JMC Shunda Narrow Body 116hp 4X2(6 wheels) 4.21m Explosive Transport Truck (Hongyu Brand)
EXW
From $12,056
Export quote
Zhengzhou Hongyu JMC Chassis Explosives Transport
Main model photos
10 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| JMC Shunda Narrow Body 116hp 4X2(6 wheels) 4.21m Explosive Transport Truck (Hongyu Brand) | 4x2 / 116hp / China V | From $12,056 | |
| JMC Shunda Narrow Body 116hp 4X2(6 wheels) 4.2m flammable liquid van truck (Hongyu brand) | 4x2 / 116hp / China V | From $12,056 | |
| JMC Shunda Narrow Body 116hp 4X2(6 wheels) 4.2m Flammable Gas Van Truck (Hongyu Brand) | 4x2 / 116hp / China V | From $12,056 | |
| JMC Shunda Narrow Body 116hp 4X2(6 wheels) 4.2m Flammable Solid Van Truck (Hongyu Brand) | 4x2 / 116hp / China V | From $12,056 | |
| JMC Shunda Narrow Body 116hp 4X2(6 wheels) 4.2m Explosive Material Transport Truck (Hongyu Brand) | 4x2 / 116hp / China V | From $12,056 |
JMC Shunda Narrow Body 116hp 4X2(6 wheels) 4.2m flammable liquid van truck (Hongyu brand)
EXW
From $12,056
Export quote
JMC Shunda Narrow Body 116hp 4X2(6 wheels) 4.2m Flammable Gas Van Truck (Hongyu Brand)
EXW
From $12,056
Export quote
JMC Shunda Narrow Body 116hp 4X2(6 wheels) 4.2m Flammable Solid Van Truck (Hongyu Brand)
EXW
From $12,056
Export quote
JMC Shunda Narrow Body 116hp 4X2(6 wheels) 4.2m Explosive Material Transport Truck (Hongyu Brand)
EXW
From $12,056
Export quote
Series Specs
Basic Info
Cab dimensions: 5.995×1.95×2.79 / 5.995×1.95×2.72 / 4.89×1.94×2.78m
Type: Explosives Transport Truck / Flammable liquid van truck / Flammable gas van truck / flammable solid van truck
Drive type: 4X2
Wheelbase: 3360 / 2490mm
Front/rear track width: Front: 1385mm; Rear: 1425 / Front track: 1385mm; Rear track: 1425
Rated mass: 1.495 / 1.497 / 1.4ton
GVWR: 4.495 / 4.19ton
Max. speed: 80km/h
Front/rear suspension: 1.065/1.57 / 1.065/1.335m
Energy Type: Diesel
Body Parameters
rear guard section size: 100×50 / 100×60mm
Transport medium: Black powder, compressed black powder, electric (non-electric) detonators, blasting explosives, detonating cord, igniting fuse
Vehicle certification code: HYJ5040XQYB6 / HYJ5040XRYB3 / HYJ5040XRQB3 / HYJ5040XRGB3 / HYJ5040XQYB5
Body Brand: Hongyu brand
Engine parameters
Engine Brand: JMC
Engine Model: Nanchang JMC JX493ZLQ5
Number of cylinders: 4cylinder
Displacement: 2.771L
Emission standard: China V
Max output power: 85kW
Max hp: 116Horsepower
Max torque: 285N·m
Max torque speed: 1800-2200rpm
Rated speed: 3200rpm
Cargo box parameters
Cargo box dimensions: 4.21×1.805×1.73 / 4.210×1.805×1.73 / 3.01×1.805×1.73m
Chassis Specs
Chassis Brand: JMC
Chassis Series: Shunda Narrow Body
Chassis Model: JX1041TG25
rear axle description: Ratio 6.142
Leaf spring count: 7/4+6
Transmission Parameters
Number of gears: 5Gear
Transmission Model: Jiangchi JC528 / Jiangchi JC528T8
Tire
Tire Size: 7.00R16LT 8PR
Number of tires: 6pcs
FAQ
What kind of truck is Zhengzhou Hongyu Zhengzhou Hongyu JMC Chassis Explosives Transport Truck?
Zhengzhou Hongyu Zhengzhou Hongyu JMC Chassis is an export-oriented Explosives Transport Truck lineup with about 6 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Zhengzhou Hongyu JMC Chassis Explosives Transport?
Zhengzhou Hongyu JMC Chassis Explosives Transport export reference is about From $12,056. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Zhengzhou Hongyu JMC Chassis Explosives Transport cover?
Zhengzhou Hongyu JMC Chassis Explosives Transport mainly covers: Drive: 4x2; Horsepower: 116 hp; Emission: China V; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Zhengzhou Hongyu JMC Chassis Explosives Transport?
For Zhengzhou Hongyu JMC Chassis Explosives Transport: define the job and emission first, compare key drive/power options, then open the matching model for special equipment and quote.
What is Explosives Transport Truck typically used for?
Explosives Transport Truck specs vary widely by job. Define the application first, then compare specs here and request a quote.
How many models does Zhengzhou Hongyu JMC Chassis Explosives Transport include?
Zhengzhou Hongyu JMC Chassis Explosives Transport currently lists about 6 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Zhengzhou Hongyu JMC Chassis Explosives Transport?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
