Hualing HanmaH6 180hp 4X2(6 wheels) Refrigerated Truck

Export reference
MSRP N/A
Emission: China V
Fuel: Diesel
Curb Weight:: 6.87ton
Wheelbase:: 5600mm
Tire Size:: 9.00R20
Cab dimensions:: 9.05×2.55×4m
Rated payload: 9ton
Drive 4X2 (6 wheels)
Cargo box dimensions: 7.6×2.33×2.65m
Horsepower 180

Overview

The Hualing HanmaH6 180hp 4X2(6 wheels) Refrigerated Truck is a Refrigerated Truck featuring 7.6×2.33×2.65m cargo body, 9t payload, Hanma H3 flat roof full steel cab cab and 5600mm wheelbase. On the powertrain side, it comes with 180 hp, 4X2 (6 wheels) drive, China V emissions and Diesel fuel.

China V 180 Diesel 4X2

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Cab dimensions: 9.05×2.55×4m
Truck Type: Refrigerated Truck
Drive type: 4X2
Vehicle origin: Ma'anshan, Anhui
Wheelbase: 5600mm
Front track width: 1908mm
rear track: 1860mm
Curb Weight: 6.87ton
Rated payload: 9ton
Max. speed: 98km/h
Front/rear suspension: 1.45/2.95m
Energy Type: Diesel
Engine parameters
Engine Model: SDECSC4H180Q5
Number of cylinders: 4cylinder
fuel type: Diesel
Displacement: 4.295L
Emission standard: China V
Max output power: 132kW
Max hp: 180Horsepower
Max torque: 660N·m
Rated speed: 2300rpm
Engine Type: Inline, electronic control system
Cargo box parameters
Cargo box dimensions: 7.6×2.33×2.65m
Cargo box width: 2.33m
Cargo box height: 2.65m
Body Parameters
Vehicle certification code: HN5160XLCH19E6M5
Chassis Specs
Chassis Brand: Hualing
Chassis Series: HanmaH6
Chassis Model: HN1160H19E6M5J
Front axle description: 145
Frame Dimensions: 250(7)mm
rear axle description: HL145
Axle ratio: 4.875
Leaf spring count: 10/9+6
Transmission Parameters
Number of gears: 8Gear
Transmission Model: Fast Gear8JS75C
Cab parameters
Cab: Hanma H3 flat roof full steel cab
Tire
Tire Size: 9.00R20
Number of tires: 6pcs

Photos

Exterior1

1 photos

FAQ

What emission standard does Hualing HanmaH6 180hp 4X2(6 wheels) Refrigerated Truck use, and can it enter my country?

This model is listed as China V. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of Hualing HanmaH6 180hp 4X2(6 wheels) Refrigerated Truck?

Key specs of Hualing HanmaH6 180hp 4X2(6 wheels) Refrigerated Truck: Drive: 4x2; Horsepower: 180 hp; Emission: China V; Fuel: Diesel. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is Hualing HanmaH6 180hp 4X2(6 wheels) Refrigerated Truck suited for?

Hualing HanmaH6 180hp 4X2(6 wheels) Refrigerated Truck is a Refrigerated Truck model for box, bulk or regional distribution. Choose by body type, wheelbase and power; mention cargo type and market in your quote.

How does Hualing HanmaH6 180hp 4X2(6 wheels) Refrigerated Truck differ from other variants in the same series?

Hualing HanmaH6 180hp 4X2(6 wheels) Refrigerated Truck belongs to Hualing Hanma H6 Heavy Truck (Refrigerated Truck). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for Hualing HanmaH6 180hp 4X2(6 wheels) Refrigerated Truck?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export Hualing HanmaH6 180hp 4X2(6 wheels) Refrigerated Truck?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
