Isuzu 190hp 4X2(6 wheels) Water Tank Fire Truck (Chengliwei Brand) (HXF5101GXFSG30/QL)
EXW
From $26,250
Export quote
Chengliwei Qingling chassis fire truck
Main model photos
41 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Isuzu 190hp 4X2(6 wheels) Water Tank Fire Truck (Chengliwei Brand) (HXF5101GXFSG30/QL) | 4x2 / 190hp / China V | From $26,250 | |
| Qingling Isuzu 190hp 4X2(6 wheels) foam fire truck (Chengliwei brand) (HXF5101GXFPM30/QL) | 4x2 / 190hp / China V | From $26,250 |
Qingling Isuzu 190hp 4X2(6 wheels) foam fire truck (Chengliwei brand) (HXF5101GXFPM30/QL)
EXW
From $26,250
Export quote
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Qingling Isuzu 189hp 4X2(6 wheels) water tank fire truck (Chengliwei brand) | 4x2 / 189hp / China IV |
Series Specs
Basic Info
Cab dimensions: 6.94x2.28x2.88 / 6.975×2.28×3.14m
Type: fire truck
Drive type: 4X2
Wheelbase: 3815mm
Front/rear track width: Front track: 1680mm; Rear track: 1650
Rated mass: 3.15 / 3.1ton
GVWR: 9.7 / 9.775ton
Front/rear suspension: 1.11/2.015 / 1.11/2.05m
Energy Type: Diesel
Body Parameters
Liquid Capacity: 3.1ton
Tank Size: 1.25×2.2×1.18 / 0.865×2.2×1.18m
Tank Volume: 3.15 / 3.13m3
Vehicle certification code: HXF5101GXFSG30/QL / HXF5101GXFPM30/QL / HXF5101GXFSG30
Body Brand: Chengliwei
Engine parameters
Engine Model: Qingling Isuzu4HK1-TC51 / Qingling Isuzu4HK1-TCG40
Displacement: 5.193L
Emission standard: China V / China IV
Max output power: 141 / 139kW
Max hp: 190 / 189Horsepower
Rated speed: 2600rpm
Chassis Specs
Chassis Brand: Qingling
Chassis Series: Isuzu
Chassis Model: QL1100A8KAY / QL11109KARY
Leaf spring count: 8/10+6
Transmission Parameters
Number of gears: 6Gear
Transmission Model: 6-speed transmission
Cab parameters
Cab: Cab-over, Double-row Cab
Tire
Tire Size: 235/75R17.5 14PR,8.25R20 14PR / 235/75R17.5 14PR / 235/75R17.5-16PR
Number of tires: 6pcs
FAQ
What kind of truck is Chengliwei Chengliwei Qingling chassis fire truck?
Chengliwei Chengliwei Qingling chassis is an export-oriented fire truck lineup with about 3 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Chengliwei Qingling chassis fire truck?
Chengliwei Qingling chassis fire truck export reference is about From $26,250. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Chengliwei Qingling chassis fire truck cover?
Chengliwei Qingling chassis fire truck mainly covers: Drive: 4x2; Horsepower: 189 hp / 190 hp; Emission: China IV / China V; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Chengliwei Qingling chassis fire truck?
For Chengliwei Qingling chassis fire truck: define the job and emission first, compare key drive/power options, then open the matching model for special equipment and quote.
What is fire truck typically used for?
fire truck specs vary widely by job. Define the application first, then compare specs here and request a quote.
How many models does Chengliwei Qingling chassis fire truck include?
Chengliwei Qingling chassis fire truck currently lists about 3 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Chengliwei Qingling chassis fire truck?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
