Dongfeng Liuqi Chenglong H5 350 hp 6X4(10 wheels) Hook-lift Garbage Truck (Zoomlion brand)
EXW
From $39,306
Export quote
ZOOMLION Dongfeng Liuqi chassis garbage truck
Main model photos
69 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Dongfeng Liuqi Chenglong H5 350 hp 6X4(10 wheels) Hook-lift Garbage Truck (Zoomlion brand) | 6x4 / 350hp / China VI | From $39,306 | |
| Dongfeng Liuqi Chenglong H5 350 hp 6X4(10 wheels) Compactor Garbage Truck (Zoomlion brand) | 6x4 / 350hp / China VI | From $39,306 | |
| Dongfeng Liuqi Chenglong H5 270 hp 6X4(10 wheels) hook-lift garbage truck (Zhonglian brand) | 6x4 / 270hp / China VI | From $35,139 | |
| Dongfeng Liuqi Chenglong H5 350 hp 8X4(12 wheels) Compression Type Garbage Truck (Zhonglian Brand) | 8x4 / 350hp / China VI | From $42,083 | |
| Dongfeng Liuqi Chenglong M3 230 hp 4X2(6 wheels) Container Detachable Garbage Truck (Zoomlion Brand) | 4x2 / 230hp | From $32,222 |
Dongfeng Liuqi Chenglong H5 350 hp 6X4(10 wheels) Compactor Garbage Truck (Zoomlion brand)
EXW
From $39,306
Export quote
Dongfeng Liuqi Chenglong H5 270 hp 6X4(10 wheels) hook-lift garbage truck (Zhonglian brand)
EXW
From $35,139
Export quote
Dongfeng Liuqi Chenglong H5 350 hp 8X4(12 wheels) Compression Type Garbage Truck (Zhonglian Brand)
EXW
From $42,083
Export quote
Dongfeng Liuqi Chenglong M3 230 hp 4X2(6 wheels) Container Detachable Garbage Truck (Zoomlion Brand)
EXW
From $32,222
Export quote
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Dongfeng Liuqi Chenglong M3 180 hp 4X2(6 wheels) Compactor Garbage Truck (Zoomlion Brand) | 4x2 / 180hp / China IV | ||
| Dongfeng Liuqi Chenglong M3 210 hp 4X2(6 wheels) sanitation garbage truck (Zhonglian brand) | 4x2 / 210hp / China IV |
Series Specs
Basic Info
Cab dimensions: 8.53×2.5×3.195 / 10.635×2.54×3.47 / 11.995*2.52*3.995 / 7.195X2.5X2.985 / 11.998×2.5×3.995 / 8.578×2.5×3.34 / 10.36×2.52×3.55 / 7.19×2.496×3.02 / 6.635×2.54×3.28 / 8.61×2.495×3.15 / 8.725×2.48×3.1 / 7.87×2.496×3.095m
Type: Interchangeable body garbage truck / Compression-type garbage truck / Compression-type docking garbage truck / garbage truck
Drive type: 6X4 / 8X4 / 4X2
Wheelbase: 4500+1350 / 2050+3050+1350 / 4500 / 1950+4500+1350 / 5850+1350 / 4700mm
Front/rear track width: 2050/1860/1860 / 2020/2020/1860/1860 / 1940/1860 / 1.94/1.86 / Front: 2020/2020mm; Rear: 1860/1860 / Front: 2050mm; Rear: 1860/1860 / Front track: 1940mm; Rear track: 1860 / Front track: 1940mm; Rear track: 1860mm
Rated mass: 13.52 / 10.02 / 9.925 / 9.82 / 12.79 / 9.85 / 10.325 / 9.74 / 13.22 / 5.145 / 5.405ton
GVWR: 25 / 31 / 18 / 16ton
Front/rear suspension: 1.445/1.235 / 1.445/3.01 / 1.525/2.67 / 1.445/1.25 / 1.512/2.686 / 1.445/1.283 / 1.445/3.065 / 1.445/1.245 / 1.445/1.52 / 1.445/1.315 / 1.445/2.74 / 1.445/1.925m
Energy Type: Diesel
Body Parameters
Special Function Description: Mechanical full-floating cab suspension, manual hydraulic tilt, mechanical damping driver seat, electric windows, remote central locking, A/C, onboard terminal (tachograph + compatible with BeiDou/GPS), external sun visor, multi-state switch, right-turn reminder, overspeed alarm. Domestic valves, ABS (WABCO), self-adjusting arm, maintenance-free battery, direct-drive fan, start/stop from ground, cab master switch, PTO switch, Toyota white, color-matched bumper + fender.
Vehicle certification code: ZBH5251ZXXLZE6 / ZBH5250ZYSLZE6 / ZBH5311ZDJLZE6 / ZLJ5311ZDJLZE5 / ZLJ5250ZDJLZE5 / ZLJ5251ZYSLZE5 / ZLJ5180ZXXLZE5 / ZLJ5182ZDJLZE5 / ZLJ5251ZXXLZE5 / ZLJ5160ZYSLZE4 / ZLJ5163TSLLE4
Body Brand: ZOOMLION
Engine parameters
Engine Model: YuchaiYCK08350-60 / YuchaiYCS06270-60 / DongfengD6.7NS6B230 / YuchaiYCS06245-60 / YuchaiYCS04200-68 / YuchaiYC6L350-50 / YuchaiYC6A270-50 / DongfengISD270 50 / YuchaiYC6JA200-50 / YuchaiYC6J180-42 / Dongfeng ISDe210 40
Displacement: 7.7 / 6.23 / 6.7 / 4.16 / 8.424 / 7.52 / 6.87 / 6.494L
Emission standard: China VI / China V / China IV
Max output power: 257 / 199 / 169 / 180 / 147 / 198 / 132 / 155kW
Max hp: 350 / 270 / 230 / 245 / 200 / 180 / 210Horsepower
Rated speed: 2200 / 2300 / 2500rpm
Chassis Specs
Chassis Brand: DongfengLiuqi
Chassis Series: ChenglongH5 / New Chenglong M3 / ChenglongM3
Chassis Model: LZ1256H5DCT / LZ1316H5FCT / LZ1186M3ACT / LZ1310M5FBT / LZ1250M5DBT / LZ5185XXYM3ABT / LZ1161RAPAT
Frame Dimensions: 300(8+4) / 282(8+4) / 264(6+4) / 231(6) / 300(8+4) double-layer frame / 860 wide 264(6)mm single layer
Steering gear: Domestic
rear axle description: 2*440 (14mm)/ widened brake / 2*440 / 153 / 8T / 457 dual rear axle / 9T / 2*153 / 5T/153
Axle ratio: 5.143 / 5.571 / 4.875 / 5.286 / 4.364
Leaf spring count: 11/10 / 11/11/10 / 11/12+9 / 8/9+5 / 11/11/13 / 11/10,11/13,3/4
clutch: Φ430 / Φ395
Transmission Parameters
Number of gears: 8 / 10 / 7 / 6Gear
Transmission Model: Fast Gear10JSD140T / SinotrukHW11708STC / Fast Gear10JSD160T / DongfengDT0690 / Fast Gear8JS75C / Fast Gear10JSD140B / DachiDC7J120TC / Fast Gear8JS85E / DachiDC7J120TA / Fuller 6J80T / 6J80T
Cab parameters
Cab: H53S / H51S / M31B cab
Tire
Tire Size: 11.00R20 18PR / 10.00R20 18PR / 11.00R20 / 10.00R20 / 11R22.5 / 10.00-20
Number of tires: 10 / 12 / 6pcs
FAQ
What kind of truck is ZOOMLION ZOOMLION Dongfeng Liuqi chassis garbage truck?
ZOOMLION ZOOMLION Dongfeng Liuqi chassis is an export-oriented garbage truck lineup with about 17 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for ZOOMLION Dongfeng Liuqi chassis garbage truck?
ZOOMLION Dongfeng Liuqi chassis garbage truck export reference is about $23,583 – $43,514. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does ZOOMLION Dongfeng Liuqi chassis garbage truck cover?
ZOOMLION Dongfeng Liuqi chassis garbage truck mainly covers: Drive: 4x2 / 6x4 / 8x4; Horsepower: 180 hp / 210 hp / 230 hp / 270 hp / 350 hp; Emission: China IV / China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in ZOOMLION Dongfeng Liuqi chassis garbage truck?
For ZOOMLION Dongfeng Liuqi chassis garbage truck: define the job and emission first, compare key drive/power options, then open the matching model for special equipment and quote.
What is garbage truck typically used for?
garbage truck specs vary widely by job. Define the application first, then compare specs here and request a quote.
How many models does ZOOMLION Dongfeng Liuqi chassis garbage truck include?
ZOOMLION Dongfeng Liuqi chassis garbage truck currently lists about 17 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for ZOOMLION Dongfeng Liuqi chassis garbage truck?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
