JAC Kangling X3 60hp 4X2(6 wheels) 1.1L Gasoline 2.7m Single Row Stake Mini Truck
EXW
From $5,556
Export quote
JAC X3 light-duty truck Cargo Trucks
Main model photos
64 photos
Models
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| JAC Kangling X3 60hp 4X2(6 wheels) 1.1L Gasoline 2.7m Single Row Stake Mini Truck | 4x2 / 60hp / China V | From $5,556 | |
| JAC Kangling X3 1.3L 87hp 4X2(6 wheels) Gasoline 2.5m Double Row Box Mini Truck | 4x2 / 87hp / China V | From $5,556 | |
| JAC Kangling X3 1.3L 87 hp 4X2(6 wheels) Gasoline 2.5m Double Row Flatbed Mini Truck | 4x2 / 87hp / China V | From $5,417 | |
| JAC Kangling X3 1.3L 87 hp 4X2(6 wheels) Gasoline 3.25m Single Row Van Mini Truck | 4x2 / 87hp / China V | From $5,694 | |
| JAC Kangling X3 1.3L 87 hp 4X2(6 wheels) Gasoline 3.25m Single Row Flatbed Mini Truck | 4x2 / 87hp / China V | From $5,417 |
JAC Kangling X3 1.3L 87hp 4X2(6 wheels) Gasoline 2.5m Double Row Box Mini Truck
EXW
From $5,556
Export quote
JAC Kangling X3 1.3L 87 hp 4X2(6 wheels) Gasoline 2.5m Double Row Flatbed Mini Truck
EXW
From $5,417
Export quote
JAC Kangling X3 1.3L 87 hp 4X2(6 wheels) Gasoline 3.25m Single Row Van Mini Truck
EXW
From $5,694
Export quote
JAC Kangling X3 1.3L 87 hp 4X2(6 wheels) Gasoline 3.25m Single Row Flatbed Mini Truck
EXW
From $5,417
Export quote
Series Specs
Basic Info
Model code (announced): HFC5030CCYPW6E1B1DV / HFC5030XXYRW6E1B7V / HFC1030RW6E1B7V / HFC5030XXYPW6E3B7V / HFC1030PW6E3B7V / HFC5030CCYRW6E2B7DV / HFC5030XXYRW6E2B7DV / HFC1030RW6E2B7DV / HFC5030CCYPW6E1B7DV / HFC1030PV7E2B3V / HFC1030PW6E1B1DV / HFC1030PW6T1B7DV / HFC5030XXYRW6T1B7DV / HFC5030XXYPW6E1B1DV / HFC5020XXYRW6T1B7DV / HFC5020XXYPW6E1B7DV / HFC1030PW6E1B7DV / HFC5030XXYRW6E1B7DV / HFC1020PW6T1B7DV / HFC1030RW6E1B7DV / HFC5030CCYRW6T1B7DV / HFC1030RW6T1B7DV / HFC5020CCYPW6E1B7DV / HFC5020CCYPW6T1B7DV / HFC5030XXYPW6E1B7DV / HFC5030XXYPW6T1B7DV / HFC1020PW6E1B7DV / HFC5020CCYPW6K1B7 / HFC5020XXYPW6K1B7 / HFC1020PW6K1B7 / HFC1030RW6E2B7D / HFC1020RW6E1B7DV / HFC5030CCYRW6E1B7DV / HFC5030CCYPW6T1B7DV / HFC1020PW6E1B7D / HFC5020XXYRW6T1B7D / HFC1020RW6T1B7D / HFC5020XXYPW6T1B7D / HFC1030PW6E1B7D
Type: stake truck / enclosed cargo truck / Cargo Trucks
Drive type: 4X2
Wheelbase: 2370 / 2700 / 2600mm
Box length class: 2.7 / 2.5 / 3.3 / 3m
Engine Model: Wuling LiujiLJ465Q-2AE / Wuling LiujiLJ469Q-1AEB / Quanchai4A1-68C40
Transmission Model: QingshanMR508A / QingshanMR513B / 5-speed transmission
Rear Axle Ratio: 5.375 / 6.833 / 5.571
Cab length: 4.34 / 5.038 / 5.008 / 5.05 / 5.02 / 4.45 / 4.81 / 4.84m
Cab width: 1.61 / 1.51 / 1475m
Cab height: 2.41 / 2.005 / 2.58 / 2m
Front track width: 1260mm
rear track: 1260 / 1195 / 1180 / 1360mm
Curb Weight: 1.3 / 1.54 / 1.34 / 1.445 / 1.25 / 1.32 / 1.45 / 1.21 / 1.23 / 1.59 / 1.4 / 1.48 / 1.26 / 1.28 / 1.38 / 1.42 / 1.55 / 1.19 / 1.53 / 1.37 / 1.46 / 1.2ton
Rated payload: 1.495 / 1.8 / 1.815 / 1.35 / 1.22 / 1.46 / 0.995 / 1.475 / 0.95 / 1.465 / 0.445 / 0.685 / 0.925 / 0.495 / 0.975 / 0.745 / 1.385 / 0.725 / 0.735 / 1.48 / 0.9 / 1.485 / 1.405ton
GVWR: 2.925 / 3.36 / 3.16 / 3.375 / 3.195 / 2.995 / 2.66 / 2.815 / 2.855 / 2.865 / 2.31 / 2.215 / 2.73 / 2.08 / 2.51 / 2.72 / 2.6 / 2.175 / 2.255 / 2.065 / 2.105 / 2.285 / 2.415 / 2.165 / 2.295 / 2.01 / 2.595 / 2.825ton
Max. speed: 105 / 95 / 96km/h
Origin: Hefei, Anhui
tonnage class: mini truck
Approach angle: 32 / 19.6 / 30°
departure angle: 20 / 17.9°
Remarks: Dual sun visors, optional A/C, electronic power steering / Optional A/C, electronic power steering / A/C Optional / Double sun visor, A/C optional / Dual sun visors; optional metallic paint / Dual fuel (oil/gas) / Dual fuel: gasoline (45 kW) / CNG (40.5 kW) bi-fuel / Dual fuel: gasoline (45 kW) / NG (40.5 kW) bi-fuel
Front/rear suspension: 0.91/1.06 / 0.91/1.428 / 0.91/1.398 / 0.91/1.41 / 0.91/1.44 / 1.185/1.36 / 0.91/1.17 / 0.91/1.3 / 0.91/1.33m
Version: 2012 model
Energy Type: gasoline / Gasoline-CNG Dual Fuel / Diesel
Engine parameters
Engine Brand: Wuling Liuji / Quanchai
Engine info: Liuji gasoline 1.1L / Liuji gasoline 1.3L / Wuling Liuji1.1L / Quanchai480
Number of cylinders: 4cylinder
Cylinder arrangement: Inline
Displacement: 1.051 / 1.249 / 1.809L
Emission standard: China V / China IV
Max output power: 45 / 64 / 50kW
Max hp: 60 / 87 / 68Horsepower
Max torque: 850 / 105 / 170 / 85N·m
Max torque speed: 3500-4000 / 4000 / 3600-4000 / 1800rpm
Rated speed: 5600 / 6000 / 3200rpm
Engine Type: 4-stroke, inline inclined, mechanically adjusted roller rocker arm, electronic fuel injection, electronic ignition / Naturally aspirated, liquid-cooled, electronic injection, inline / Inline, vertical, water-cooled, high-pressure common rail, turbocharged intercooled
Transmission Parameters
Transmission Brand: Qingshan
shift method: Manual
Forward gears: 5Gear
FAQ
What kind of truck is JAC JAC X3 light-duty truck Cargo Trucks?
JAC JAC X3 light-duty truck is an export-oriented Cargo Trucks lineup with about 46 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for JAC X3 light-duty truck Cargo Trucks?
JAC X3 light-duty truck Cargo Trucks export reference is about $4,361 – $6,639. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does JAC X3 light-duty truck Cargo Trucks cover?
JAC X3 light-duty truck Cargo Trucks mainly covers: Drive: 4x2; Horsepower: 60 hp / 87 hp; Emission: China V; Fuel: gasoline. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in JAC X3 light-duty truck Cargo Trucks?
For JAC X3 light-duty truck Cargo Trucks: 1) set emission; 2) match body/wheelbase to cargo type; 3) pick drive and horsepower; 4) compare prices, then open a model to quote.
What is Cargo Trucks typically used for?
Cargo Trucks covers box, stake or flatbed cargo work from city delivery to regional haul. Filter by body and payload needs.
How many models does JAC X3 light-duty truck Cargo Trucks include?
JAC X3 light-duty truck Cargo Trucks currently lists about 46 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for JAC X3 light-duty truck Cargo Trucks?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
