Luoxiang 13m Dump Semi-Trailer
EXW
Export quote
Luoxiang Trailer 13m Series dump semi-trailer
Main model photos
19 photos
Models
Series Specs
Basic Info
Design load capacity: 32.5ton
Cab length: 13m
Cab width: 2.55m
Cab height: 2.9m
Curb Weight: 7.5ton
Chassis Specs
Axle Brand: Fuhua
Number of Axles: 3
Axle Load Rating: -/24000(tri-axle group)
suspension: Leaf spring
Wheel Material: Steel rim
Parts & accessories
Brake chamber: Ruili 4 single 2 double
Outrigger: 16T single-action
ratchet tie-down: 40pcs
Toolbox: aluminum alloy, 2160mmpcs
ABS: Kemi, 4S/2M; with low-pressure alarm
Body Parameters
Frame material: B750L
Web Plate: 5mm
frame rail height: 470mm
upper wing panel: 8mm
Lower Wing Plate: 10mm
Cargo box floor thickness: 2mm
Side beam: high-strength bent 3.0
Cargo box side plate thickness:
Lifting device: Hydraulic
Cargo box parameters
Cargo box length: 12.85m
Cargo box width: 2.45m
Cargo box height: 0.6m
Other notes
Lead time for customization: 15
warranty method: Service Station
Tire
Tire brand: Rishang
Tire Size: 12R22.5 12PR
Number of tires: 12pcs
FAQ
What kind of truck is Luoxiang Trailer Luoxiang Trailer 13m Series dump semi-trailer?
Luoxiang Trailer Luoxiang Trailer 13m Series is an export-oriented dump semi-trailer lineup with about 1 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is dump semi-trailer typically used for?
dump semi-trailer is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does Luoxiang Trailer 13m Series dump semi-trailer include?
Luoxiang Trailer 13m Series dump semi-trailer currently lists about 1 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Luoxiang Trailer 13m Series dump semi-trailer?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
