Xin Guanghua Chen XG491QMB 112 hp 2.24L China IV Gasoline Engine
EXW
Export quote
Xin Guanghua Chen XG491Q Series engine
Main model photos
1 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Xin Guanghua Chen XG491QMB 112 hp 2.24L China IV Gasoline Engine | 112hp / China IV | ||
| Xin Guanghua Chen XG491Q-ME 103 hp 2.24L China IV Gasoline Engine | 103hp / China IV |
Xin Guanghua Chen XG491Q-ME 103 hp 2.24L China IV Gasoline Engine
EXW
Export quote
Series Specs
Engine parameters
Engine Series: XG491Q series
Engine manufacturer: Shenyang Xin Guanghua Chen Automotive Engine Co., Ltd. / Xin Guanghua Chen
Suitable Range: Pickup, light truck
Intake type: Naturally aspirated
Min. fuel consumption at full load: 210 / 270g/kW.h
Engine Dimensions: 651x685x751mm
Compression ratio: 16.7:1 / 9:1
Bore × Stroke: 83.1x92 / 91X86mm
Valves per cylinder: 8pcs
Engine Brand: Xin Guanghua Chen
Engine Model: XG491QMB / Xin Guanghua Chen XG491Q-ME
Number of cylinders: 4cylinder
fuel type: Diesel / gasoline
Cylinder arrangement: Inline
Displacement: 2.237L
Emission standard: China IV
Max output power: 82 / 76kW
Max hp: 112 / 103Horsepower
Max torque: 200 / 193N·m
Max torque speed: 2300-2800 / 2600-3200rpm
Rated speed: 4600rpm
Engine Type: 4-cylinder, inline, water-cooled, overhead valve, 4-stroke gasoline engine / Inline 4-cylinder, 4-stroke, water-cooled, naturally aspirated, side-mounted camshaft, 8-valve
FAQ
What kind of truck is Xin Guanghua Chen Xin Guanghua Chen XG491Q Series engine?
Xin Guanghua Chen Xin Guanghua Chen XG491Q Series is an export-oriented engine lineup with about 2 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does Xin Guanghua Chen XG491Q Series engine cover?
Xin Guanghua Chen XG491Q Series engine mainly covers: Horsepower: 103 hp / 112 hp; Emission: China IV; Fuel: Diesel / gasoline. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Xin Guanghua Chen XG491Q Series engine?
For Xin Guanghua Chen XG491Q Series engine, choose in order: emission → drive → horsepower/fuel → compare price and photos → open a model to quote. Include port and quantity.
What is engine typically used for?
For engine, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does Xin Guanghua Chen XG491Q Series engine include?
Xin Guanghua Chen XG491Q Series engine currently lists about 2 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Xin Guanghua Chen XG491Q Series engine?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
