JAC EV5 Air Brake 4.15m Single Row Pure Electric Van Light Truck CATL 120kWh 4X2(6 wheels)
EXW
From $23,028
Export quote
JACEV5 electric cargo truck
Main model photos
49 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| JAC EV5 Air Brake 4.15m Single Row Pure Electric Van Light Truck CATL 120kWh 4X2(6 wheels) | 4x2 | From $23,028 | |
| JAC EV5 Air Brake 4.15m Single Row Pure Electric Van Light Truck CATL 100.46kWh 4X2(6 wheels) | 4x2 | From $19,417 | |
| JAC EV5 4.22m Single Row Pure Electric Flatbed Light Truck EVE 103.47kWh 4X2(6 wheels) | 4x2 | From $29,139 | |
| JAC EV5 4.22m Single Row Pure Electric Grain Hauler Light Truck EVE 103.47kWh 4X2(6 wheels) | 4x2 | From $29,972 | |
| JAC EV5 4.22m Single Row Pure Electric Van Light Truck EVE 103.47kWh 4X2(6 wheels) | 4x2 | From $29,972 |
JAC EV5 Air Brake 4.15m Single Row Pure Electric Van Light Truck CATL 100.46kWh 4X2(6 wheels)
EXW
From $19,417
Export quote
JAC EV5 4.22m Single Row Pure Electric Flatbed Light Truck EVE 103.47kWh 4X2(6 wheels)
EXW
From $29,139
Export quote
JAC EV5 4.22m Single Row Pure Electric Grain Hauler Light Truck EVE 103.47kWh 4X2(6 wheels)
EXW
From $29,972
Export quote
JAC EV5 4.22m Single Row Pure Electric Van Light Truck EVE 103.47kWh 4X2(6 wheels)
EXW
From $29,972
Export quote
Series Specs
Basic Info
Model code (announced): HFC5042XXYEV5 / HFC5046XXYEV1 / HFC1042P3EV2 / HFC5042CCYP3EV2 / HFC5042XXYP3EV2 / HFC1042P3EV1 / HFC5042CCYP3EV1 / HFC5042XXYP3EV1 / HFC5042XXYSEV3 / HFC1042EV10 / HFC5042XXYEV11 / HFC5042CCQEV10 / HFC5042CCYEV10 / HFC5042XXYEV10
Type: enclosed cargo truck / Cargo Trucks / stake truck
Drive type: 4X2
Wheelbase: 3365mm
Box length class: 4.2m
Cab length: 5.995m
Cab width: 2.2 / 1900m
Cab height: 3.22 / 3.24 / 2.4 / 3.1 / 3.14 / 2.35 / 3.15 / 3.21 / 2.445 / 2.46m
CLTC range: 350 / 280 / 300 / 240 / 200 / 186km
Curb Weight: 3.25 / 3.35 / 2.95 / 3.31 / 3.2 / 2.98 / 3.18 / 3.15 / 3.12 / 2.7 / 3.05 / 2.88 / 3.02ton
Rated payload: 1.05 / 0.95 / 1.35 / 0.99 / 1.1 / 1.32 / 1.12 / 1.15 / 1.18 / 1.6 / 1.25 / 1.42 / 1.28ton
GVWR: 4.495ton
Max. speed: 90km/h
Origin: Hefei, Anhui
tonnage class: Light Truck
electric motor
Motor 1 Brand: JAC Motors / JAC
Motor 1 Model: TZ220XSJ200 / TZ220XSJ300
Motor Type: Permanent magnet synchronous motor
Energy Type: Electric
total rated power: 65 / 90kW
Peak power: 130 / 170kW
total peak torque: 360N·m
Battery/Charging
Charging method: Fast Charge
Battery Brand: CATL / EVE / EVE Energy, Hubei
Battery type: Lithium Iron Phosphate Battery
Battery capacity: 120 / 100.46 / 103.47 / 100.07 / 102.78 / 81 / 81.144 / 81.14kWh
Battery rated voltage: 611.8V
fast charge time: 1.5 / 1.2h
Battery total voltage: 502.32 / 722.7V
Energy Density: 156.48 / 148.2
Battery Model: T3E-LF168-1P190S
Cargo box parameters
Cargo box volume: 19 / 19.2m³
Cargo box type: Van body / stake body / Stake type
Cargo box length: 4.15 / 4.22 / 4.18m
Cargo box width: 2.1m
Cargo box height: 2.2 / 0.4 / 2.1m
Cab parameters
Cab: EV5
seating capacity: 3Personnel
Seat rows: Single Row
Chassis Specs
Front axle allowable load: 1950kg
FAQ
What kind of truck is JAC JACEV5 electric cargo truck?
JAC JACEV5 is an export-oriented electric cargo truck lineup with about 15 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for JACEV5 electric cargo truck?
JACEV5 electric cargo truck export reference is about $19,417 – $31,917. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does JACEV5 electric cargo truck cover?
JACEV5 electric cargo truck mainly covers: Drive: 4x2. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in JACEV5 electric cargo truck?
For JACEV5 electric cargo truck: confirm local charging and registration first, then filter by range/power and payload, and quote with your operating route.
What is electric cargo truck typically used for?
electric cargo truck focuses on lower-emission work where charging is available. Confirm local charging and registration before purchase.
How many models does JACEV5 electric cargo truck include?
JACEV5 electric cargo truck currently lists about 15 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for JACEV5 electric cargo truck?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
