Luoxiang 13m Dump Semi-Trailer

Export reference
MSRP N/A
Cab length:: 13m
Axle Brand:: Fuhua
suspension:: Leaf spring
Wheel Material:: Steel rim
Brake chamber:: Ruili 4 single 2 double
Outrigger:: 16T single-action
Design load capacity: 32.5ton
Cargo box floor thickness: 2mm
Curb Weight: 7.5ton
Tire brand: Rishang

Overview

The Luoxiang Trailer Luoxiang 13m Dump Semi-Trailer is a dump semi-trailer featuring 32.5ton payload, 7.5ton GVW, 2mm cargo body and 13m cab.

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Design load capacity: 32.5ton
Cab length: 13m
Cab width: 2.55m
Cab height: 2.9m
Curb Weight: 7.5ton
Chassis Specs
Axle Brand: Fuhua
Number of Axles: 3
Axle Load Rating: -/24000(tri-axle group)
suspension: Leaf spring
Wheel Material: Steel rim
Parts & accessories
Brake chamber: Ruili 4 single 2 double
Outrigger: 16T single-action
ratchet tie-down: 40pcs
Toolbox: aluminum alloy, 2160mmpcs
ABS: Kemi, 4S/2M; with low-pressure alarm
Body Parameters
Frame material: B750L
Web Plate: 5mm
frame rail height: 470mm
upper wing panel: 8mm
Lower Wing Plate: 10mm
Cargo box floor thickness: 2mm
Side beam: high-strength bent 3.0
Cargo box side plate thickness:
Lifting device: Hydraulic
Cargo box parameters
Cargo box length: 12.85m
Cargo box width: 2.45m
Cargo box height: 0.6m
Other notes
Lead time for customization: 15
warranty method: Service Station
Tire
Tire brand: Rishang
Tire Size: 12R22.5 12PR
Number of tires: 12pcs

Photos

Exterior1

1 photos

FAQ

What transport jobs is Luoxiang 13m Dump Semi-Trailer suited for?

Luoxiang 13m Dump Semi-Trailer is a dump semi-trailer model often used on construction, mining and aggregate jobs. Check drive, horsepower and emission; state duty cycle and destination in your quote.

How does Luoxiang 13m Dump Semi-Trailer differ from other variants in the same series?

Luoxiang 13m Dump Semi-Trailer belongs to Luoxiang Trailer 13m Series (dump semi-trailer). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for Luoxiang 13m Dump Semi-Trailer?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export Luoxiang 13m Dump Semi-Trailer?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
