Foton Ruiwo E3 Engineering Type 130hp 4X2(6 wheels) 4.15m LNG Dump Truck

Export reference
From $20,389
MSRP ¥14.68M CNY
Emission: China V
Fuel: LNG (liquefied natural gas)
Transmission: WLY
Curb Weight:: 2.375ton
Wheelbase:: 3300mm
Tire Size:: 8.25R16
Rated payload: 1.99ton
Drive 4X2 (6 wheels)
Horsepower 130
Cargo box type: Rear-dump body

Overview

The Foton Ruiwo E3 Engineering Type 130hp 4X2(6 wheels) 4.15m LNG Dump Truck is a Light Truck featuring 1.99t payload, 4.495t GVW, Rear-dump body cargo body and 4X2 (6 wheels) drive. On the powertrain side, it comes with a Yunnei PowerYN38QNE engine, 130 hp, China V emissions and WLY transmission.

China V 130 LNG (liquefied natural gas) 4X2

Model Specs

Legend: ● Standard ○ Optional - N/A

Basic Info
Model code (announced): BJ3045D9JEA-5
Drive type: 4X2
Wheelbase: 3300mm
engine: Yunnei PowerYN38QNE
transmission: WLYWLY540CHF
Rear Axle Ratio: 6.33
Cab length: 5.995m
Cab width: 2.24m
Cab height: 2.5m
Front track width: 1620mm
rear track: 1669mm
Curb Weight: 2.375ton
Rated payload: 1.99ton
GVWR: 4.495ton
Origin: Shandong Zhucheng
tonnage class: Light Truck
Approach angle: 22°
departure angle: 12°
Version: Heavy-duty type
Energy Type: LNG (liquefied natural gas)
Engine parameters
Engine Brand: Yunnei Power
Engine Model: Yunnei PowerYN38QNE
Number of cylinders: 4cylinder
fuel type: LNG (liquefied natural gas)
Displacement: 3.76L
Emission standard: China V
Max output power: 95kW
Max hp: 130Horsepower
Max torque: 360N·m
Max torque speed: 1400-2200rpm
Rated speed: 3000rpm
Engine Type: Inline, 4-stroke, turbocharged intercooled, water-cooled, single-point electronic centralized injection system
Transmission Parameters
Transmission Model: WLYWLY540CHF
Transmission Brand: WLY
Forward gears: 5Gear
Number of Reverse Gears:
Cargo box parameters
Unloading Type: Rear-dump body
Cargo box type: Rear-dump body
Cargo box length: 4.15m
Cargo box width: 2.05m
Cargo box height: 0.55m
Chassis Specs
rear axle description: 1092Z Spring Brake
rear axle allowable load: 2925kg
Axle ratio: 6.33
Leaf spring count: 8/8+5
Tire
Tire Size: 8.25R16
Number of tires: 6pcs

Photos

Exterior1

1 photos

FAQ

What is the export price of Foton Ruiwo E3 Engineering Type 130hp 4X2(6 wheels) 4.15m LNG Dump Truck, and what does it include?

Foton Ruiwo E3 Engineering Type 130hp 4X2(6 wheels) 4.15m LNG Dump Truck export reference is about From $20,389; MSRP is ¥14.68M CNY. This estimate is based on China MSRP (near factory/EXW style) and usually excludes ocean freight, insurance and destination charges. Quantity, emission version, FOB/CIF and port change the final price — request a quote on this page.

What emission standard does Foton Ruiwo E3 Engineering Type 130hp 4X2(6 wheels) 4.15m LNG Dump Truck use, and can it enter my country?

This model is listed as China V. Import rules differ by country (some require Euro V/VI). Confirm local rules before ordering, and state your destination country in the quote request so we can check a suitable export configuration.

What are the key specs of Foton Ruiwo E3 Engineering Type 130hp 4X2(6 wheels) 4.15m LNG Dump Truck?

Key specs of Foton Ruiwo E3 Engineering Type 130hp 4X2(6 wheels) 4.15m LNG Dump Truck: Drive: 4x2; Horsepower: 130 hp; Emission: China V; Fuel: LNG (liquefied natural gas); Transmission: WLY. See full standard/optional equipment on this page. Mention your use case or destination rules in the quote if you need compliance or trailer matching advice.

What transport jobs is Foton Ruiwo E3 Engineering Type 130hp 4X2(6 wheels) 4.15m LNG Dump Truck suited for?

Foton Ruiwo E3 Engineering Type 130hp 4X2(6 wheels) 4.15m LNG Dump Truck is a Dump Trucks model often used on construction, mining and aggregate jobs. Check drive, horsepower and emission; state duty cycle and destination in your quote.

How does Foton Ruiwo E3 Engineering Type 130hp 4X2(6 wheels) 4.15m LNG Dump Truck differ from other variants in the same series?

Foton Ruiwo E3 Engineering Type 130hp 4X2(6 wheels) 4.15m LNG Dump Truck belongs to Foton E3 Light Truck (Dump Trucks). Variants usually differ by horsepower band, drive and emission. Compare on-sale configs and price range on the subseries page, then request a quote.

How do I get a real export quote for Foton Ruiwo E3 Engineering Type 130hp 4X2(6 wheels) 4.15m LNG Dump Truck?

Use Get a quote or the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission standard and Incoterms (e.g. FOB/CIF) so we can reply with a more executable export price.

Can I export Foton Ruiwo E3 Engineering Type 130hp 4X2(6 wheels) 4.15m LNG Dump Truck?

Yes. 86Trucks lists Chinese commercial trucks for export and connects quote requests. Documents, sailing and deal terms are confirmed in the quote reply.
