Xichai 4DX23S-140E5 140hp 3.86L China V Diesel Engine
EXW
Export quote
Xichai Kangwei 4DX Series engine
Main model photos
12 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Xichai 4DX23S-140E5 140hp 3.86L China V Diesel Engine | 140hp / China V | ||
| Xichai 4DX23-120E5 120hp 3.86L China V Diesel Engine | 120hp / China V | ||
| Xichai 4DX23-130E5 130hp 3.86L China V Diesel Engine | 130hp / China V | ||
| Xichai 4DX23-140E5 140hp 3.86L China V diesel engine | 140hp / China V | ||
| Xichai 4DX23-120E4R 120hp 3.86L China IV diesel engine | 120hp / China IV |
Xichai 4DX23-120E5 120hp 3.86L China V Diesel Engine
EXW
Export quote
Xichai 4DX23-130E5 130hp 3.86L China V Diesel Engine
EXW
Export quote
Xichai 4DX23-140E5 140hp 3.86L China V diesel engine
EXW
Export quote
Xichai 4DX23-120E4R 120hp 3.86L China IV diesel engine
EXW
Export quote
Series Specs
Engine parameters
Engine Series: Kangwei 4DX Series
Engine manufacturer: Xichai / FAW Jiefang Automobile Co., Ltd. without Xichai engine plant / FAWXichai
Suitable Range: Ideal power for 6-7m intercity, tourist, and urban small/medium buses, light trucks / 8–10m highway, tourist and city midibuses, medium cargo truck / 6~7m highway, tourism and city mid-small bus, light-duty cargo truck / Ideal power for 6-7m intercity, tourist, and urban small/medium buses, light cargo trucks
Intake type: Turbocharged Air-to-Air Intercooling / Turbocharged / Naturally aspirated
Min. fuel consumption at full load: ≤205 / 200 / 205 / 215 / ≤215 / ≤220 / 225 / ≤235 / ≤225g/kW.h
Engine net weight: 620 / 380 / 340 / 330 / 320 / 310kg
Engine Dimensions: 955×820×960 / 795×680×825mm
noise at 1m: 94 / 95.5 / ≤96.5 / 96.5dB
Bore × Stroke: 102x118 / 110 × 135 / 100x118 / 100x100mm
Valves per cylinder: 4 / 2pcs
Engine Brand: Xichai
Engine Model: 4DX23S-140E5 / 4DX23-120E5 / 4DX23-130E5 / 4DX23-140E5 / 4DX23-120E4R / CA4DX23-120E4 / 4DX23-110E4 / 4DX23-100E4 / 4DX23-140E4 / 4DX23-130E4 / 4DX23-120E4 / 4DX23B-130E3 / 4DX23-120E3F / 4DX23-110E3F / 4DX23-100E3F / 4DX13-120E3 / 4DX13-110E3 / 4DX13-100E3 / 4DX23-130E3 / 4DX23-120E3 / 4DX23-110E3 / 4DX23-130 / 4DX23-110 / 4DX13-104 / 4DX22-110 / 4DX22-104 / 4DX12-96 / 4DX21-96 / 4DX11-90 / 4DX11-80 / 4DX13-96NG2 / 4DX12-94NG2 / 4DX11-90NG2
Number of cylinders: 4cylinder
fuel type: Diesel / gasoline
Cylinder arrangement: Inline
Displacement: 3.857 / 3.86 / 3.707 / 3.142 / 3.856 / 3.705L
Emission standard: China V / China IV / China III / Euro III / China II/Euro II
Max output power: 105 / 90 / 97.5 / 88 / 83 / 76 / 106 / 99 / 91 / 78 / 95.5 / 101 / 84 / 78.5 / 86 / 72.6 / 70.6 / 66.2 / 58.8 / 69 / 60kW
Max hp: 140 / 120 / 130 / 110 / 100 / 104 / 96 / 90 / 80 / 94Horsepower
Max torque: 450 / 380 / 410 / 343 / 324 / 296 / 285 / 323 / 300 / 245 / 225 / 201 / 260 / 261N·m
Max torque speed: 1600-2000 / 1800-2000 / 1300-1700 / 1800 / 1900 / 2000 / 2000-2200 / 1900-2100rpm
Rated speed: 2800 / 2300 / 3000 / 3200 / 2900rpm
Engine Type: 4-cylinder inline, direct injection, turbocharged & intercooled, electronic common rail / 4-cylinder inline, direct injection, turbocharged intercooled, inline pump + EGR / 4-cylinder, inline, direct injection, turbocharged, intercooled, electronic unit pump / 4-cylinder, inline, direct injection, turbocharged, intercooled / 4-cylinder inline direct injection turbocharged / 4-cylinder, inline, direct injection, naturally aspirated / 4-cylinder inline water-cooled turbocharged intercooled / 4-cylinder inline water-cooled turbocharged / 4-cylinder inline water-cooled naturally aspirated
FAQ
What kind of truck is Xichai Xichai Kangwei 4DX Series engine?
Xichai Xichai Kangwei 4DX Series is an export-oriented engine lineup with about 33 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does Xichai Kangwei 4DX Series engine cover?
Xichai Kangwei 4DX Series engine mainly covers: Horsepower: 120 hp / 130 hp / 140 hp; Emission: China IV / China V; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Xichai Kangwei 4DX Series engine?
For Xichai Kangwei 4DX Series engine, choose in order: emission → drive → horsepower/fuel → compare price and photos → open a model to quote. Include port and quantity.
What is engine typically used for?
For engine, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does Xichai Kangwei 4DX Series engine include?
Xichai Kangwei 4DX Series engine currently lists about 33 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Xichai Kangwei 4DX Series engine?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
