Export quote
JAC H5 2.0L CNG 150 hp 4X2(6 wheels) Xingrui 6-Speed 3.85m Extended Cab Flatbed Light Truck
EXW
Export quote
Series Specs
Basic Info
Model code (announced): HFC5043CCYP31K1C7NS / HFC5043CCYP31K1C4NS-1 / HFC5043CCYP31K1C4NS / HFC5043XXYP31K1C7NS / HFC5045XXYP22K1C7S / HFC5045CCYP32N3C7NS / HFC5045XXYP32N3C7NS / HFC1045P32N3C7NS / HFC5045CCYB22K1C7S / HFC5045XXYB22K1C7S / HFC1045B22K1C7S / HFC5045CCYP22K1C7S-1 / HFC5045CCYP22K1C7S / HFC1045P22K1C7S / HFC1043P31K1C4NS / HFC5043XXYP31K1C4NS
Type: stake truck / enclosed cargo truck / Cargo Trucks
Drive type: 4X2
Wheelbase: 3365 / 3600mm
Box length class: 3.8 / 4.2m
Engine Model: Yunnei PowerYN25PLUS160A / QuanchaiQ25A-150E60 / Yunnei PowerG20TNF-150 / QuanchaiQ23A-142E60 / QuanchaiQ25-152E60A / QuanchaiQ25A-162E60
Transmission Model: WLYWLY8GS46 / Lu'an LC6T450B / Xingrui LC6T450B / Xingrui ML532C / Xingrui ML645B / WLY 8-speed / WLYWLY6GS46 / WLY8GS46
Rear Axle Ratio: 4.875 / 4.33
Cab length: 5.995m
Cab width: 2.2 / 2.125 / 2.165 / 2.115 / 2.075 / 2.11 / 2.18 / 2.14 / 1900m
Cab height: 3.1 / 3.16 / 3.25 / 3.05 / 2.45 / 2.36 / 3.15 / 2.48 / 2.54 / 2.5m
Front track width: 1595 / 1560 / 1695mm
rear track: 1705 / 1560 / 1620mm
Curb Weight: 2.72 / 2.6 / 2.805 / 2.565ton
Rated payload: 1.58 / 1.495 / 1.735ton
GVWR: 4.495 / 4.29ton
Max. speed: 95 / 100km/h
Origin: Suining, Sichuan / Hefei, Anhui
tonnage class: Light Truck
Approach angle: 24 / 21°
departure angle: 16 / 14 / 15°
Remarks: Optional: 4.33 ratio. / With hydraulic tail lift / Optional ratio 4.33/5.375 / Optional ratio 4.875/5.375 / Optional ratio 5.375 / Optional: 4.33 ratio, leaf spring count 4/4+2. / Optional: Wide track, 2100 wide cargo box, tread plate, aluminum side guard, aluminum fuel tank, leather seat.
Front/rear suspension: 1.075/1.32 / 1.075/1.555 / 1.1/1.53 / 1.125/1.27 / 1.125/1.505 / 1.17/1.46 / 1.1/1.525 / 1.1/1.085m
Version: Luxury Edition
Energy Type: Diesel / Compressed Natural Gas (CNG)
Engine parameters
Engine Brand: Yunnei Power / Quanchai
Engine info: Yunnei Power2.5L / Quanchai2.5L / Yunnei Power2L / QuanchaiQ23A / Quanchai2.3 / QuanchaiQ25 / Yunnei 2.5L
Number of cylinders: 4cylinder
Cylinder arrangement: Inline
Displacement: 2.499 / 2.496 / 1.989 / 2.3 / 2.493L
Emission standard: China VI
Max output power: 114 / 110 / 103 / 112 / 116kW
Max hp: 155 / 150 / 142 / 152 / 162Horsepower
Max torque: 420 / 330 / 350 / 440N·m
Max torque speed: 1400-2300 / 1200-3000 / 1400-2750 / 1400-2400 / 1400rpm
Rated speed: 3300 / 3000 / 4000rpm
Transmission Parameters
Transmission Brand: WLY / Lu'an / Xingrui / Xingrui ML532C
shift method: Manual
Forward gears: 8 / 6 / 5Gear
Number of Reverse Gears: 2 / 1pcs
FAQ
What kind of truck is JAC JAC H5 light truck Cargo Trucks?
JAC JAC H5 light truck is an export-oriented Cargo Trucks lineup with about 206 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for JAC H5 light truck Cargo Trucks?
JAC H5 light truck Cargo Trucks export reference is about $10,139 – $20,556. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does JAC H5 light truck Cargo Trucks cover?
JAC H5 light truck Cargo Trucks mainly covers: Drive: 4x2; Horsepower: 150 hp / 155 hp; Emission: China VI; Fuel: Compressed Natural Gas (CNG) / Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in JAC H5 light truck Cargo Trucks?
For JAC H5 light truck Cargo Trucks: 1) set emission; 2) match body/wheelbase to cargo type; 3) pick drive and horsepower; 4) compare prices, then open a model to quote.
What is Cargo Trucks typically used for?
Cargo Trucks covers box, stake or flatbed cargo work from city delivery to regional haul. Filter by body and payload needs.
How many models does JAC H5 light truck Cargo Trucks include?
JAC H5 light truck Cargo Trucks currently lists about 206 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for JAC H5 light truck Cargo Trucks?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
