Dongfeng ISZ500 51 500 hp 13L China V Diesel Engine
EXW
Export quote
Dongfeng ISZ13 Series engine
Main model photos
27 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Dongfeng ISZ500 51 500 hp 13L China V Diesel Engine | 500hp / China V | ||
| Dongfeng ISZ560 51 560 hp 13L China V Diesel Engine | 560hp / China V | ||
| Dongfeng ISZ520 51 520 hp 13L China V Diesel Engine | 520hp / China V | ||
| Dongfeng ISZ480 51 480 hp 13L China V Diesel Engine | 480hp / China V | ||
| Dongfeng ISZ460 51 460 hp 13L China V Diesel Engine | 460hp / China V |
Dongfeng ISZ560 51 560 hp 13L China V Diesel Engine
EXW
Export quote
Dongfeng ISZ520 51 520 hp 13L China V Diesel Engine
EXW
Export quote
Dongfeng ISZ480 51 480 hp 13L China V Diesel Engine
EXW
Export quote
Dongfeng ISZ460 51 460 hp 13L China V Diesel Engine
EXW
Export quote
Series Specs
Engine parameters
Engine Series: ISZ13 series
Engine manufacturer: Dongfeng Engine Co., Ltd. / Dongfeng
Suitable Range: Tractor Trucks / Truck engine / Trucks
Intake type: Turbocharged Air-to-Air Intercooling / Air-to-air intercooled
Min. fuel consumption at full load: 186g/kW.h
Engine Dimensions: 1367x982x1213 / 1.389x1.016x1.233 / 1389×1016×1233mm
Compression ratio: 17：1 / 17.3：1 / 17:1
Bore × Stroke: 130x163mm
Valves per cylinder: 4pcs
firing order: 1-5-3-6-2-4
Engine Brand: Dongfeng
Engine Model: ISZ500 51 / ISZ560 51 / ISZ520 51 / ISZ480 51 / ISZ460 51 / ISZ430 51 / ISZ520 41 / ISZ480 41 / ISZ425 41 / ISZ480 50 / ISZ450 41 / ISZ425 50 / ISZ525 40 / ISZ450 40
Number of cylinders: 6cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 13 / 12.972 / 13.2L
Emission standard: China V / China IV
Max output power: 368 / 412 / 382 / 353 / 338 / 316 / 312 / 358 / 331 / 317 / 392 / 335kW
Max hp: 500 / 560 / 520 / 480 / 460 / 430 / 425 / 450 / 525Horsepower
Max torque: 2460 / 2500 / 2330 / 2000 / 2458 / 2321 / 2016 / 2320 / 2238 / 2508 / 2237N·m
Max torque speed: 1100-1300 / 1000-1400 / 1100-1400 / 1000-1300 / 1200 / 1400rpm
Rated speed: 1900 / 2100rpm
Engine Type: SCR / turbocharged intercooled air-to-air
FAQ
What kind of truck is Dongfeng Dongfeng ISZ13 Series engine?
Dongfeng Dongfeng ISZ13 Series is an export-oriented engine lineup with about 14 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does Dongfeng ISZ13 Series engine cover?
Dongfeng ISZ13 Series engine mainly covers: Horsepower: 460 hp / 480 hp / 500 hp / 520 hp / 560 hp; Emission: China V; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Dongfeng ISZ13 Series engine?
For Dongfeng ISZ13 Series engine, choose in order: emission → drive → horsepower/fuel → compare price and photos → open a model to quote. Include port and quantity.
What is engine typically used for?
For engine, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does Dongfeng ISZ13 Series engine include?
Dongfeng ISZ13 Series engine currently lists about 14 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Dongfeng ISZ13 Series engine?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
