Sinotruk Wangpai W5G Heavy Truck 380 hp 6X4(10 wheels) 6.8m Dump Truck
EXW
From $50,792
Export quote
Sinotruk Wangpai W5G near-heavy truck Dump Trucks
Main model photos
85 photos
Models
Inventory
| Model | Drive / HP / Emission | EXW | Export quote |
|---|---|---|---|
| Sinotruk Wangpai W5G Heavy Truck 380 hp 6X4(10 wheels) 6.8m Dump Truck | 6x4 / 380hp / China V | From $50,792 | |
| Sinotruk Wangpai W5G Heavy Truck 380 hp 6X4(10 wheels) 6m Dump Truck | 6x4 / 380hp / China V | From $50,097 | |
| Sinotruk Wangpai W5G Heavy Truck 380 hp 6X4(10 wheels) 5.8m Dump Truck | 6x4 / 380hp / China V | From $50,097 | |
| Sinotruk Wangpai W5G heavy truck 380 hp 6X4(10 wheels) 5.6m dump truck | 6x4 / 380hp / China V | From $49,681 | |
| Sinotruk Wangpai W5G Heavy Truck 380 hp 6X4(10 wheels) 5.4m Dump Truck | 6x4 / 380hp / China V | From $49,681 |
Sinotruk Wangpai W5G Heavy Truck 380 hp 6X4(10 wheels) 6m Dump Truck
EXW
From $50,097
Export quote
Sinotruk Wangpai W5G Heavy Truck 380 hp 6X4(10 wheels) 5.8m Dump Truck
EXW
From $50,097
Export quote
Sinotruk Wangpai W5G heavy truck 380 hp 6X4(10 wheels) 5.6m dump truck
EXW
From $49,681
Export quote
Sinotruk Wangpai W5G Heavy Truck 380 hp 6X4(10 wheels) 5.4m Dump Truck
EXW
From $49,681
Export quote
Series Specs
Basic Info
Model code (announced): CDW5251ZLJA2S5 / CDW3252A2S5 / CDW3250A2S5 / CDW3250A2S4 / CDW3317A1S4
Drive type: 6X4 / 8X4
Wheelbase: 4600+1350 / 4100+1350 / 3800+1350 / 1850+4600+1350mm
Engine Model: SinotrukD10.38-50 / SinotrukD10.34-40
Transmission Model: SinotrukHW19712 / Sinotruk 12-speed / SinotrukHW15710C
Rear Axle Ratio: 5.45 / 5.921 / 5.263
Cab length: 9.9 / 9.3 / 8.8 / 8.6 / 8.4 / 9.09 / 8.49 / 8.66 / 8.46 / 11.32m
Cab width: 2.55 / 2.5 / 2480m
Cab height: 3.75 / 3.45 / 3.25 / 3.46m
Front track width: 2020 / 2017mm
rear track: 1847/1847 / 1860/1860 / 1860mm
Curb Weight: 12.5 / 11.955 / 11.95 / 14.88ton
Rated payload: 12.37 / 12.85 / 15.925ton
GVWR: 25 / 24.995 / 31ton
Origin: Chengdu, Sichuan
tonnage class: Heavy truck
Approach angle: 24 / 23°
departure angle: 23 / 20 / 24 / 17°
Remarks: HW70 PTO
Energy Type: Diesel
Engine parameters
Engine Brand: Sinotruk
Number of cylinders: 6cylinder
Displacement: 9.726L
Emission standard: China V / China IV
Max output power: 276 / 249kW
Max hp: 380 / 340Horsepower
Max torque: 1560 / 1490N·m
Max torque speed: 1200-1500rpm
Rated speed: 2000 / 1900rpm
Engine Type: Inline 6-cylinder, water-cooled, 4-stroke, turbocharged intercooled, high-pressure common rail
Transmission Parameters
Transmission Brand: Sinotruk
shift method: Manual
Forward gears: 12 / 10Gear
Number of Reverse Gears: 2pcs
Cargo box parameters
Unloading Type: Dump type / Rear-dump body
Cargo box length: 6.8 / 6 / 5.8 / 5.6 / 5.4 / 6.2 / 8.6m
Cargo box width: 2.35 / 2.3m
Cargo box height: 1.5 / 1.1 / 1.2 / 1.15 / 0.95m
Cab parameters
Cab: S80 / W5GS80 wide body mid roof
Cab suspension: Four-point air suspension
FAQ
What kind of truck is Sinotruk Sinotruk Wangpai W5G near-heavy truck Dump Trucks?
Sinotruk Sinotruk Wangpai W5G near-heavy truck is an export-oriented Dump Trucks lineup with about 10 variants listed here. Filter by drive, horsepower and emission, check reference prices and specs, then shortlist a configuration before requesting a quote.
What is the export price range for Sinotruk Wangpai W5G near-heavy truck Dump Trucks?
Sinotruk Wangpai W5G near-heavy truck Dump Trucks export reference is about $46,528 – $51,778. The band is estimated from MSRP — higher specs usually cost more — and typically excludes ocean freight and destination charges. Confirm the final price via quote (state FOB/CIF and port).
What spec range does Sinotruk Wangpai W5G near-heavy truck Dump Trucks cover?
Sinotruk Wangpai W5G near-heavy truck Dump Trucks mainly covers: Drive: 6x4; Horsepower: 380 hp; Emission: China V; Fuel: Diesel. Fix destination emission first, then pick drive and horsepower. See aggregated specs here, and open a model for full equipment.
How do I choose a variant in Sinotruk Wangpai W5G near-heavy truck Dump Trucks?
For Sinotruk Wangpai W5G near-heavy truck Dump Trucks: 1) confirm emission and duty (site/mine); 2) match drive and horsepower; 3) compare price band and photos; 4) open a model for full specs, then quote.
What is Dump Trucks typically used for?
Dump Trucks is common for earth, aggregate and mining tipper work. Match drive and power to the duty, and confirm destination emission.
How many models does Sinotruk Wangpai W5G near-heavy truck Dump Trucks include?
Sinotruk Wangpai W5G near-heavy truck Dump Trucks currently lists about 10 models. Browse On sale / Upcoming / Inventory, then open a model for full specs.
How do I request a quote for Sinotruk Wangpai W5G near-heavy truck Dump Trucks?
Shortlist by drive/horsepower, open a model and click Get a quote, or use the sidebar form. Include destination port/country, quantity, LHD/RHD, required emission and FOB/CIF terms.
