WP13Q560E62
EXW
Export quote
Weichai WP13 Series engine
Main model photos
32 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| WP13Q560E62 | 560hp / China VI | ||
| Weichai WP13H560E68C 560 hp 13L China VI Diesel Engine | 560hp / China VI | ||
| Weichai WP13H600E61 600hp 13L China VI Diesel Engine | 600hp / China VI | ||
| Weichai WP13H560E61A 560hp 13L China VI Diesel Engine | 560hp / China VI | ||
| Weichai WP13H530E61A 530hp 13L China VI Diesel Engine | 530hp / China VI |
Weichai WP13H560E68C 560 hp 13L China VI Diesel Engine
EXW
Export quote
Weichai WP13H600E61 600hp 13L China VI Diesel Engine
EXW
Export quote
Weichai WP13H560E61A 560hp 13L China VI Diesel Engine
EXW
Export quote
Weichai WP13H530E61A 530hp 13L China VI Diesel Engine
EXW
Export quote
Series Specs
Engine parameters
Engine Series: WP13 Series
Engine manufacturer: Weichai Power Co., Ltd. / Weichai
Suitable Range: land-use power generation / Truck diesel engine / Tractor truck, cargo truck, dump truck, etc. / heavy-duty truck, passenger transport, truck crane, loader, crawler crane / Trucks, buses, power generation, marine engines, construction machinery
Intake type: Turbocharged Air-to-Air Intercooling / Intercooled
Min. fuel consumption at full load: 184 / 185g/kW.h
Engine net weight: 905 / 1000kg
Engine Dimensions: 1556×817×1094mm
Compression ratio: 17:1
Bore × Stroke: 127x165 / 130×162mm
Valves per cylinder: 4pcs
Engine Brand: Weichai
Engine Model: WP13Q560E62 / WP13H560E68C / WP13H600E61 / WP13H560E61A / WP13H530E61A / WP13H500E61 / WP13H500E61A / WP13H480E61 / WP13H480E62 / WP13H500E62 / WP13H530E62 / WP13H560E62 / WP13.530E62A / WP13.560E68 / WP13.530E62 / WP13.480E62 / WP13H560E68A / WP13H560E68 / WP13H530E68 / WP13H600E68 / WP13.580E62 / WP13.510E62 / WP13 / WP13.500E508 / WP13.550E508 / WP13.480E501 / WP13.550E62 / WP13.480E401 / WP13.550E501 / WP13.530E501 / WP13.500E501 / WP13.480E50 / WP13.480E40 / WP13.500E40 / WP13.530E40 / WP13.550E40
Number of cylinders: 6cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 12.9 / 12.54L
Emission standard: China VI / China V / China IV
Max output power: 412 / 441 / 390 / 368 / 353 / 426 / 382 / 392 / 405kW
Max hp: 560 / 600 / 530 / 500 / 480 / 580 / 510 / 550Horsepower
Max torque: 2700 / 2600 / 2500 / 2400 / 2300 / 2585 / 2685 / 2550 / 2350 / 2100 / 2200N·m
Max torque speed: 950-1400 / 900-1300 / 900-1400 / 1000-1400 / 1200-1500rpm
Rated speed: 1600 / 1900 / 1800 / 1500 / 2100rpm
Engine Type: CR+TV+E-WGT+ DOC+DPF+ SCR+ASC / CR+DOC+DPF+Hi_SCR / High-pressure common rail / High-pressure common rail, direct injection, turbocharged intercooled / Inline 6-cylinder, electronically controlled high-pressure common rail + SCR / Inline 6-cylinder, 4-stroke, electronically controlled high-pressure common rail + SCR / High-pressure common rail, SCR aftertreatment
FAQ
What kind of truck is Weichai Weichai WP13 Series engine?
Weichai Weichai WP13 Series is an export-oriented engine lineup with about 36 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does Weichai WP13 Series engine cover?
Weichai WP13 Series engine mainly covers: Horsepower: 530 hp / 560 hp / 600 hp; Emission: China VI; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Weichai WP13 Series engine?
For Weichai WP13 Series engine, choose in order: emission → drive → horsepower/fuel → compare price and photos → open a model to quote. Include port and quantity.
What is engine typically used for?
For engine, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does Weichai WP13 Series engine include?
Weichai WP13 Series engine currently lists about 36 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Weichai WP13 Series engine?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
