Dongfeng Furui Ka R5 156 hp 4X2(6 wheels) Vacuum Truck (China VI) (Huatong Brand)
EXW
From $21,250
Export quote
Huatong Dongfeng chassis suction/septic tank truck
Main model photos
25 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Dongfeng Furui Ka R5 156 hp 4X2(6 wheels) Vacuum Truck (China VI) (Huatong Brand) | 4x2 / 156hp / China VI | From $21,250 | |
| Dongfeng Furui Ka R5 170 hp 4X2(6 wheels) Vacuum Truck (China VI) (Huatong Brand) | 4x2 / 170hp / China VI | From $21,944 | |
| Dongfeng Furuika R5 170 hp 4X2(6 wheels) suction sewage truck (7-speed) (Huatong brand) | 4x2 / 170hp / China VI | From $29,681 | |
| Dongfeng Furuika R5 170 hp 4X2(6 wheels) suction sewage truck (Huatong brand) | 4x2 / 170hp / China VI | From $28,194 | |
| Dongfeng Furika R5 156 hp 4X2(6 wheels) Cleaning and Suction Truck (Huato Brand) | 4x2 / 156hp / China VI | From $27,500 |
Dongfeng Furui Ka R5 170 hp 4X2(6 wheels) Vacuum Truck (China VI) (Huatong Brand)
EXW
From $21,944
Export quote
Dongfeng Furuika R5 170 hp 4X2(6 wheels) suction sewage truck (7-speed) (Huatong brand)
EXW
From $29,681
Export quote
Dongfeng Furuika R5 170 hp 4X2(6 wheels) suction sewage truck (Huatong brand)
EXW
From $28,194
Export quote
Dongfeng Furika R5 156 hp 4X2(6 wheels) Cleaning and Suction Truck (Huato Brand)
EXW
From $27,500
Export quote
Series Specs
Basic Info
Cab dimensions: 6.9×2.3×3 / 6.9×2.3×2.75 / 6.9×2.3×3.15 / 7.3×2.36×3.16m
Type: suction sewage truck / cleaning and suction truck
Drive type: 4X2
Wheelbase: 3800mm
Front/rear track width: Front: 1745mm; Rear: 1630 / Front: 1745mm; Rear: 1650mm
Rated mass: 6.1 / 6.555 / 5.575 / 4.4ton
GVWR: 11.995ton
Front/rear suspension: 1.13/1.97 / 1.18/2.32m
Energy Type: Diesel
Body Parameters
Tank Size: 4.1×1.6 / 4.2×2.05×1.4 / 3.9×1.6 / 4.3×1.6m
Tank Volume: 8 / 8.6 / 4.95 / 5.77m3
Transport medium: Liquid waste
Medium Density: 0.8ton/cubic meter
Vehicle certification code: HCQ5125GXWE6 / HCQ5125GXEE6 / HCQ5125GQWE6 / HCQ5121GQW6EQJX
Body Brand: Huatong
Engine parameters
Engine Model: ChaochaiNV30-C6G / ChaochaiCY4SK261 / ChaochaiCY4SK361
Displacement: 2.968 / 3.856L
Emission standard: China VI
Max output power: 115 / 125kW
Max hp: 156 / 170Horsepower
Rated speed: 2500rpm
Chassis Specs
Chassis Brand: Dongfeng
Chassis Series: Forica R5
Chassis Model: EQ1125SJ8CDC
Leaf spring count: 8/10+7,12/12+9 / 8/10+7
Transmission Parameters
Number of gears: 6 / 7Gear
Transmission Model: WLY 6-speed / WLY 7-speed / WLYWLY7TS60
Tire
Tire Size: 245/70R19.5,8.25R20 / 245/70R19.5,8.25R20.25R20 / 245/70R19.5
Number of tires: 6pcs
FAQ
What kind of truck is Huatong Huatong Dongfeng chassis suction/septic tank truck?
Huatong Huatong Dongfeng chassis is an export-oriented suction/septic tank truck lineup with about 7 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Huatong Dongfeng chassis suction/septic tank truck?
Huatong Dongfeng chassis suction/septic tank truck export reference is about $20,833 – $29,681. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Huatong Dongfeng chassis suction/septic tank truck cover?
Huatong Dongfeng chassis suction/septic tank truck mainly covers: Drive: 4x2; Horsepower: 156 hp / 170 hp; Emission: China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Huatong Dongfeng chassis suction/septic tank truck?
For Huatong Dongfeng chassis suction/septic tank truck: define the job and emission first, compare key drive/power options, then open the matching model for special equipment and quote.
What is suction/septic tank truck typically used for?
suction/septic tank truck specs vary widely by job. Define the application first, then compare specs here and request a quote.
How many models does Huatong Dongfeng chassis suction/septic tank truck include?
Huatong Dongfeng chassis suction/septic tank truck currently lists about 7 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Huatong Dongfeng chassis suction/septic tank truck?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
