Foton Ollin TX 131hp 4X2(6 wheels) 4.085m Refrigerated Truck
EXW
From $20,139
Export quote
Foton TX Light Truck Refrigerated Truck
Main model photos
283 photos
Models
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Foton Ollin TX 131hp 4X2(6 wheels) 4.085m Refrigerated Truck | 4x2 / 131hp / China V | From $20,139 | |
| Foton Aoling TX 110hp 4X2(6 wheels) 4.085m refrigerated truck (Jiangchi) | 4x2 / 110hp / China V | From $22,222 | |
| Foton Aoling TX 110hp 4X2(6 wheels) 4.085m refrigerated truck (6-speed) | 4x2 / 110hp / China V | From $22,222 | |
| Foton Ollin TX 156hp 4X2(6 wheels) 4.085m Refrigerated Truck | 4x2 / 156hp / China V | ||
| Foton Ollin TX 156 hp 4X2(6 wheels) 6.7m Refrigerated Truck | 4x2 / 156hp / China V | From $19,569 |
Foton Aoling TX 110hp 4X2(6 wheels) 4.085m refrigerated truck (Jiangchi)
EXW
From $22,222
Export quote
Foton Aoling TX 110hp 4X2(6 wheels) 4.085m refrigerated truck (6-speed)
EXW
From $22,222
Export quote
Foton Ollin TX 156hp 4X2(6 wheels) 4.085m Refrigerated Truck
EXW
Export quote
Foton Ollin TX 156 hp 4X2(6 wheels) 6.7m Refrigerated Truck
EXW
From $19,569
Export quote
Series Specs
Basic Info
Cab dimensions: 5.995×2.31×3.25 / 5.995×2.05×3 / 5.995×2.2×3 / 5.995×2.16×3.3 / 8.995×2.51×3.72 / 7.445×2.2×3.28 / 7.345×2.2×3.23m
Drive type: 4X2
Truck Type: Refrigerated Truck
Wheelbase: 3360 / 4700 / 4200 / 3800mm
Vehicle origin: Beijing / Beijing Changping
Front track width: 1730 / 1710 / 1665 / 1530mm
rear track: 1615 / 1590 / 1680 / 1630 / 1485mm
Curb Weight: 3.2 / 6 / 4.995 / 5.3 / 3.7ton
Rated payload: 1.1 / 4.495 / 7.3 / 4.8 / 3.465ton
Max. speed: 95 / 100 / 110km/h
Front/rear suspension: 1.12/1.515 / 1.085/1.55 / 1.25/2.545 / 1.12/2.125 / 1.12/2.425m
Energy Type: Diesel
Engine parameters
Injection System: Common Rail
Engine Model: FotonISF2.8s5129T / Foton4J28TC3 / Yunnei PowerD30TCIE1 / FotonISF3.8s5154 / FotonISF3.8s5141
Number of cylinders: 4cylinder
Displacement: 2.78 / 2.771 / 2.977 / 3.76L
Emission standard: China V
Max output power: 96 / 81 / 115 / 105kW
Max hp: 131 / 110 / 156 / 143Horsepower
Max torque: 300 / 280 / 400 / 491 / 440N·m
Rated speed: 2900 / 3200 / 2600rpm
Engine Type: Turbocharged intercooled, Bosch high-pressure common rail, high-pressure direct injection, SCR / Inline, vertical, water-cooled / 4-cylinder inline, 16-valve, DOHC, turbocharged intercooled, high-pressure common rail fuel injection / Electronically controlled high-pressure common rail / Turbocharged Air-to-Air Intercooling Bosch High-Pressure Common Rail Direct Injection SCR
Cargo box parameters
Cargo box dimensions: 4.085×2.1×2.1 / 4.085×1.97×1.82 / 4.085×2×2.1 / 6.65×2.3×2.3 / 5.1×1.97×1.9 / 5.07×1.97×1.92m
Cargo box width: 2.1 / 1.97 / 2 / 2.3m
Cargo box height: 2.1 / 1.82 / 2.3 / 1.9 / 1.92m
Body Parameters
Vehicle certification code: BJ5048XLC-FH / BJ5049XLC-A7 / BJ5048XLC-A1 / BJ5139XLC-FA / BJ5109XLC-F1 / BJ5109XLC-A1 / BJ5079XLC-A1
Body Brand: Foton
Chassis Specs
Chassis Brand: Foton
Chassis Series: Aoling TX
Chassis Model: BJ1048V9JEA-FE / BJ1049V9JDA-A1 / BJ1048V9JDA-A1 / BJ1139VJPEK-F5 / BJ1109VFPED-F1 / BJ1109VEJEA-FB / BJ1079VDJEA-A1
Axle ratio: 4.875 / 4.33
Leaf spring count: 3/7+6 / 3+1/6+7 / 3/7+6,3/8+6 / 8/10+10 / 9/11+7
Transmission Parameters
Number of gears: 5 / 6Gear
Transmission Model: WLY5-speed / Jiangchi JC5-28 / WLYWLY6TS40 / WLYWLY6G40 / WLYWLY6T120 / WLYWLY5T92
Cab parameters
Cab: Single Row / Sleeper cab
Tire
Tire Size: 7.00R16LT 8PR,7.50R16LT 6PR / 7.00R16 10PR / 7.00R16LT 10PR,7.50R16LT 8PR / 8.25R20,9.00-20 14PR / 8.25R16 / 8.25-16,8.25R16 / 7.00R16,7.50R16
Number of tires: 6pcs
FAQ
What kind of truck is Foton Foton TX Light Truck Refrigerated Truck?
Foton Foton TX Light Truck is an export-oriented Refrigerated Truck lineup with about 9 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Foton TX Light Truck Refrigerated Truck?
Foton TX Light Truck Refrigerated Truck export reference is about $16,472 – $22,222. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Foton TX Light Truck Refrigerated Truck cover?
Foton TX Light Truck Refrigerated Truck mainly covers: Drive: 4x2; Horsepower: 110 hp / 131 hp / 156 hp; Emission: China V; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Foton TX Light Truck Refrigerated Truck?
For Foton TX Light Truck Refrigerated Truck: 1) set emission; 2) match body/wheelbase to cargo type; 3) pick drive and horsepower; 4) compare prices, then open a model to quote.
What is Refrigerated Truck typically used for?
Refrigerated Truck covers box, stake or flatbed cargo work from city delivery to regional haul. Filter by body and payload needs.
How many models does Foton TX Light Truck Refrigerated Truck include?
Foton TX Light Truck Refrigerated Truck currently lists about 9 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Foton TX Light Truck Refrigerated Truck?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
