Hitachi ZX210LC-3G crawler excavator

Export reference
MSRP N/A
Model:: ZX210LC-3G
Engine Model:: crawler excavator
Tonnage:: 21ton
Bucket capacity:: 0.91cubic meter
Machine dimensions:: 9.5×2.86×2.97mm
Track shoe width:: 600mm
Hitachi ZX210LC-3G crawler excavator exterior
View more photos (3)
Operating weight: 21.1ton
Bucket type: backhoe
Fuel Tank Capacity: 360L
Product power: Conventional Power

Overview

The Hitachi ZX210LC-3G crawler excavator is a excavator featuring 21.1ton GVW, backhoe bucket capacity, 360L tank capacity and Conventional Power power. On the powertrain side, it comes with a crawler excavator engine.

Model Specs

Legend: ● Standard　○ Optional　- N/A

Basic Info
Model: ZX210LC-3G
Engine Model: crawler excavator
Product power: Conventional Power
Bucket type: backhoe
Tonnage: 21ton
Bucket capacity: 0.91cubic meter
Operating weight: 21.1ton
Machine dimensions: 9.5×2.86×2.97mm
Track shoe width: 600mm
Track gauge: 2390mm
Counterweight ground clearance: 1040mm
Rear Overhang Radius: 2750mm
Min ground clearance: 450cm
hydraulic system
Max flow of main pump: 194×2L/min
Working hydraulic circuit: 34.3
travel hydraulic circuit: 34.3Mpa
Swing Hydraulic Circuit: 30.4Mpa
performance specs
Travel speed: 3.6/5.5km/h
Bucket digging force: 151kN
Arm Digging Force: 109kN
Oil capacity
Fuel Tank Capacity: 360L
coolant: 23L
hydraulic oil tank: 135L
Engine Oil Capacity: 25L
Operating Range
Max digging radius: 9910mm
Max digging depth: 6660mm
Max digging height: 9610mm
Max unloading height: 6790mm
Max vertical digging depth: 6040mm
Engine parameters
Engine Model: IsuzuISUZU AA-6BG1T
Max output power: 110kW

Photos

Exterior3

Hitachi ZX210LC-3G crawler excavator Exterior (1) | 86Trucks Hitachi ZX210LC-3G crawler excavator Exterior (2) | 86Trucks Hitachi ZX210LC-3G crawler excavator Exterior (3) | 86Trucks

3 photos

FAQ

What transport jobs is Hitachi ZX210LC-3G crawler excavator suited for?

Hitachi ZX210LC-3G crawler excavator is a excavator model; configuration should match the job. State the application, emission and LHD/RHD needs in your quote.

How does Hitachi ZX210LC-3G crawler excavator differ from other variants in the same series?

Hitachi ZX210LC-3G crawler excavator belongs to Hitachi Hitachi Crawler Excavator (excavator). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for Hitachi ZX210LC-3G crawler excavator?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export Hitachi ZX210LC-3G crawler excavator?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
