Dongfeng Furui R5 170 hp 4X2(6 wheels) Cleaning and Suction Truck (Zhongjie Brand)
EXW
From $30,861
Export quote
Xinzhonglv (Zhongjie) Dongfeng Chassis
Main model photos
75 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Dongfeng Furui R5 170 hp 4X2(6 wheels) Cleaning and Suction Truck (Zhongjie Brand) | 4x2 / 170hp / China VI | From $30,861 | |
| Dongfeng Furui R5 165 hp 4X2(6 wheels) Cleaning and Suction Truck (Zhongjie Brand) | 4x2 / 165hp / China VI | From $29,389 | |
| Dongfeng Furui R5 163 hp 4X2(6 wheels) Cleaning and Suction Truck (Zhongjie Brand) | 4x2 / 163hp / China VI | From $29,569 | |
| Dongfeng Furui R5 170 hp 4X2(6 wheels) Cleaning and Suction Truck (7-speed) (Zhongjie Brand) | 4x2 / 170hp / China VI | From $29,681 | |
| Dongfeng Furui R5 170 hp 4X2(6 wheels) Cleaning and Suction Truck (Zhongjie Brand) | 4x2 / 170hp / China VI | From $28,528 |
Dongfeng Furui R5 165 hp 4X2(6 wheels) Cleaning and Suction Truck (Zhongjie Brand)
EXW
From $29,389
Export quote
Dongfeng Furui R5 163 hp 4X2(6 wheels) Cleaning and Suction Truck (Zhongjie Brand)
EXW
From $29,569
Export quote
Dongfeng Furui R5 170 hp 4X2(6 wheels) Cleaning and Suction Truck (7-speed) (Zhongjie Brand)
EXW
From $29,681
Export quote
Dongfeng Furui R5 170 hp 4X2(6 wheels) Cleaning and Suction Truck (Zhongjie Brand)
EXW
From $28,528
Export quote
Series Specs
Basic Info
Cab dimensions: 6.8×2.35×2.96 / 5.95×2×2.5 / 5.85×1.97×2.5 / 6.55×2.18×2.9 / 5.85×1.98×2.55m
Type: cleaning and suction truck / suction sewage truck
Drive type: 4X2
Wheelbase: 3800 / 3308mm
Front/rear track width: Front: 1745mm; Rear: 1630 / Front: 1525mm; Rear: 1498
Rated mass: 5.1 / 2.35 / 1.435 / 3.5 / 1.495 / 5.4 / 2.8ton
GVWR: 11.995 / 7.36 / 4.495ton
Front/rear suspension: 1.13/1.87 / 1.055/1.587 / 1.055/1.487 / 1.055/1.495 / 1.13/1.62m
Energy Type: Diesel
Body Parameters
Tank Size: 4.2×1.4 / 3.4×1.2 / 2.8×1.2 / 3.6×1.65×1.2 / 3.6×1.3×0.62 / 3.8×1.5 / 3×1.3 / 2.8×1m
Tank Volume: 1.05 / 3.08 / 1.88 / 4.59 / 1.96 / 7 / 3.67m3
Transport medium: Liquid pollutants / fecal water
Medium Density: 0.8ton/cubic meter
Vehicle certification code: XZL5120GQW6 / XZL5070GQW6 / XZL5040GQW6 / XZL5070GXE6 / XZL5040GXE6 / XZL5120GXW6 / XZL5070GXW6 / XZL5040GXW6
Body Brand: Zhongjie brand / Zhongjie
Engine parameters
Engine Model: DongfengD4.0NS6B170 / YuchaiYCY30165-60 / ChaochaiNV30-C6C / ChaochaiCY4SK261 / ChaochaiCY4SK361 / YuchaiYCY24140-60 / ChaochaiCY4BK461 / QuanchaiH20-120E60 / QuanchaiQ23-115E60
Displacement: 4 / 2.97 / 3.093 / 3.856 / 2.36 / 3.707 / 2 / 2.3L
Emission standard: China VI
Max output power: 125 / 121 / 120 / 103 / 95 / 90 / 85kW
Max hp: 170 / 165 / 163 / 140 / 129 / 120 / 115Horsepower
Rated speed: 2400 / 2800 / 2500 / 2950 / 2600 / 3200 / 3000rpm
Chassis Specs
Chassis Brand: Dongfeng
Chassis Series: Forica R5
Chassis Model: EQ1125SJ8CDC / EQ1075SJ3CDF / EQ1045SJ3CDF
rear axle description: 7T / 5.5T / 3.5T
Leaf spring count: 8/10+7,12/12+9 / 6/6+5,3/3+3 / 6/6+5,3/3+3,2/3+2
Transmission Parameters
Number of gears: 8 / 6 / 7 / 5Gear
Transmission Model: Fast Gear8JS75 / WLYWLY6TS55 / WLYWLY7TS60 / WLYWLY6GT40 / WLYWLY5TS40 / WLYWLY5GT32 / WLYWLY6GT4
Tire
Tire Size: 245/70R19.5,8.25R20 / 7.00R16 / 8.25R20 / 245/70R19.5
Number of tires: 6pcs
FAQ
What kind of truck is Xinzhonglv (Zhongjie) Xinzhonglv (Zhongjie) Dongfeng Chassis suction/septic tank truck?
Xinzhonglv (Zhongjie) Xinzhonglv (Zhongjie) Dongfeng Chassis is an export-oriented suction/septic tank truck lineup with about 27 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Xinzhonglv (Zhongjie) Dongfeng Chassis?
Xinzhonglv (Zhongjie) Dongfeng Chassis export reference is about $16,500 – $30,861. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Xinzhonglv (Zhongjie) Dongfeng Chassis cover?
Xinzhonglv (Zhongjie) Dongfeng Chassis mainly covers: Drive: 4x2; Horsepower: 163 hp / 165 hp / 170 hp; Emission: China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Xinzhonglv (Zhongjie) Dongfeng Chassis?
For Xinzhonglv (Zhongjie) Dongfeng Chassis: define the job and emission first, compare key drive/power options, then open the matching model for special equipment and quote.
What is suction/septic tank truck typically used for?
suction/septic tank truck specs vary widely by job. Define the application first, then compare specs here and request a quote.
How many models does Xinzhonglv (Zhongjie) Dongfeng Chassis include?
Xinzhonglv (Zhongjie) Dongfeng Chassis currently lists about 27 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Xinzhonglv (Zhongjie) Dongfeng Chassis?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
