Dongfeng Commercial Vehicle Tianlong VL 315 hp 8X4(12 wheels) 9.34m Refrigerated Truck (Chengliwei Brand)
EXW
From $46,153
Export quote
Chengliwei Dongfeng Commercial Vehicle Chassis
Main model photos
256 photos
Models
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Dongfeng Commercial Vehicle Tianlong VL 315 hp 8X4(12 wheels) 9.34m Refrigerated Truck (Chengliwei Brand) | 8x4 / 315hp / China V | From $46,153 | |
| Dongfeng Commercial Vehicle Tianjin 220 hp 6X2(8 wheels) 9.34m Refrigerated Truck (Chengliwei Brand) | 6x2 / 220hp / China V | From $31,667 | |
| Dongfeng Commercial Vehicle Tianjin 190hp 4X2(6 wheels) Refrigerated Truck (Chengliwei) | 4x2 / 190hp / China III / Euro III | ||
| Dongfeng Commercial Vehicle Tianjin 180hp 4X2(6 wheels) Refrigerated Truck (Chengliwei) | 4x2 / 180hp / China III / Euro III |
Dongfeng Commercial Vehicle Tianjin 220 hp 6X2(8 wheels) 9.34m Refrigerated Truck (Chengliwei Brand)
EXW
From $31,667
Export quote
Dongfeng Commercial Vehicle Tianjin 190hp 4X2(6 wheels) Refrigerated Truck (Chengliwei)
EXW
Export quote
Dongfeng Commercial Vehicle Tianjin 180hp 4X2(6 wheels) Refrigerated Truck (Chengliwei)
EXW
Export quote
Series Specs
Basic Info
Cab dimensions: 11.99×2.55×3.94 / 11.99×2.55×3.9 / 9.99×2.49×3.85m
Drive type: 8X4 / 6X2 / 4X2
Truck Type: Refrigerated Truck
Wheelbase: 1850+4600+1350 / 1850+5450 / 5600mm
Vehicle origin: Suizhou, Hubei
Front track width: 2040 / 1980 / 1880mm
rear track: 1860 / 1800,1860 / 1800mm
Curb Weight: 12.9 / 11.3 / 6.805ton
Rated payload: 17.97 / 13.57 / 9ton
Max. speed: 90km/h
Front/rear suspension: 1.5/2.64 / 1.5/3.19 / 1.43/2.96m
Energy Type: Diesel
Engine parameters
Engine Model: DongfengISL9.5-315E51A / DongfengISB220 50 / DongfengB190 33 / CumminsISDe18030
Number of cylinders: 6cylinder
Displacement: 9.46 / 5.9 / 6.7L
Emission standard: China V / China III / Euro III
Max output power: 232 / 162 / 140 / 132kW
Max hp: 315 / 220 / 190 / 180Horsepower
Max torque: 1250 / 800 / 640N·m
Rated speed: 1900 / 2500rpm
Engine Type: Inline 6-cylinder, water-cooled, 4-stroke, turbocharged intercooled / Inline 6-cylinder, water-cooled, 4-stroke, turbocharged air intercooled, SCR / Inline / Inline 6-cylinder, electronic control system, enhanced high-pressure common rail, particulate filter
Cargo box parameters
Box volume: 40.5m³
Cargo box dimensions: 9.34×2.34×2.45 / 9.34×2.34×2.4 / 7.4×2.28×2.4m
Cargo box width: 2.34 / 2.28m
Cargo box height: 2.45 / 2.4m
Body Parameters
Vehicle certification code: CLW5310XLCD5 / CLW5253XLCD5 / CLW5160XLC3
Body Brand: Chengliwei
Refrigeration unit:
Others: The cargo box top is closed and non-openable. Optional side door.
Refrigeration temperature: -18°C
Chassis Specs
Chassis Brand: Dongfeng Commercial Vehicle
Chassis Series: Dongfeng Tianlong VL / Dongfeng Tianjin
Chassis Model: DFH1310A1 / DFH1250AXV / DFL5160XXYBX1
Front axle description: Payload 6500kg / Payload 7000kg / 5T
rear axle description: Payload 18000kg / Payload 11000 kg / 10T
Leaf spring count: 9/9/10,8/8/10,3/3/4,9/9/-,3/3/- / 8/8/9+9,3/3/9+3,9/9/9+3,9/9/10+3,9/9/9+9 / 7/9+6,8/10+8,11/11+10 / 7/9+6
Transmission Parameters
Number of gears: 12 / 8 / 5Gear
Transmission Model: Fast Gear12JSD160TA / DongfengDF8S1000
Tire
Tire Size: 11.00-20 16PR,11.00-20 18PR,11.00R20 16PR,11.00R20 18PR,295/80R22.5 16PR,295/80R22.5 18PR,12R22.5 16PR,12R22.5 18PR / 11.00-20 18PR,11.00R20 18PR,295/80R22.5 18PR,12R22.5 18PR / 9.00-20 / 9.00-20/9.00R20/10.00-20/10.00R20
Number of tires: 12 / 8 / 6pcs
FAQ
What kind of truck is Chengliwei Chengliwei Dongfeng Commercial Vehicle Chassis Refrigerated Truck?
Chengliwei Chengliwei Dongfeng Commercial Vehicle Chassis is an export-oriented Refrigerated Truck lineup with about 4 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Chengliwei Dongfeng Commercial Vehicle Chassis?
Chengliwei Dongfeng Commercial Vehicle Chassis export reference is about $31,667 – $46,153. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Chengliwei Dongfeng Commercial Vehicle Chassis cover?
Chengliwei Dongfeng Commercial Vehicle Chassis mainly covers: Drive: 4x2 / 6x2 / 8x4; Horsepower: 180 hp / 190 hp / 220 hp / 315 hp; Emission: China III / Euro III / China V; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Chengliwei Dongfeng Commercial Vehicle Chassis?
For Chengliwei Dongfeng Commercial Vehicle Chassis: 1) set emission; 2) match body/wheelbase to cargo type; 3) pick drive and horsepower; 4) compare prices, then open a model to quote.
What is Refrigerated Truck typically used for?
Refrigerated Truck covers box, stake or flatbed cargo work from city delivery to regional haul. Filter by body and payload needs.
How many models does Chengliwei Dongfeng Commercial Vehicle Chassis include?
Chengliwei Dongfeng Commercial Vehicle Chassis currently lists about 4 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Chengliwei Dongfeng Commercial Vehicle Chassis?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
