Dongfeng Special Chassis Series 270 hp 6X4(10 wheels) Truck Mounted Crane (BanJunChangXing Brand)
EXW
From $38,958
Export quote
Suizhou Changxing (Banjun Changxing) Dongfeng
Main model photos
8 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Dongfeng Special Chassis Series 270 hp 6X4(10 wheels) Truck Mounted Crane (BanJunChangXing Brand) | 6x4 / 270hp / China V | From $38,958 | |
| Dongfeng Special Chassis Series 240 hp 6X4(10 wheels) Truck Mounted Crane (BanJunChangXing Brand) | 6x4 / 240hp / China V | From $36,875 | |
| Dongfeng Special Chassis Series 220 hp 6X4(10 wheels) Truck Mounted Crane (BanJunChangXing Brand) | 6x4 / 220hp / China V | From $36,458 | |
| Dongfeng Jincheng 180 hp 4X2(6 wheels) Truck-Mounted Crane (Ban Jun Chang Xing Brand) | 4x2 / 180hp / China V | From $36,736 | |
| Dongfeng Special Chassis Series 180 hp 4X2(6 wheels) Truck-Mounted Crane (Ban Jun Chang Xing Brand) | 4x2 / 180hp / China V | From $39,861 |
Dongfeng Special Chassis Series 240 hp 6X4(10 wheels) Truck Mounted Crane (BanJunChangXing Brand)
EXW
From $36,875
Export quote
Dongfeng Special Chassis Series 220 hp 6X4(10 wheels) Truck Mounted Crane (BanJunChangXing Brand)
EXW
From $36,458
Export quote
Dongfeng Jincheng 180 hp 4X2(6 wheels) Truck-Mounted Crane (Ban Jun Chang Xing Brand)
EXW
From $36,736
Export quote
Dongfeng Special Chassis Series 180 hp 4X2(6 wheels) Truck-Mounted Crane (Ban Jun Chang Xing Brand)
EXW
From $39,861
Export quote
Series Specs
Basic Info
Cab dimensions: 12×2.55×3.88 / 9×2.55×3.58m
Type: Truck with crane
Drive type: 6X4 / 4X2
Wheelbase: 4350+1300 / 4500 / 5100mm
Rated mass: 9.105 / 8.505ton
GVWR: 25 / 18ton
Front/rear suspension: 1.44/3.36 / 1.515/2.385m
Energy Type: Diesel
Body Parameters
Crane model: SPS25000 / SPS16000
Lifting capacity: 10 / 7ton
crane self-weight: 3.8 / 2.65ton
Vehicle certification code: AAA5250JSQE5 / AAA5180JSQE5
Body Brand: Banjun Changxing
Engine parameters
Engine Brand: Yuchai / Dongfeng / Weichai
Engine Model: YuchaiYC6A270-50 / YuchaiYC6JA240-50 / DongfengISB220 50 / YuchaiYC6JA180-50 / WeichaiWP4.1Q165E50
Displacement: 7.52 / 6.87 / 5.9 / 4.088L
Emission standard: China V
Max output power: 199 / 177 / 162 / 132 / 120kW
Max hp: 270 / 240 / 220 / 180 / 165Horsepower
Max torque: 1100 / 950 / 800 / 700 / 560N·m
Max torque speed: 1200-1800 / 1500-1600rpm
Rated speed: 2300 / 2500 / 2600rpm
Chassis Specs
Chassis Brand: Dongfeng
Chassis Series: special chassis series / Dongfeng Special Chassis
Chassis Model: EQ1250GD5DJ1 / EQ1180GSZ5DJ
rear axle description: 13T / 10T
Leaf spring count: 8/9,8/10,9/10,8/13,9/13,3/- / 9/11+9,8/10+8
Transmission Parameters
Number of gears: 9 / 8Gear
Transmission Model: Fast Gear 9-speed / Fast Gear 8-speed
Tire
Tire Size: 11.00R20 18PR / 10.00R20 18PR
Number of tires: 10 / 6pcs
FAQ
What kind of truck is Suizhou Changxing (Banjun Changxing) Suizhou Changxing (Banjun Changxing) Dongfeng Chassis truck-mounted crane?
Suizhou Changxing (Banjun Changxing) Suizhou Changxing (Banjun Changxing) Dongfeng Chassis is an export-oriented truck-mounted crane lineup with about 6 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Suizhou Changxing (Banjun Changxing) Dongfeng?
Suizhou Changxing (Banjun Changxing) Dongfeng export reference is about $36,458 – $39,861. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Suizhou Changxing (Banjun Changxing) Dongfeng cover?
Suizhou Changxing (Banjun Changxing) Dongfeng mainly covers: Drive: 4x2 / 6x4; Horsepower: 180 hp / 220 hp / 240 hp / 270 hp; Emission: China V; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Suizhou Changxing (Banjun Changxing) Dongfeng?
For Suizhou Changxing (Banjun Changxing) Dongfeng: define the job and emission first, compare key drive/power options, then open the matching model for special equipment and quote.
What is truck-mounted crane typically used for?
truck-mounted crane specs vary widely by job. Define the application first, then compare specs here and request a quote.
How many models does Suizhou Changxing (Banjun Changxing) Dongfeng include?
Suizhou Changxing (Banjun Changxing) Dongfeng currently lists about 6 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Suizhou Changxing (Banjun Changxing) Dongfeng?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
