SANY C8 8X4(12 wheels) 7.13m³ Electric Concrete Mixer Truck
EXW
From $148,611
Export quote
SANY Heavy Industry C series concrete mixer truck
Main model photos
50 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| SANY C8 8X4(12 wheels) 7.13m³ Electric Concrete Mixer Truck | 8x4 | From $148,611 | |
| SANY C8 8X4(12 wheels) 7.73m³ Electric Concrete Mixer Truck | 8x4 | From $127,778 | |
| SANY Group C8 8X4(12 wheels) 6.95m³ Pure Electric Concrete Mixer Truck | 8x4 | From $150,000 | |
| SANY Heavy Industry C8 290hp 8X4(12 wheels) 7.99m³ Concrete Mixer Truck | 8x4 / 290hp / China V | ||
| SANY Heavy Industry C8 336hp 8X4(12 wheels) 6.5m³ Concrete Mixer Truck | 8x4 / 336hp / China V |
SANY C8 8X4(12 wheels) 7.73m³ Electric Concrete Mixer Truck
EXW
From $127,778
Export quote
SANY Group C8 8X4(12 wheels) 6.95m³ Pure Electric Concrete Mixer Truck
EXW
From $150,000
Export quote
SANY Heavy Industry C8 290hp 8X4(12 wheels) 7.99m³ Concrete Mixer Truck
EXW
Export quote
SANY Heavy Industry C8 336hp 8X4(12 wheels) 6.5m³ Concrete Mixer Truck
EXW
Export quote
Series Specs
Basic Info
Cab dimensions: 10.255×2.53×3.98 / 9.65x2.53x3.85 / 10.29X2.53X3.98 / 9.7×2.5×3.98 / 10.3×2.49×3.985 / 11.08×2.49×3.985m
Truck Type: concrete mixer truck
Drive type: 8X4
Wheelbase: 1700+3450+1350 / 1700+3150+1350 / 1700+3200+1300 / 1700+3200+1350mm
Front/rear track width: Front: 2043/2043mm; Rear: 1860/1860 / Front track: 1987mm; Rear track: 1860/1860 / Front track: 2048/2048mm; Rear track: 1860/1860
Vehicle origin: Changsha, Hunan
Curb Weight: 15.3 / 14 / 15.7 / 13.2 / 16.6 / 17.8ton
Rated payload: 15.57 / 16.87 / 15.17 / 17.67 / 14.255 / 13.055ton
Max. speed: 85 / 90km/h
Front/rear suspension: 1.48/2.275 / 1.48/1.97 / 1.48/2.31 / 1.48/2.02 / 1.48/2.57 / 1.48/3.05m
electric motor
Motor 1 Brand: Fast Gear / Lv Kong
Motor 1 Model: TZ368XSSFD01 / TZ410XS-LKM2001
Motor Type: Permanent magnet synchronous motor
total rated power: 215 / 240kW
Peak power: 350 / 360kW
total rated torque: 1207 / 1000N·m
total peak torque: 2800 / 2000N·m
Body Parameters
Drum geometric volume: 10 / 8 / 12m³
Mixing drum capacity: 7.13 / 7.73 / 6.95 / 7.99 / 6.5 / 5.9m³
Vehicle certification code: SYM5310GJB3BEV / SYM5316GJB1BEV / SYM5311GJB1BEV / SYM5310GJB1E / SYM5311GJB1E / SYM5312GJB1E
Body Brand: SANY Group
Engine parameters
Injection System: Common Rail (China V)
Engine Model: YuchaiYC6A290-50 / WeichaiWP10.336E53 / Shanghai HinoP11C-WC / WeichaiWP10.350E53 / SANYD07C5-313E0
Number of cylinders: 6cylinder
fuel type: Electric / Diesel
Displacement: 7.5 / 9.726 / 10.52 / 7.41L
Emission standard: China V
Max output power: 213 / 247 / 259 / 257 / 230kW
Max hp: 290 / 336 / 350 / 313Horsepower
Rated speed: 2300 / 1900rpm
Engine Type: Vertical, inline, water-cooled, four-stroke / Water-cooled, 4-stroke, with exhaust brake, direct injection, turbocharged intercooled, electronically controlled high-pressure common rail + SCR / Electronic high-pressure common rail + SCR
Chassis Specs
Chassis Series: SANY Heavy Industry C8
Chassis Model: SYM1310T1BEV / SYM1312T1BEV / SYM1310T1E / SYM1312T1E
Front axle description: 2×5.5t
rear axle description: 2×13t
Axle ratio: 6.833 / 5.73
Leaf spring count: 4/4/- / 4/4/10 / 9/9/12
Transmission Parameters
Number of gears: 9Gear
Transmission Model: Fast Gear9JS119TA / Fast Gear9JS150TA-B
Cab parameters
Cab: CB318
FAQ
What kind of truck is SANY SANY Heavy Industry C series concrete mixer truck?
SANY SANY Heavy Industry C series is an export-oriented concrete mixer truck lineup with about 8 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for SANY Heavy Industry C series concrete mixer truck?
SANY Heavy Industry C series concrete mixer truck export reference is about $127,778 – $150,000. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does SANY Heavy Industry C series concrete mixer truck cover?
SANY Heavy Industry C series concrete mixer truck mainly covers: Drive: 8x4; Horsepower: 290 hp / 336 hp; Emission: China V; Fuel: Diesel / Electric. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in SANY Heavy Industry C series concrete mixer truck?
For SANY Heavy Industry C series concrete mixer truck: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is concrete mixer truck typically used for?
concrete mixer truck is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does SANY Heavy Industry C series concrete mixer truck include?
SANY Heavy Industry C series concrete mixer truck currently lists about 8 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for SANY Heavy Industry C series concrete mixer truck?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
