CIMC 13m Grain Silo Semi-Trailer

Export reference
From $17,083
MSRP ¥12.3M CNY
Cab width:: 2.55m
Fifth Wheel Pin:: 50#
Design load capacity:: 40ton
Cab height:: 3.55m
Wheel brand:: Rishang
Brake chamber:: Imported
Axle Brand: CIMC
Curb Weight: 6.4ton
Cab length: 13m
Spare Tire Carrier: 2 unitspcs

Overview

The CIMC 13m Grain Silo Semi-Trailer is a Stake Semi-trailer featuring CIMC-axle setup, 6.4ton GVW, 13m length and 40ton payload.

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Design load capacity: 40ton
Cab length: 13m
Cab width: 2.55m
Cab height: 3.55m
Curb Weight: 6.4ton
Chassis Specs
Axle Brand: CIMC
Number of Axles: 3
Axle Load Rating: 10T
Wheel brand: Rishang
Number of wheels: 12
suspension: CIMC
Wheel Material: aluminum alloy
Parts & accessories
Fifth Wheel Pin: 50#
Brake chamber: Imported
Outrigger: aluminum alloy
Toolbox:
Spare Tire Carrier: 2 unitspcs
ABS: 4S/2M
Body Parameters
Frame material: high-strength steel
Floor Board: 2mm
frame rail height: 500mm
upper wing panel: 8mm
Box panel: 600+600+600
Lower Wing Plate: 10mm
Side beam: 140
Number of openings: 13
Other notes
Lead time for customization: in-stock vehicle sale
warranty period: One year
warranty method: National Warranty
Other: Electrophoresis + powder coating paint
Tire
Tire brand: Linglong
Tire Size: 12R22.5
Number of tires: 12pcs

Photos

Exterior3

3 photos

FAQ

What is the export price of CIMC 13m Grain Silo Semi-Trailer, and what does it include?

CIMC 13m Grain Silo Semi-Trailer export reference is about From $17,083; MSRP is ¥12.3M CNY. This estimate is based on China MSRP (near factory/EXW style) and usually excludes ocean freight, insurance and destination charges. Quantity, emission version, FOB/CIF and port change the final price — request a quote on this page.

What transport jobs is CIMC 13m Grain Silo Semi-Trailer suited for?

CIMC 13m Grain Silo Semi-Trailer is a Stake Semi-trailer model; configuration should match the job. State the application, emission and LHD/RHD needs in your quote.

How does CIMC 13m Grain Silo Semi-Trailer differ from other variants in the same series?

CIMC 13m Grain Silo Semi-Trailer belongs to CIMC brand 13.75m center-axle vehicle transport trailer (Stake Semi-trailer). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for CIMC 13m Grain Silo Semi-Trailer?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export CIMC 13m Grain Silo Semi-Trailer?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
