SDEC SC8DK280Q4 280hp 8.27L China IV diesel engine
EXW
Export quote
SDEC SC8DK Series engine
Main model photos
4 photos
Models
On sale
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| SDEC SC8DK280Q4 280hp 8.27L China IV diesel engine | 280hp / China IV | ||
| SDEC SC8DK260Q4 260hp 8.27L China IV diesel engine | 260hp / China IV | ||
| SDEC SC8DK240Q4 240hp 8.27L China IV Diesel Engine | 240hp / China IV | ||
| SDEC SC8DK230Q4 230hp 8.27L China IV Diesel Engine | 230hp / China IV | ||
| SDEC SC8DK250Q3 250hp 8.27L China III Diesel Engine | 250hp / China III / Euro III |
SDEC SC8DK260Q4 260hp 8.27L China IV diesel engine
EXW
Export quote
SDEC SC8DK240Q4 240hp 8.27L China IV Diesel Engine
EXW
Export quote
SDEC SC8DK230Q4 230hp 8.27L China IV Diesel Engine
EXW
Export quote
SDEC SC8DK250Q3 250hp 8.27L China III Diesel Engine
EXW
Export quote
Series Specs
Engine parameters
Engine Series: SC8DK series
Engine manufacturer: Shanghai Diesel Engine Co., Ltd.
Suitable Range: Truck engine
Intake type: Turbocharged / Turbocharged Air-to-Air Intercooling
Min. fuel consumption at full load: 196 / 200g/kW.h
Engine net weight: 800 / 700kg
Engine Dimensions: 1255X890X982 / 1363x890x982mm
Compression ratio: 18：1
noise at 1m: 98dB
Bore × Stroke: 114x144 / 114x135mm
Valves per cylinder: 4pcs
Engine Brand: SDEC
Engine Model: SC8DK280Q4 / SC8DK260Q4 / SC8DK240Q4 / SC8DK230Q4 / SC8DK250Q3 / SC8DK250Q4 / SC8DK230Q3 / SC8DK300Q3 / SC8DK340 / SC8DK310 / SC8DK290 / SC8DK280 / SC8DK250 / SC8DK230 / SC8DK215Q3 / SC8DK290Q3 / SC8DK240Q3 / SC8DK260Q3 / SC8DK280Q3
Number of cylinders: 6cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 8.268 / 8.27L
Emission standard: China IV / China III / Euro III
Max output power: 206 / 192 / 177 / 170 / 184 / 220 / 251 / 228 / 213 / 158 / 199kW
Max hp: 280 / 260 / 240 / 230 / 250 / 300 / 340 / 310 / 290 / 215Horsepower
Max torque: 1160 / 1100 / 960 / 900 / 1430 / 1250 / 1200 / 1000N·m
Max torque speed: 1400rpm
Rated speed: 2200rpm
Engine Type: Electronic control system / Electronic control system, turbocharger / Inline 6-cylinder, electronically controlled common rail, turbocharged intercooled, water-cooled wet liner, front gear train / Inline 6-cylinder, electronically controlled common rail, turbocharged, water-cooled wet liner, front gear train / direct injection, inline, 6-cylinder, water-cooled, 4-stroke
FAQ
What kind of truck is SDEC SDEC SC8DK Series engine?
SDEC SDEC SC8DK Series is an export-oriented engine lineup with about 19 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What spec range does SDEC SC8DK Series engine cover?
SDEC SC8DK Series engine mainly covers: Horsepower: 230 hp / 240 hp / 250 hp / 260 hp / 280 hp; Emission: China III / Euro III / China IV; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in SDEC SC8DK Series engine?
For SDEC SC8DK Series engine, choose in order: emission → drive → horsepower/fuel → compare price and photos → open a model to quote. Include port and quantity.
What is engine typically used for?
For engine, use drive, horsepower and emission on this page to shortlist, and state use case plus destination in your quote.
How many models does SDEC SC8DK Series engine include?
SDEC SC8DK Series engine currently lists about 19 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for SDEC SC8DK Series engine?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
