SHACMAN Commercial Vehicle Xuande X9 160hp 4X2(6 wheels) 3.7m³ concrete mixer truck

Export reference
From $21,292
MSRP ¥15.33M CNY
Fuel: Diesel
Curb Weight:: 7.65ton
Wheelbase:: 3700mm
Tire Size:: 9.00R20
Cab dimensions:: 7.4×2.35×3.65m
Truck Type:: Concrete mixer truck
Rated payload: 8.155ton
Drive 4X2 (6 wheels)
Horsepower 160
Emission China V

Overview

The SHACMAN Commercial Vehicle Xuande X9 160hp 4X2(6 wheels) 3.7m³ concrete mixer truck is a concrete mixer truck featuring 8.155t payload, 7.65ton GVW, 4X2 (6 wheels) drive and X903 cab. On the powertrain side, it comes with 160 hp, China V emissions and Diesel fuel.

China V 160 Diesel 4X2

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Cab dimensions: 7.4×2.35×3.65m
Truck Type: Concrete mixer truck
Drive type: 4X2
Vehicle origin: Xi'an, Shaanxi
Wheelbase: 3700mm
Front/rear track width: Front: 1765mm; Rear: 1750
Curb Weight: 7.65ton
Rated payload: 8.155ton
Max. speed: 80km/h
Front/rear suspension: 1.3/2.4m
Body Parameters
Mixing drum capacity: 3.7m³
Vehicle certification code: SX5160GJBGP5371
Body Brand: SHACMAN Commercial Vehicle
Others: Standard: Cab X903 (2080) mechanical seat, cab reserved A/C interface, Tianxingjian Zhiya Edition BD onboard terminal; cab color: polar white; Brake: domestic four-channel ABS; with FARIZON throttle control system; ECU reads vehicle code; brake test connector; right-turn voice alert. Option: A/C.
Engine parameters
Engine Model: YuchaiYC4S160-50
Number of cylinders: 4cylinder
fuel type: Diesel
Displacement: 3.767L
Emission standard: China V
Max output power: 118kW
Max hp: 160Horsepower
Rated speed: 2600rpm
Engine Type: Vertical, inline, water-cooled, four-stroke
Chassis Specs
Chassis Series: Xuande X9
Chassis Model: SX1160GP5371
Front axle description: 148S
Frame Dimensions: 800x250/7+4 double-layermm
rear axle description: 153SDL
Axle ratio: 6.83
Leaf spring count: 8/10+8,9/11+8
Transmission Parameters
Number of gears: 8Gear
Transmission Model: Fast Gear8JS85E-C
Cab parameters
Cab: X903
Tire
Tire Size: 9.00R20
Number of tires: 6pcs

Photos

Exterior1

1 photos

FAQ

What is the export price of SHACMAN Commercial Vehicle Xuande X9 160hp 4X2(6 wheels) 3.7m³ concrete mixer truck, and what does it include?

SHACMAN Commercial Vehicle Xuande X9 160hp 4X2(6 wheels) 3.7m³ concrete mixer truck export reference is about From $21,292; MSRP is ¥15.33M CNY. This estimate is based on China MSRP (near factory/EXW style) and usually excludes ocean freight, insurance and destination charges. Quantity, emission version, FOB/CIF and port change the final price — request a quote on this page.

What emission standard does SHACMAN Commercial Vehicle Xuande X9 160hp 4X2(6 wheels) 3.7m³ concrete mixer truck use, and can it enter my country?

This model is listed as China V. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of SHACMAN Commercial Vehicle Xuande X9 160hp 4X2(6 wheels) 3.7m³ concrete mixer truck?

Key specs of SHACMAN Commercial Vehicle Xuande X9 160hp 4X2(6 wheels) 3.7m³ concrete mixer truck: Drive: 4x2; Horsepower: 160 hp; Emission: China V; Fuel: Diesel. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is SHACMAN Commercial Vehicle Xuande X9 160hp 4X2(6 wheels) 3.7m³ concrete mixer truck suited for?

SHACMAN Commercial Vehicle Xuande X9 160hp 4X2(6 wheels) 3.7m³ concrete mixer truck is a concrete mixer truck model often used on construction, mining and aggregate jobs. Check drive, horsepower and emission; state duty cycle and destination in your quote.

How does SHACMAN Commercial Vehicle Xuande X9 160hp 4X2(6 wheels) 3.7m³ concrete mixer truck differ from other variants in the same series?

SHACMAN Commercial Vehicle Xuande X9 160hp 4X2(6 wheels) 3.7m³ concrete mixer truck belongs to SHACMAN Xuande X9 Light Truck (concrete mixer truck). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for SHACMAN Commercial Vehicle Xuande X9 160hp 4X2(6 wheels) 3.7m³ concrete mixer truck?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export SHACMAN Commercial Vehicle Xuande X9 160hp 4X2(6 wheels) 3.7m³ concrete mixer truck?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
