YCS06230-61
EXW
Export quote
Yuchai YCS06 Series engine
Main model photos
7 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| YCS06230-61 | 230hp / China VI | ||
| Yuchai YCS06245-61 245 hp 6.2L China VI diesel engine | 245hp / China VI | ||
| Yuchai YCS06300-61A 300 hp 6.4L China VI Diesel Engine | 300hp / China VI | ||
| Yuchai YCS06245-61A 245hp 6.2L China VI Diesel Engine | 245hp / China VI | ||
| Yuchai YCS06245-61C 245 hp 6.4L China VI Diesel Engine | 245hp / China VI |
Yuchai YCS06245-61 245 hp 6.2L China VI diesel engine
EXW
Export quote
Yuchai YCS06300-61A 300 hp 6.4L China VI Diesel Engine
EXW
Export quote
Yuchai YCS06245-61A 245hp 6.2L China VI Diesel Engine
EXW
Export quote
Yuchai YCS06245-61C 245 hp 6.4L China VI Diesel Engine
EXW
Export quote
Series Specs
Engine parameters
Engine Series: YCS06 Series
Engine manufacturer: Guangxi Yuchai Machinery Co., Ltd.
Suitable Range: Low-speed tractor trucks, 4×2, 6×2 medium-heavy cargo trucks, construction trucks, concrete mixer trucks, 12~16 ton truck cranes. / 8.5~9m highway coach, 9~11m city bus, 10~12m hybrid, 11m school bus / 6×2/6×4 medium-heavy highway truck, medium dump truck, 4×2 special vehicle
Intake type: Turbocharged Air-to-Air Intercooling
Engine net weight: ≤520kg
Bore × Stroke: 105×120 / 105×105 / 102×120mm
Valves per cylinder: 4pcs
Engine Brand: Yuchai
Engine Model: YCS06230-61 / YCS06245-61 / YCS06300-61A / YCS06245-61A / YCS06245-61C / YCS06300-61 / YCS06270-61 / YCS06290-61A / YCS06270-60A / YCS06290-61 / YCS06220-60 / YCS06245-60A / YCS06200-62 / YCS06220-62 / YCS06245-62 / YCS06270-62 / YCS06200-60 / YCS06230-60 / YCS06245-60 / YCS06270-60
Number of cylinders: 6cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 6.234 / 6.442 / 6.2 / 6.23L
Emission standard: China VI
Max output power: 169 / 180 / 221 / 199 / 213 / 162 / 147kW
Max hp: 230 / 245 / 300 / 270 / 290 / 220 / 200Horsepower
Max torque: 800 / 950 / 1200 / 750 / 1000 / 900 / 850 / 1050N·m
Max torque speed: 2300 / 1200-1700rpm
Rated speed: 2300 / 2100rpm
Engine Type: High-pressure common rail + EGR + DOC + DPF + SCR + ASC / High-pressure common rail + EGR + DOC + DPF + SCR
FAQ
What kind of truck is Yuchai Yuchai YCS06 Series engine?
Yuchai Yuchai YCS06 Series is an export-oriented engine lineup with about 20 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does Yuchai YCS06 Series engine cover?
Yuchai YCS06 Series engine mainly covers: Horsepower: 230 hp / 245 hp / 300 hp; Emission: China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Yuchai YCS06 Series engine?
For Yuchai YCS06 Series engine, choose in order: emission → drive → horsepower/fuel → compare price and photos → open a model to quote. Include port and quantity.
What is engine typically used for?
For engine, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does Yuchai YCS06 Series engine include?
Yuchai YCS06 Series engine currently lists about 20 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Yuchai YCS06 Series engine?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
