FAW Jiefang J6P 320hp 8X4(12 wheels) Fuel Tank Truck (Xingshi Brand)
EXW
Export quote
Suizhou Lishen FAW Jiefang chassis fuel tanker truck
Main model photos
57 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| FAW Jiefang J6P 320hp 8X4(12 wheels) Fuel Tank Truck (Xingshi Brand) | 8x4 / 320hp / China V | ||
| FAW Jiefang J6P 350 hp 6X4(10 wheels) Fuel Tank Truck (Xingshi brand) | 6x4 / 350hp / China V | From $46,361 | |
| FAW Jiefang J6M 260hp 6X4(10 wheels) Refueling Truck (Xingshi Brand) | 6x4 / 260hp / China V | From $40,611 | |
| FAW Jiefang J6M 260hp 6X4(10 wheels) Refueling Truck (Xingshi Brand) (9-speed) | 6x4 / 260hp / China V | From $40,611 | |
| FAW Jiefang J6L 220hp 6X2(8 wheels) Fuel Tank Truck (Xingshi Brand) | 6x2 / 220hp / China V | From $30,347 |
FAW Jiefang J6P 350 hp 6X4(10 wheels) Fuel Tank Truck (Xingshi brand)
EXW
From $46,361
Export quote
FAW Jiefang J6M 260hp 6X4(10 wheels) Refueling Truck (Xingshi Brand)
EXW
From $40,611
Export quote
FAW Jiefang J6M 260hp 6X4(10 wheels) Refueling Truck (Xingshi Brand) (9-speed)
EXW
From $40,611
Export quote
FAW Jiefang J6L 220hp 6X2(8 wheels) Fuel Tank Truck (Xingshi Brand)
EXW
From $30,347
Export quote
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| FAW Jiefang J6P 320hp 8X4(12 wheels) Fuel Tank Truck (Xingshi Brand) | 8x4 / 320hp / China V | ||
| FAW Jiefang J6P 320hp 8X4(12 wheels) Fuel Tank Truck (Xingshi Brand) | 8x4 / 320hp / China V | ||
| FAW Jiefang J6P 280hp 8X2(10 wheels) Oil Tanker Truck (Xingshi Brand) | 8x2 / 280hp / China V | ||
| FAW Jiefang J6 260 hp 6X2(8 wheels) Oil Tank Truck (Xingshi Brand) | 6x2 / 260hp / China III / Euro III |
FAW Jiefang J6P 320hp 8X4(12 wheels) Fuel Tank Truck (Xingshi Brand)
EXW
Export quote
FAW Jiefang J6P 320hp 8X4(12 wheels) Fuel Tank Truck (Xingshi Brand)
EXW
Export quote
FAW Jiefang J6P 280hp 8X2(10 wheels) Oil Tanker Truck (Xingshi Brand)
EXW
Export quote
FAW Jiefang J6 260 hp 6X2(8 wheels) Oil Tank Truck (Xingshi Brand)
EXW
Export quote
Series Specs
Basic Info
Cab dimensions: 1.181×2.5×3.505 / 9.3×2.55×3.35 / 9.7×2.5×3.3 / 10.2×2.5×3.35 / 10.15×2.5×3.3 / 10.35×2.5×3.3 / 8.45×2.5×3.25 / 8.5×2.5×3.25 / 11.53×2.55×3.68 / 10.15×2.5×3.33 / 10.2×2.55×3.4 / 11.81×2.5×3.505 / 11.9×2.5×3.505 / 11.8×2.5×3.505 / 11.72×2.5×3.505 / 8.45×2.5×3.1 / 8.45×2.5×3.2 / 11.0×2.5×3.25m
Truck Type: Fuel tanker truck
Drive type: 8X4 / 6X4 / 6X2 / 4X2 / 8X2
Wheelbase: 1950+4550+1350 / 4300+1350 / 4800+1350 / 1900+4700 / 4700 / 2100+4000+1350 / 1950+4250+1350 / 5800 / 1950+5150mm
Vehicle origin: Suizhou, Hubei
Front track width: 1987/1987 / 2057 / 1987 / 1890/1890 / 1890 / 1950/1950mm
rear track: 1860/1860 / 1878/1878 / 1880/1880 / 1847 / 1860 / 1900/1900 / 1847/1847 / 1946/1847mm
Curb Weight: 10.805 / 13.205 / 11.805 / 9.805 / 8.465 / 10.325 / 8.105 / 6.705 / 11.605 / 11.505 / 7.805 / 7.81ton
Rated payload: 21 / 11.6 / 13.065 / 15 / 15.86 / 14 / 9.7 / 11.1 / 20.2 / 16 / 19.3 / 20 / 10 / 7.995ton
Max. speed: 79 / 90km/h
Front/rear suspension: 1.46/2.5 / 1.47/2.18 / 1.46/2.59 / 1.4/2.35 / 1.4/2.4 / 1.46/2.62 / 1.46/2.54 / 1.46/2.49 / 1.46/2.71 / 1.4/2.5m
Energy Type: Diesel
Body Parameters
Tank Size: 6.4×2.25×1.55 / 6.9×2.3×1.6 / 7.4×2.35×1.65 / 7×2.3×1.6 / 7.3×2.3×1.6 / 5.7×2.15×1.5 / 5.75×2.15×1.5 / 8.6×2.25×1.55 / 7.13×2.3×1.6 / 7.4×2.4×1.7 / 8.7×2.35×1.65 / 9×2.47×1.77 / 9×2.4×1.7 / 8.8×2.47×1.77 / 5.75×2×1.4 / 5.55×2.15×1.5 / 8×2.4×1.63m
Tank Volume: 26.5 / 17.4 / 19.4 / 22.4 / 20 / 21 / 14.5 / 14.6 / 23.7 / 20.2 / 24 / 31 / 28.9 / 29.9 / 12.6 / 11.98m3
Transport medium: gasoline / Diesel, kerosene, gasoline / gasoline, kerosene, diesel
Medium Density: 0.7 / 0.75 / 0.71ton/cubic meter
Vehicle certification code: SLS5320GYYC5A / SLS5250GYYC5Q / SLS5250GJYC5 / SLS5250GJYC5A / SLS5253GJYC5A / SLS5253GJYC5 / SLS5180GJYC5 / SLS5180GYYC5 / SLS5320GYYC5F / SLS5261GYYC5 / SLS5260GYYC5 / SLS5320GYYC5 / SLS5311GYYC5 / SLS5310GYYC5T / SLS5181GJYC5 / SLS5160GYYC5 / SLS5254GYYC
Body Brand: Xingshi Brand
Others: Optional flat-top cab as per chassis; when flat-top cab is selected, overall vehicle height is 3250 mm. Guard materials are Q235 steel plate; side guard bolted, rear guard welded; rear guard section height 100 mm, width 50 mm, ground clearance 540 mm.
Engine parameters
Engine Brand: Dachai / Xichai
Engine Model: DachaiCA6DK1-32E51 / XichaiCA6DL2-35E5 / DachaiCA6DK1-26E5 / DachaiCA4DK1-22E51 / DachaiCA4DK1-18E51 / XichaiCA6DM2-39E51 / DachaiCA6DK1-28E51 / DachaiCA6DK1-26E51 / DachaiCA6DK1-28E5 / DachaiCA6DK1-32E5 / Xichai CA6DL1-26E3
Number of cylinders: 6 / 4cylinder
Displacement: 7.146 / 8.57 / 4.764 / 11.05 / 7.7L
Emission standard: China V / China III / Euro III
Max output power: 239 / 261 / 195 / 165 / 139 / 287 / 209kW
Max hp: 320 / 350 / 260 / 220 / 180 / 390 / 280Horsepower
Max torque: 1200 / 1500 / 1050 / 820 / 720 / 1750 / 1100N·m
Max torque speed: 1200-1700 / 1300-1470 / 1300-1400 / 1300-1700rpm
Rated speed: 2300 / 2100 / 1900rpm
Engine Type: 6-cylinder inline, direct injection, turbocharged intercooled, electronic common rail / Inline, 4-stroke, water-cooled, 4-valve, turbocharged intercooled / Electronically controlled / Inline
Chassis Specs
Chassis Brand: FAW Jiefang
Chassis Series: FAW JiefangJ6P / FAW JiefangJ6M / FAW JiefangJ6L / FAW Jiefang J6
Chassis Model: CA5320GYYP63K1L6T4E5 / CA5250GYYP66K2L2T1E5 / CA5250GYYP63K1L3T1E5 / CA5250GYYP62K1L6T3E5 / CA5180GYYP62K1L5E5 / CA5260GYYP63K1L3T1E5 / CA5310GYYP63K1L6T4E5 / CA5310GYYP63K1L6T10E5 / CA5160GYYP62K1L3E5 / CA1250P63K2L6T3HE
Front axle description: 2020 / 1950 / 1800
Frame Dimensions: 300×80×(8+8+5) / 270×75×(7+5) / 237×75×(7+4) / 300×80×8mm
rear axle description: Φ300 cast wheel reduction axle / Ф435 stamped-welded axle / 435 stamped-welded axle
Axle ratio: 5.263 / 4.875 / 5.143 / 4.111 / 4.333 / 4.444 / 5.571
Transmission Parameters
Number of gears: 9 / 10 / 6 / 12Gear
Transmission Model: FAWCA9TB / FAWCA10TA160M2 / FAWCA9TB160M / FAWCA6T138 / FAWCA12TAX210M / FAWCA10TA / FAWCA6TBX085M / FAWCA6TBX075M
Cab parameters
Cab: J6P full-floating flat roof small row-half / J6M Semi-Float Flat Roof Small Day Cab / J6L Semi-floating Flat Roof Short Extended Cab / 2017 Model J6L Semi-Float Flat-Roof Small Half-Row Cab
FAQ
What kind of truck is Suizhou Lishen Suizhou Lishen FAW Jiefang chassis fuel tanker truck?
Suizhou Lishen Suizhou Lishen FAW Jiefang chassis is an export-oriented fuel tanker truck lineup with about 19 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Suizhou Lishen FAW Jiefang chassis fuel tanker truck?
Suizhou Lishen FAW Jiefang chassis fuel tanker truck export reference is about $22,222 – $48,333. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Suizhou Lishen FAW Jiefang chassis fuel tanker truck cover?
Suizhou Lishen FAW Jiefang chassis fuel tanker truck mainly covers: Drive: 6x2 / 6x4 / 8x2 / 8x4; Horsepower: 220 hp / 260 hp / 280 hp / 320 hp / 350 hp; Emission: China III / Euro III / China V; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Suizhou Lishen FAW Jiefang chassis fuel tanker truck?
For Suizhou Lishen FAW Jiefang chassis fuel tanker truck: define the job and emission first, compare key drive/power options, then open the matching model for special equipment and quote.
What is fuel tanker truck typically used for?
fuel tanker truck specs vary widely by job. Define the application first, then compare specs here and request a quote.
How many models does Suizhou Lishen FAW Jiefang chassis fuel tanker truck include?
Suizhou Lishen FAW Jiefang chassis fuel tanker truck currently lists about 19 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Suizhou Lishen FAW Jiefang chassis fuel tanker truck?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
