Huayuan Laidong 4J30F 122hp 3L China IV Diesel Engine
EXW
Export quote
Huayuan Laidong China IV Series engine
Main model photos
1 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Huayuan Laidong 4J30F 122hp 3L China IV Diesel Engine | 122hp / China IV | ||
| Huayuan Laidong 4J28F 95hp 2.77L China IV Diesel Engine | 95hp / China IV | ||
| Huayuan Laidong K10 57hp 1L China IV Diesel Engine | 57hp / China IV | ||
| Huayuan Laidong 4K28F 95 hp 2.77L China IV Diesel Engine | 95hp / China IV | ||
| Huayuan Laidong 4L22CF 82 hp 2.16L China IV Diesel Engine | 82hp / China IV |
Huayuan Laidong 4J28F 95hp 2.77L China IV Diesel Engine
EXW
Export quote
Huayuan Laidong K10 57hp 1L China IV Diesel Engine
EXW
Export quote
Huayuan Laidong 4K28F 95 hp 2.77L China IV Diesel Engine
EXW
Export quote
Huayuan Laidong 4L22CF 82 hp 2.16L China IV Diesel Engine
EXW
Export quote
Series Specs
Engine parameters
Engine Series: China IV series
Engine manufacturer: Shandong Huayuan Laidong Internal Combustion Engine Co., Ltd.
Suitable Range: light truck, mini truck
Intake type: Turbocharged Air-to-Air Intercooling
Min. fuel consumption at full load: 215 / 220 / ≤210g/kW.h
Engine net weight: 242 / 290 / 120 / 255 / 140kg
Engine Dimensions: 840x658x720 / 781x627x740 / 536x610x662 / 800x620x660 / 567.5x559x636mm
Bore × Stroke: 96x105 / 93x102 / 76x80.5 / 85x95mm
Valves per cylinder: 2 / 4pcs
Engine Brand: Huayuan Laidong
Engine Model: 4J30F / 4J28F / K10 / 4K28F / 4L22CF / K15
Number of cylinders: 4 / 3cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 3.04 / 2.774 / 1.095 / 2.156 / 1.461L
Emission standard: China IV
Max output power: 90 / 70 / 42 / 60 / 52kW
Max hp: 122 / 95 / 57 / 82 / 71Horsepower
Max torque: 300 / 225 / 130 / 206 / 180N·m
Max torque speed: 2200 / 1600-2400 / 1800-2400 / 1600-2600 / 1800-2200rpm
Rated speed: 3200 / 3600rpm
Engine Type: Direct injection high-pressure common rail, turbocharged & intercooled, EGR (intercooled), aftertreatment (DOC) / Vertical, inline, water-cooled, four-stroke, direct injection, turbocharged intercooled
FAQ
What kind of truck is Huayuan Laidong Huayuan Laidong China IV Series engine?
Huayuan Laidong Huayuan Laidong China IV Series is an export-oriented engine lineup with about 6 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does Huayuan Laidong China IV Series engine cover?
Huayuan Laidong China IV Series engine mainly covers: Horsepower: 57 hp / 82 hp / 95 hp / 122 hp; Emission: China IV; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Huayuan Laidong China IV Series engine?
For Huayuan Laidong China IV Series engine, choose in order: emission → drive → horsepower/fuel → compare price and photos → open a model to quote. Include port and quantity.
What is engine typically used for?
For engine, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does Huayuan Laidong China IV Series engine include?
Huayuan Laidong China IV Series engine currently lists about 6 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Huayuan Laidong China IV Series engine?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
