Foton V-Card 2.3L Diesel 142hp 4X2(6 wheels) WLY 5-speed 3.7m Single-row Cargo Micro Truck

Export reference
From $11,181
MSRP ¥8.05M CNY
Horsepower: 142
Emission: China VI
Fuel: Diesel
Engine: Quanchai2.3L
Transmission: WLY
Curb Weight:: 2.495ton
seating capacity: 2Personnel
Rated payload: 1.495ton
Drive 4X2 (6 wheels)
Cargo box type: Stake type

Overview

The Foton V-Card 2.3L Diesel 142hp 4X2(6 wheels) WLY 5-speed 3.7m Single-row Cargo Micro Truck is a mini truck featuring 3.7m cargo length, Stake type cargo body, 2Personnel volume and 1.495t payload. On the powertrain side, it comes with a Quanchai2.3L engine, 142 hp, 4X2 (6 wheels) drive and China VI emissions.

China VI 142 Diesel 4X2

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): BJ5044CCY8JBA-AB1
Type: stake truck
Drive type: 4X2
Wheelbase: 2900mm
Box length class: 3.7m
engine: QuanchaiQ23A-142E60
transmission: WLYWLY5G32
Rear Axle Ratio: 4.33
Cab length: 5.48m
Cab width: 1.95m
Cab height: 2.865m
Front track width: 1500mm
rear track: 1455mm
Curb Weight: 2.495ton
Rated payload: 1.495ton
GVWR: 4.12ton
Max. speed: 110km/h
Origin: Shandong Zhucheng
tonnage class: mini truck
Approach angle: 18°
departure angle: 17°
Front/rear suspension: 1.115/1.465m
Energy Type: Diesel
Engine parameters
Engine Brand: Quanchai
Engine Model: Q23A-142E60
Engine info: Quanchai2.3L
Number of cylinders: 4cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 2.3L
Emission standard: China VI
Max output power: 103kW
Max hp: 142Horsepower
Max torque: 330N·m
Max torque speed: 1400-2400rpm
Rated speed: 3000rpm
Transmission Parameters
Transmission Model: WLY5G32
Transmission Brand: WLY
shift method: Manual
Forward gears: 5Gear
Number of Reverse Gears:
Cargo box parameters
Cargo box type: Stake type
Cargo box length: 3.7m
Cargo box width: 1.85m
*Cargo box interior width: 1.85
Cab parameters
Cab width: 1730mm
seating capacity: 2Personnel
Seat rows: Single Row
fuel tank
Fuel tank capacity: 70L
Chassis Specs
Front axle allowable load: 1650kg
Frame Dimensions: 714/760-140×50×4mm
rear axle description: 4.5T
rear axle allowable load: 2470kg
Axle ratio: 4.33
Leaf spring count: 3/5+3
Tire
Tire Size: 6.50R16LT 10PR
Number of tires: 6pcs
Control configuration
ABS:
interior configuration
Multifunction steering wheel:
AC control type: Optional manual.
Power Windows:
Electric Heated Rearview Mirror:
Seat material: Fabric
Reverse Camera:
Remote key:
Electronic Central Lock:
Exterior features
Air deflector:
Multimedia features
Center Console Color Screen:
Bluetooth / hands-free calling:
lighting configuration
Front fog lamp:
daytime running lights:
Halogen Headlights:
Service brake
Brake Type: Hydraulic brake
Parking brake: parking brake
Front wheel brake: Disc
Rear Wheel Brake: Drum Type
smart configuration
Telematics System:
Cruise control (CCS):

Photos

0 photos

FAQ

What is the export price of Foton V-Card 2.3L Diesel 142hp 4X2(6 wheels) WLY 5-speed 3.7m Single-row Cargo Micro Truck, and what does it include?

Foton V-Card 2.3L Diesel 142hp 4X2(6 wheels) WLY 5-speed 3.7m Single-row Cargo Micro Truck export reference is about From $11,181; MSRP is ¥8.05M CNY. This estimate is based on China MSRP (near factory/EXW style) and usually excludes ocean freight, insurance and destination charges. Quantity, emission version, FOB/CIF and port change the final price — request a quote on this page.

What emission standard does Foton V-Card 2.3L Diesel 142hp 4X2(6 wheels) WLY 5-speed 3.7m Single-row Cargo Micro Truck use, and can it enter my country?

This model is listed as China VI. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of Foton V-Card 2.3L Diesel 142hp 4X2(6 wheels) WLY 5-speed 3.7m Single-row Cargo Micro Truck?

Key specs of Foton V-Card 2.3L Diesel 142hp 4X2(6 wheels) WLY 5-speed 3.7m Single-row Cargo Micro Truck: Drive: 4x2; Horsepower: 142 hp; Emission: China VI; Fuel: Diesel; Engine: Quanchai2.3L; Transmission: WLY. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is Foton V-Card 2.3L Diesel 142hp 4X2(6 wheels) WLY 5-speed 3.7m Single-row Cargo Micro Truck suited for?

Foton V-Card 2.3L Diesel 142hp 4X2(6 wheels) WLY 5-speed 3.7m Single-row Cargo Micro Truck is a Cargo Trucks model for box, bulk or regional distribution. Choose by body type, wheelbase and power; mention cargo type and market in your quote.

How does Foton V-Card 2.3L Diesel 142hp 4X2(6 wheels) WLY 5-speed 3.7m Single-row Cargo Micro Truck differ from other variants in the same series?

Foton V-Card 2.3L Diesel 142hp 4X2(6 wheels) WLY 5-speed 3.7m Single-row Cargo Micro Truck belongs to Foton V Card (Cargo Trucks). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for Foton V-Card 2.3L Diesel 142hp 4X2(6 wheels) WLY 5-speed 3.7m Single-row Cargo Micro Truck?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export Foton V-Card 2.3L Diesel 142hp 4X2(6 wheels) WLY 5-speed 3.7m Single-row Cargo Micro Truck?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
