Hualing Lingma H3 180 hp 4X2(6 wheels) 6.8m Stake Cargo Truck

Export reference
MSRP N/A
Horsepower: 180
Emission: China V
Fuel: Diesel
Engine: Yuchai 6-cylinder
Transmission: Fast Gear
Curb Weight:: 6.15ton
seating capacity: 3Personnel
Rated payload: 9.72ton
Drive 4X2 (6 wheels)
Cargo box type: Stake type

Overview

The Hualing Lingma H3 180 hp 4X2(6 wheels) 6.8m Stake Cargo Truck is a Medium-duty truck featuring 6.8m cargo length, Stake type cargo body, 3Personnel volume and 9.72t payload. Its segment focus covers Agricultural product transport, green channel and industrial product transport, matching those duty cycles. On the powertrain side, it comes with a Yuchai 6-cylinder engine, 180 hp, 4X2 (6 wheels) drive and China V emissions.

China V 180 Diesel 4X2

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): HN5160CCYH19E6M5
Type: stake truck
Drive type: 4X2
Wheelbase: 5300mm
Box length class: 6.8m
engine: YuchaiYC6J180-50
transmission: Fast Gear8JS75C
Rear Axle Ratio: 4.875
Cab length: 9m
Cab width: 2.55m
Cab height: 3.85m
Front track width: 1908mm
rear track: 1860mm
Curb Weight: 6.15ton
Rated payload: 9.72ton
GVWR: 16ton
Max. speed: 98km/h
Origin: Ma'anshan, Anhui
tonnage class: Medium-duty truck
Approach angle: 20°
departure angle: 20°
market segment: Agricultural product transport, green channel, industrial product transport
Remarks: Optional fuel tank capacity: 250L; optional fuel tank material: aluminum alloy
Front/rear suspension: 1.45/2.25m
Energy Type: Diesel
Engine parameters
Engine Brand: Yuchai
Engine Model: YuchaiYC6J180-50
Engine info: Yuchai 6-cylinder
Number of cylinders: 6cylinder
fuel type: Diesel
Cylinder arrangement: Inline
Displacement: 6.494L
Emission standard: China V
Max output power: 132kW
Max hp: 180Horsepower
Max torque: 650N·m
Max torque speed: 1200-1700rpm
Rated speed: 2500rpm
Engine Type: Vertical, inline 6-cylinder, water-cooled, 4-stroke, electronic direct injection
Transmission Parameters
Transmission Model: Fast Gear8JS75C
Transmission Brand: Fast Gear
shift method: Manual
Forward gears: 8Gear
Number of Reverse Gears: 2pcs
Cargo box parameters
Cargo box type: Stake type
Cargo box length: 6.8m
Cargo box width: 2.45m
Cargo box height: 0.6m
*Cargo box interior width: 2.4500000476837
Cab parameters
Cab: Flat roof, all-steel cab
seating capacity: 3Personnel
Seat rows: Sleeper cab
Driver seat type: Mechanical suspension seat
fuel tank
Fuel tank material: Iron
Fuel tank capacity: 200L
Chassis Specs
Front axle description: 145
Front axle allowable load: 6000kg
Frame Dimensions: 250(7)mm
rear axle description: HL145
rear axle allowable load: 10000kg
Axle ratio: 4.875
Leaf spring count: 10/9+6
Tire
Tire Size: 9.00R20
Number of tires: 6pcs
Control configuration
ABS:
interior configuration
AC control type: Manual
Power Windows:
Electronic Central Lock:
Exterior features
Air deflector:
Multimedia features
Radio:

Photos

0 photos

FAQ

What emission standard does Hualing Lingma H3 180 hp 4X2(6 wheels) 6.8m Stake Cargo Truck use, and can it enter my country?

This model is listed as China V. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of Hualing Lingma H3 180 hp 4X2(6 wheels) 6.8m Stake Cargo Truck?

Key specs of Hualing Lingma H3 180 hp 4X2(6 wheels) 6.8m Stake Cargo Truck: Drive: 4x2; Horsepower: 180 hp; Emission: China V; Fuel: Diesel; Engine: Yuchai 6-cylinder; Transmission: Fast Gear. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is Hualing Lingma H3 180 hp 4X2(6 wheels) 6.8m Stake Cargo Truck suited for?

Hualing Lingma H3 180 hp 4X2(6 wheels) 6.8m Stake Cargo Truck is a Cargo Trucks model for box, bulk or regional distribution. Choose by body type, wheelbase and power; mention cargo type and market in your quote.

How does Hualing Lingma H3 180 hp 4X2(6 wheels) 6.8m Stake Cargo Truck differ from other variants in the same series?

Hualing Lingma H3 180 hp 4X2(6 wheels) 6.8m Stake Cargo Truck belongs to Hualing Lingma H3 Heavy Truck (Cargo Trucks). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for Hualing Lingma H3 180 hp 4X2(6 wheels) 6.8m Stake Cargo Truck?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export Hualing Lingma H3 180 hp 4X2(6 wheels) 6.8m Stake Cargo Truck?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
